The Dongfeng EURO VI small fire truck that sprays water is built on a Dongfeng small tanker fire truckchassis and is equipped with a Liuzhou 1.5T EURO VI gasoline engine, delivering a maximum of 113 horsepower. It features a 5-speed gearbox, a 1.5-ton front axle, a 2.5-ton rear axle, and 185R14 vacuum rear dual tires. Standard configurations include power steering, ABS, a multifunction steering wheel, central locking, electric windows, and front disc brakes.
Item
Specification
Overall Dimensions (L × W × H)
5,230 × 1,670 × 2,360 mm
Wheelbase
2,600 mm
Gross Vehicle Weight
3,390 kg
Curb Weight
2,420 kg
Rated Load
820 kg
Mounted Tank Total Capacity
0.818 m³
Water Tank
740 kg / 0.74 m³ Dimensions: 775 × 1,000 × 1,000 mm
Fire Suppressant Tank (Water-based)
80 kg / 0.078 m³ Dimensions: 80 × 1,000 × 1,000 mm
Pump
Imported Italian high-pressure pump
Firefighting System
Water mist system, multifunction spray fire nozzle
This Dongfeng EURO VI small water fire truck is suitable not only for micro fire stations but also for deployment in firefighting units, urban streets, communities, commercial outlets, densely populated areas, tourist attractions, key cultural heritage sites, and local township professional fire brigades for emergency fire rescue. In the event of a sudden fire, it can quickly reach the scene to carry out firefighting operations, ensuring early detection and rapid containment to prevent fire spread and escalation.
