21Ton Water and Foam Tower Fire Truck

Make/Model:	CSCTRUCK/TFT020
Water+Foam:	16,600+4,400kg
Overall Dimensions(LxWxH):	11,400×2,500×3,100kg
Total weight:	40,800kg
Max. travel speed:	≥95km/h
Max. net power:	350kW
Rated working height:	20m
Max. working radius:	12.5m
Water monitor rated flow:	≥120L/s
Water monitor rated reach:	≥80m
Fire-rated flow:	≥100L/s
Fire-rated pressure:	≥1MPa

Truck Enquiry

Categories: Aerial Fire Truck, Tower Fire Truck

BRIEF

The CSCTRUCK Fire Rescue Truck 21Ton water and foam tower fire truck was built on the Benz Actros 4148 chassis. Designed as a multi-functional main battle truck, it combines the features of a water tank, a high-spraying system, and foam capabilities. This makes it highly effective for extinguishing fires in various environments, particularly in low-rise buildings within urban areas. Its utility extends to industrial and mining enterprises, petrochemical engineering plants, oil tank facilities, warehouses, and other high-risk locations. The truck’s advanced design ensures it can handle various fire hazards, offering a powerful solution for fire control and emergency response. Whether in an industrial setting or a commercial environment, the 21Ton water and foam tower fire truck provides reliable and efficient fire suppression, making it a critical asset in ensuring safety and minimizing damage during fire incidents.

FEATURES

● Key operational parameters are industry-leading: A working height of 20 meters, a reach of 12.5 meters, and a carrying capacity of 21,000 kg.

● Exceptional fire extinguishing capability: The fire system boasts a maximum flow rate of 80 liters per second, delivering a high-volume system flow with an extended range.

● Efficient and user-friendly operation with enhanced safety: Centralized control of the upper booms, turntables, water monitor, and pump rotation speed; the turntables offer 360° continuous rotation, ensuring high efficiency, safety, and comfort. A 25-meter wired remote control makes it ideal for hazardous fire scenarios, improving firefighter safety.

● Ergonomic design, advanced safety features, and a high level of intelligence.

SPECIFICATION

Item	Unit	Parameter
Overall length	mm	11,400
Overall height	mm	3,100
Overall width	mm	2,500
Total weight	kg	40,800
Extinguishant-rated load weight
Water	kg	16,600
Foam	kg	4,400
Dry powder	kg	–
Max. travel speed	km/h	≥95
Max. net power	kW	350
Rated working height	m	20
Max. working radius	m	12.5
Time for deploying the boom	s	≤70
Time for deploying outriggers	s	≤30
Monitor
Water monitor-rated flow	L/s	≥120
Water monitor-rated reach	m	≥80
Water pump
Fire-rated flow	L/s	≥100
Fire-rated pressure	MPa	≥1
