BRIEF
The 6-Wheeler 6CBM water tanker fire truck produced by CSCTRUCK Fire Rescue Truck is a compact yet powerful firefighting and water transport vehicle designed for rapid response in urban, industrial, and rural environments. Built on the reliable Dongfeng chassis, this model combines durability, maneuverability, and performance, making it ideal for both firefighting and general water supply operations.
Powered by the CY4SK361 engine, the tanker fire truck delivers 125 kW (170 HP), ensuring robust performance and stability even under demanding conditions. With a 4×2 drive type and a top speed of 90 km/h, it offers excellent road handling and swift deployment capabilities. The engine complies with the EURO VI emission standard, ensuring low emissions and environmental friendliness without compromising power efficiency.
The 6CBM water tanker fire truck is equipped with a 6 CBM (6,000 liters) stainless steel water tank that provides ample water capacity for small to medium-scale fire emergencies. It features a CB10/30 fire pump with strong suction and discharge capabilities, ensuring consistent water delivery during operations. The onboard PS30 fire monitor enables a fire flow rate of 30 liters per second and a firefighting range of over 55 meters, allowing firefighters to control flames effectively from a safe distance.
Designed with practicality in mind, the truck includes user-friendly control systems, corrosion-resistant tank materials, and efficient plumbing layouts for reliable performance. Its compact structure makes it suitable for narrow streets and quick maneuvering, while the combination of power, range, and efficiency ensures adaptability across multiple firefighting scenarios.
Overall, the 6CBM water tanker fire truck stands out as a versatile and efficient emergency response vehicle—balancing speed, capacity, and operational reliability to meet modern firefighting demands with confidence and precision.
FEATURES
- High-Performance Firefighting System
Equipped with a CB10/30 fire pump and PS30 fire monitor, this fire truck delivers a 30L/s fire flow rate with a fire range of up to 55 meters, ensuring powerful water discharge for effective firefighting operations. - Large-Capacity Water Tank
The truck features a 6,000-liter (6CBM) water tank, providing sufficient water supply for medium-scale firefighting and emergency response missions without frequent refilling. - Reliable Dongfeng Chassis
Built on a durable Dongfeng 4×2 chassis, the vehicle offers excellent stability, maneuverability, and load-bearing capacity, making it suitable for urban, suburban, and industrial firefighting applications. - Efficient and Eco-Friendly Engine
Powered by a CY4SK361 diesel engine with 125kW (170HP) output, the truck meets the EURO VI emission standard, delivering strong performance with reduced emissions and improved fuel efficiency. - Excellent Mobility and Speed
With a maximum speed of 90 km/h, the truck ensures rapid response to fire emergencies, allowing firefighters to reach incident sites quickly and efficiently.
SPECIFICATION
General Parameters
| Item | Specification |
|---|---|
| Model | CSCWTFT006 |
| Dimensions (L×W×H) | 6,940 × 2,195 × 3,060 mm |
| Gross Weight | 11,270 kg |
| Crew Capacity | 3 + 3 persons |
Chassis Parameters
| Item | Specification |
|---|---|
| Chassis Manufacturer | Dongfeng Motor Co., Ltd. |
| Chassis Model | EQ1125SJ8CDC |
| Engine Model | CY4SK361 |
| Engine Power | 125 kW (170 HP) |
| Engine Displacement | 3856 mL |
| Maximum Speed | 90 km/h |
| Tire Specification | 245/70R19.5 |
| Number of Tires | 6 + 1 |
| Drive Type | 4×2 |
| Transmission | Manual, 6-speed |
| Wheelbase | 3,800 mm |
| Emission Standard | EURO VI |
Firefighting System Parameters
| Item | Specification |
|---|---|
| Tank Capacity | 5.5 m³ |
| Power Take-Off | Full-power PTO, forced water cooling |
| Fire Pump Model | CB10/30 |
| Fire Monitor Model | PS30 |
| Fire Flow Rate | 30 L/s |
| Fire Range | ≥ 55 m |
Cabin Description
Flat-head, 4-door cab with optional rear exhaust air intake, power steering, clutch assist, electric windows, central locking, air conditioning, and circuit breaker.
Water Tank Description
Made of high-quality carbon steel (Q235) or optional stainless steel 304/PP.
Internal and external anti-corrosion coating, equipped with transverse baffles and wave-resistant structure.
Includes manhole, overflow port, and drain valve.
Firmly connected to the vehicle chassis with a corrosion-resistant frame.
Equipment Compartment
The main frame is welded with high-quality square tubing.
Located behind the crew cabin with aluminum roll-up doors on both sides and the rear.
Internal lighting and control panels are included for convenience.
Electrical Configuration
- Front roof: 100 W siren and red/blue warning lights
- Rear roof: 35 W top-mounted lamps
- Sides: red/blue strobe lights
- Underside: standard lighting
- Cab and crew cabin: intercom, lighting, indicator, and operation illumination
Fire Equipment List
| No. | Item | Specification | Quantity | Unit | Remarks |
|---|---|---|---|---|---|
| 1 | Suction Hose | Φ125 × 4 m | 2 | pcs | Screw type |
| 2 | Filter | FLF125 | 1 | pcs | Screw type |
| 3 | Water Divider | FII80/65×3–1.6 | 1 | pcs | Internal thread |
| 4 | Water Collector | JII125/65×2–1.0 | 1 | pcs | Internal thread |
| 5 | Hose (65 mm) | 13-65-20 | 6 | rolls | Low-pressure, internal thread |
| 6 | Hose (80 mm) | 13-80-20 | 6 | rolls | Low-pressure, internal thread |
| 7 | Adapter | KJ65/80 | 2 | pcs | Internal thread |
| 8 | Hose Wrap | DT-SB | 4 | pcs | — |
| 9 | Hose Hook | — | 4 | pcs | — |
| 10 | Above-Ground Fire Hydrant Wrench | QT-DS1; 400 mm | 1 | pcs | — |
| 11 | Underground Fire Hydrant Wrench | 860 mm | 1 | pcs | — |
| 12 | Suction Hose Wrench | FS100 | 2 | pcs | — |
| 13 | Straight Stream Nozzle | QZG3.5/7.5; 65 | 1 | pcs | Low-pressure, internal thread |
| 14 | Spray Nozzle | QZK3.5/7.5; 65 | 1 | pcs | Low-pressure, internal thread |
| 15 | Fire Bucket | — | 1 | pcs | — |
| 16 | Fire Extinguisher | 3 kg | 1 | pcs | — |
| 17 | Fire Axe | 390 mm; GF-285 | 1 | pcs | — |
| 18 | Rubber Hammer | — | 1 | pcs | — |
| 19 | Rechargeable Portable Lamp | — | 1 | pcs | — |
