BRIEF
The 4×4 3T small water fire engine produced by CSCTRUCK Fire Rescue Truck is a compact yet highly capable firefighting vehicle designed for rapid response in urban streets, rural areas, industrial zones, and mountainous terrain. Built on the reliable DFV5101TGP6DJ chassis manufactured by Dongfeng, this unit combines durability, mobility, and efficient fire suppression performance in a compact footprint.
Powered by a 132 kW diesel engine delivering 177 horsepower and paired with a manual transmission, the truck provides strong traction and stable handling under demanding road conditions. The 4×4 driving configuration ensures excellent off-road capability, making it suitable for forest firefighting, construction sites, and remote rescue operations. With a wheelbase of 3,500 mm and overall dimensions of 6,520 × 2,350 × 3,200 mm, the vehicle offers a balanced structure that supports maneuverability without compromising stability.
The fire engine is equipped with a 3-ton (3,000 L) water tank, matching its liquid carrying capacity, allowing it to handle initial fire suppression efficiently. Its fire pump delivers dual performance options: 20 L/s at 2.0 MPa for high-pressure firefighting and 40 L/s at 1.0 MPa for large-volume water discharge. The roof-mounted fire monitor provides a flow rate of 40 L/s, enabling long-range and high-efficiency water projection.
Designed to accommodate a driver and one crew member (2 persons total), the cabin layout ensures quick deployment and operational readiness. Complying with EURO 6 emission standards, the vehicle meets modern environmental requirements while maintaining strong performance.
Overall, this 4×4 3T small water fire engine is an ideal solution for rapid-response firefighting tasks where mobility, compact size, and reliable water output are essential.
FEATURES
1. Reliable Dongfeng 4×4 Chassis
Built on the Dongfeng Motor Corporation DFV5101TGP6DJ chassis, this fire engine ensures structural durability and long-term reliability. The 4×4 drivetrain provides excellent traction and stability, making it highly suitable for urban streets, rural roads, construction sites, and mountainous terrain.
2. Powerful 177 HP Diesel Engine
Equipped with a 132 kW (177 horsepower) diesel engine and manual transmission, the vehicle delivers strong torque and smooth power output. This ensures rapid acceleration, dependable climbing performance, and stable handling even under demanding off-road or emergency response conditions.
3. Compact Yet Highly Maneuverable Design
With overall dimensions of 6,520 × 2,350 × 3,200 mm and a 3,500 mm wheelbase, the truck maintains an ideal balance between maneuverability and operational stability. Its compact footprint allows it to navigate narrow city streets, village roads, and confined industrial zones with ease.
4. Efficient 3,000L Water Tank Capacity
The 3-ton (3,000-liter) water tank provides sufficient capacity for initial fire suppression and emergency response. This makes the vehicle especially effective for first-arrival firefighting, forest patrols, and remote rescue operations where quick action is critical.
5. High-Performance Fire Pump & Monitor System
The fire pump offers dual performance modes:
- 20 L/s at 2.0 MPa (high-pressure firefighting)
- 40 L/s at 1.0 MPa (large-volume discharge)
The roof-mounted fire monitor delivers up to 40 L/s for long-range water projection, ensuring efficient fire control and improved operational coverage.
SPECIFICATION
|
Transmission type
|
Manual
|
|
Horsepower (hp)
|
177
|
|
Tank volume: Water
|
3t
|
|
Fuel
|
Diesel
|
|
Vehicle dimensions(LxWxH)
|
6,520*2,350*3,200mm
|
|
Chassis model
|
DFV5101TGP6DJ
|
|
Chassis manufacturer
|
Dongfeng
|
|
Driver and crew
|
2
|
|
Engine power
|
132kW
|
|
Wheelbase
|
3,500mm
|
|
Liquid carrying capacity
|
3t
|
|
Fire pump flow rate
|
20L/[email protected], 40L/[email protected]
|
|
Fire monitor flow rate
|
40L/s
|
|
Driving form
|
4X4
|
|
Emission standard
|
EURO 6
|
