BRIEF
The HOWO 10 Wheelers 16 CBM water foam fire tender produced by CSCTRUCK Fire Rescue Truck is a heavy-duty firefighting vehicle designed for rapid emergency response, high water-carrying capacity, and reliable fire suppression performance. Built on the robust SINOTRUK HOWO 6×4 chassis, this fire tender combines powerful mobility with advanced firefighting systems, making it ideal for municipal fire brigades, industrial zones, airports, warehouses, and petrochemical facilities.
With overall dimensions of 10,050 × 2,500 × 3,670 mm, the vehicle provides a balanced structure for maneuverability and stability. It has a gross vehicle weight of 26,800 kg and a curb weight of 14,350 kg, ensuring excellent payload capacity for firefighting equipment and extinguishing agents. The HW76 extended cab offers a comfortable and practical working environment with a single berth, air conditioner, adjustable steering wheel, safety belts, and ergonomic VDO instrumentation, allowing crews to travel efficiently to emergency scenes.

Power comes from the reliable WD615.87 diesel engine, delivering 290 horsepower with 9.726L displacement, paired with a 10-speed HW13710 gearbox for smooth driving performance across urban roads and rugged terrain. The HOWO 10 Wheelers 16 CBM water foam fire tender uses a durable braking system featuring dual-circuit pneumatic brakes, spring parking brakes, and engine exhaust braking for enhanced operational safety.
The fire suppression system includes a 12 CBM water tank and 4 CBM foam tank, both constructed from quality carbon steel for durability. Equipped with a CB10/60 normal-pressure fire pump, the unit delivers 60 L/s flow at 1.0 MPa, providing strong firefighting capability. The PL48 fire monitor supports both water and foam discharge, with ranges up to 60 meters for water and 55 meters for foam, plus full 360° rotation for flexible targeting.
Additional features include a sandwich PTO, complete pipeline system, pump room, equipment lockers, foldable rear pedal, and electrical control systems. Overall, this HOWO fire tender is a dependable, high-capacity solution for professional firefighting and rescue operations.
FEATURES
- High-Capacity Water & Foam System – Equipped with a 12 CBM water tank and 4 CBM foam tank, this fire tender offers a total 16 CBM extinguishing agent capacity, making it ideal for large-scale firefighting and prolonged emergency operations.
- Powerful Fire Suppression Performance – Fitted with a CB10/60 fire pump delivering 60 L/s at 1.0 MPa, along with a PL48 fire monitor, the vehicle provides strong water and foam jets with discharge ranges of 60 m (water) and 55 m (foam).
- Reliable HOWO Heavy-Duty Chassis – Built on the robust SINOTRUK HOWO 6×4 chassis, powered by a 290 HP WD615.87 diesel engine and matched with a 10-speed gearbox, it ensures dependable mobility, durability, and performance under demanding rescue conditions.
- Crew Comfort & Safety Design – The HW76 extended cab features a single berth, air conditioning, adjustable steering wheel, ergonomic dashboard, and safety belts, providing a comfortable and efficient workspace for firefighting crews during long deployments.
- Comprehensive Operational Equipment – Includes a sandwich PTO, full pipeline system, pump room, equipment lockers, foldable rear pedal, and advanced electrical controls, allowing firefighters quick access to tools and efficient emergency response.
SPECIFICATION
Vehicle Description |
|
| Overall dimensions(LxWxH) | 10,050*2,500*3,670mm |
| GVW | 26,800kg |
| Curb weight | 14,350kg |
| Chassis brand | SINOTRUK HOWO |
| Traction type | 6×4 |
Chassis Description |
||
| Chassis model | ZZ1257M4641W | |
| Cab | HW76-extended cab, single berth, adjustable steering wheel, VDO instrument and control module, safety belt with double locking mechanism, exterior sunroof, air-conditioner. | |
| Wheelbase | 4,600+1,350mm | |
| Tire specification | 315/80R22.5 | |
| Tire quantity | 10+1 units | |
| Engine | Engine model | WD615.87 |
| Emission level | Euro 2 | |
| Displacement/output | 9,726ml/213kW | |
| Horse power | 290hp | |
| Gear box | Model | HW13710 |
| Number of gears | 10 forward gears& 2 reverse, planetary reducer | |
| Brake system | Service brake: Dual-circuit pneumatic brake; Parking brake: Energy storage spring air cutoff brake; Auxiliary brake: Engine exhaust brake. |
|
| Axle | Front | HF-7T |
| Rear | ST-16T*2, ratio 4.8/5.73 | |
| Suspension | Front | Leaf springs with shock abosorber |
| Rear | Leaf springs with transverse stabilizer | |
| Fuel tanker | Type | Steel tanker, with lockable cap |
| Capacity | 400L | |
Tanker Description |
|||
| Tanker capacity | Water tanker | 12CBM, carbon steel | |
| Foam tanker | 4CBM, carbon steel | ||
| Configuration | 1 set manhole with quick lock and open device; 1 set overflow device; 1 set fluid level gauge; 1 set drain outlet with manual controlled. |
||
| Fire pump | Model | CB10/60, normal pressure pump | |
| Flux | 60L/S | ||
| Pressure | 1.0Mpa | ||
| Range | 55m | ||
| Fire monitor | Model | PL48 | |
| Pressure | 1.0Mpa | ||
| Range | Water | 60m | |
| Foam | 55m | ||
| Rotation angle | 360°, up 750, down 450 | ||
| Other configuration | Equipped with sandwich PTO, pipeline system; Equipped with equipment box and pump box; Equipped with flip pedal and electric system. Other equipment. |
||
