MAN 5ton CAFS Tanker Fire Truck

BRIEF

The MAN 5-ton CAFS tanker fire truck, manufactured by CSCTRUCK Fire Rescue Truck, is a highly advanced and efficient firefighting vehicle designed for rapid response and large-scale fire suppression. Built on the MAN TGS 21.510 chassis, this vehicle combines robust engineering, powerful performance, and modern firefighting technology to ensure maximum reliability and operational efficiency in challenging fire rescue scenarios.

Equipped with a 4,200-liter water tank and an 800-liter foam tank, the truck utilizes a Compressed Air Foam System (CAFS) capable of delivering a maximum flow rate of 100 liters per second, providing superior fire extinguishing capability with reduced water consumption. The CAFS system enhances foam stability, penetration, and coverage, making it particularly effective in combating fuel, chemical, and industrial fires.

Powered by a V6 engine delivering 377 kW at 1,800 rpm, the truck offers exceptional torque and performance while maintaining a maximum speed of 85 km/h. The 4×2 drive configuration ensures stable handling and maneuverability, suitable for both urban and rural firefighting operations. With a full-load weight of approximately 18,700 kilograms, it maintains excellent balance and durability under demanding conditions.

The firefighting system is equipped with a HALE CB10/100-RSD fire pump, featuring a rated pressure of 1.0 MPa and a rated flow of 80 L/s, ensuring strong and consistent water delivery. Complementing this is the POK PL10/64-LMP80 fire monitor, capable of projecting water up to 75 meters and foam up to 70 meters, with a 0°–360° horizontal rotation and electric remote control operation for precise targeting.

Overall, the MAN 5-ton CAFS tanker fire truck represents a perfect blend of power, efficiency, and modern firefighting innovation, making it an essential asset for professional fire departments and industrial emergency response teams.

FEATURES

1. Advanced CAFS Technology
   Equipped with a high-performance Compressed Air Foam System (CAFS) delivering up to 100 L/s, the truck ensures superior fire suppression efficiency with extended foam coverage, reduced water consumption, and faster cooling effects during firefighting operations.
2. High-Capacity Dual Tank System
   The truck features a 4,200L water tank and an 800L foam tank, allowing versatile firefighting capabilities for various fire types, including flammable liquids and solid materials, ensuring long-duration operations without frequent refilling.
3. Powerful and Reliable Chassis
   Built on the robust MAN TGS 21.510 chassis with a 4×2 drive type, powered by a 377 kW/1,800 rpm V6 engine, it provides strong traction, high stability, and excellent performance even under full load conditions of approximately 18,700 kg.
4. Efficient Fire Pump and Monitor System
   Fitted with a HALE CB10/100-RSD fire pump (rated pressure 1.0 MPa, flow 80 L/s) and a POK PL10/64-LMP80 fire monitor (range: water ≥75m, foam ≥70m), the truck offers powerful discharge performance, electric remote control operation, and a full 360° horizontal rotation angle for flexible firefighting.
5. Enhanced Mobility and Operational Safety
   With a maximum driving speed of 85 km/h, ergonomic control layout, and high-grade materials, the MAN 5-ton CAFS tanker ensures quick emergency response, durability, and safe handling during both urban and industrial firefighting missions.

SPECIFICATION
