ISUZU ELF 4T Water Foam Tanker Fire Truck (3)

ISUZU ELF 4T Water Foam Tanker Fire Truck (4)

ISUZU ELF 4T Water Foam Tanker Fire Truck

Model No.:	CSCWFTFT004
Tank Capacity:	3 tons water + 1 ton foam
Overall Dimensions(LxWxH):	6,980×2,250×3,100mm
Chassis Brand:	ISUZU
Drive Type:	4×2
Wheelbase:	3,815mm
Engine Model:	4HK1-TCG61
Engine Power:	139kW
Emission Standard:	EURO VI
Maximum Speed:	100km/h
Fire Pump Model:	Shanghai CB10/30
Fire Monitor Model:	Wester PS30W
Fire Monitor Range:	≥50m(water), ≥45m(foam)

Truck Enquiry

BRIEF

The ISUZU ELF 4T water foam tanker fire truck, produced by CSCTRUCK Fire Rescue Truck, is a compact and highly efficient firefighting vehicle engineered for rapid response in urban areas, industrial zones, residential communities, and narrow streets. Built on the reliable ISUZU QL1110ANKAY chassis manufactured by Qingling Motors Co., Ltd., this truck combines excellent maneuverability with professional firefighting capabilities, making it ideal for various emergency scenarios.

Powered by the proven 4HK1-TCG61 engine from Isuzu Engine Co., Ltd., it delivers 139 kW (190 hp) with a displacement of 5,193 ml, achieving a top speed of 100 km/h. Its 6-speed manual transmission and 4×2 drive provide smooth handling and operational stability, while the 3,815 mm wheelbase ensures agility in confined spaces. The vehicle rides on 235/75R17.5 16PR tires, with a total of 6+1 tires for optimal load distribution.

The fire truck features a 3-ton water tank combined with a 1-ton foam tank, integrated with a high-performance Shanghai CB10/30 fire pump (optional CB10/40) and a Wester PS30W fire monitor, capable of reaching ≥50m for water and ≥45m for foam. The system is powered via a full-power PTO with water cooling, ensuring consistent performance under demanding conditions.

The vehicle body is built for durability and functionality. Its 4-door full-metal cabin offers panoramic visibility, electric windows, and modern lighting. The tank body utilizes high-quality carbon steel with anti-surge baffles and epoxy anti-corrosion treatment; Stainless steel is optional for enhanced durability. Equipment compartments feature high-strength aluminum alloy roll-up doors, secure European aluminum profile brackets, and concealed tower joints for both safety and aesthetics.

The electrical system includes front and rear sirens and lights, side flashing signals, compartment lighting, and a rotary switch with communication interface readiness, providing comprehensive operational safety and visibility. This ISUZU ELF 4T fire truck blends performance, reliability, and professional-grade firefighting capability in a compact, versatile platform.

FEATURES

Compact and Highly Maneuverable: Built on the ISUZU QL1110ANKAY chassis with a 3,815 mm wheelbase, 4×2 drive, and 235/75R17.5 tires, this fire truck excels in urban environments, narrow streets, and confined spaces.
Powerful and Reliable Engine: Equipped with the 4HK1-TCG61 engine from Isuzu Engine Co., Ltd., delivering 139 kW (190 hp) and 5,193 ml displacement, allowing a top speed of 100 km/h for rapid emergency response.
Efficient Firefighting System: Features a 3-ton water tank and 1-ton foam tank, high-performance Shanghai CB10/30 (optional CB10/40) fire pump, and Wester PS30W monitor capable of projecting water ≥50 m and foam ≥45 m, powered by a full-power PTO with water cooling.
Durable and Functional Body: Full-metal 4-door cabin with panoramic visibility, modern lighting, and electric windows; Tank body made of carbon steel with anti-surge baffles and epoxy anti-corrosion treatment (optional stainless steel); Secure equipment compartments with aluminum alloy roll-up doors.
Comprehensive Safety and Electrical System: Includes front/rear sirens and lights, side flashing signals, compartment lighting, and a rotary switch with communication interface readiness, ensuring safe, efficient, and highly visible operation.

SPECIFICATION

Category	Item	Specification
Chassis Parameters	Chassis Model	QL1110ANKAY
	Chassis Manufacturer	Qingling Motors Co., Ltd.
	Engine Model	4HK1-TCG61
	Engine Manufacturer	Isuzu Engine Co., Ltd.
	Engine Power	139 kW (190 hp)
	Engine Displacement	5,193 ml
	Max Speed	100 km/h
	Tire Size	235/75R17.5 16PR
	Number of Tires	6+1
	Drive Type	4×2
	Transmission	6-speed Manual
	Wheelbase	3,815 mm
	Tank Capacity	3 tons water + 1 ton foam
Water Cannon System Parameters	Fire Pump Model	Shanghai CB10/30 (optional CB10/40)
	Fire Monitor Model	Wester PS30W
	Fire Monitor Range	Water ≥ 50 m, Foam ≥ 45 m
	Power Take-Off (PTO)	Full-power PTO with water cooling
Vehicle Body Parameters	Cabin	4-door flat-nose full-metal closed cabin, factory double row, panoramic curved windshield, front bumper, combination front lights, electric windows, front lower mask
	Tank Body	High-quality carbon steel (Q23**), welded structure, with longitudinal and transverse anti-surge baffles, epoxy anti-corrosion treatment. Foam tank standard: 304 stainless steel. Water tank optional: 304 stainless steel
	Equipment Compartments	Fire pump positioned mid or rear. 4 water outlets on the pump room sides. Compartments with new high-strength aluminum alloy roll-up doors. Equipment brackets made from European aluminum profiles, concealed tower joint design, full internal hex connections, durable, and aesthetic
	Electrical Configuration	Front top of cabin: Long-row 100W siren. Rear: 24V/60W fire scene light. Vehicle sides: Red-blue flashing lights. Safety marker lights installed below. Lighting in the cabin, compartments, and pump room. Rotary switch and communication interface prepared.
