The Sinotruk SITRAK Dual-row Euro VI 5CBM Compressed Air Foam Fire Truck is equipped with a SITRAK dual-row cab, with a standard seating capacity of 2+4 people. It is powered by a Sinotruk 340-horsepower engine, delivering a maximum power output of 251 kW and a peak torque of 1,250 N·m. It comes with 315/80R22.5 tires, and standard features include power windows, air conditioning, and ABS.
| Item | Specification |
|---|---|
| Overall Dimensions (L × W × H) | 8,700 × 2,530 × 3,600 mm |
| Gross Vehicle Weight | 17,800 kg |
| Rated Load Capacity | 5,000 kg |
| Curb Weight | 12,350 kg |
| Upper-Mounted Tank Total Volume | 4.977 m³ |
| Water Tank Volume & Dimensions | 4.000 m³ (2,090 × 1,400 × 1,430 mm) |
| Class A Foam Tank Volume & Dimensions | 0.291 m³ (505 × 420 × 1,430 mm) |
| Class B Foam Tank Volume & Dimensions | 0.686 m³ (510 × 980 × 1,430 mm) |
| Side Protection | Integrated structure |
| Rear Protective Device Material | Q235A steel |
| Rear Protective Device Size (W × H) | 60 × 120 mm |
| Rear Protective Device Mounting | Bolted connection |
| Ground Clearance of Rear Device | 435 mm |
With its configuration, this fire truck carries both Class A foam and Class B foam, enabling it to extinguish both Class A fires (solid fires) and Class B fires (liquid fires). This allows flexible switching during firefighting operations, effectively enhancing adaptability in real combat situations while improving rescue efficiency.
Application Scenarios:
This compressed air foam tanker fire truck is suitable for extinguishing Class A and Class B fires, limited-space fires, and controlling flowing fires of liquefied petroleum gas (LPG) and liquefied natural gas (LNG). Typical use cases include:
- Solid material warehouses
- Flammable liquid warehouses
- Industrial workshops with fire hazards
- Underground construction projects
- Engine rooms of various ships
- Protection of valuable instruments, equipment, and materials
- Flowing fires involving flammable liquids, LPG, and LNG
