BRIEF
The HOWO 10-wheel 18 CBM water tender fire truck from CSCTRUCK Fire Rescue Truck is a robust, high-capacity firefighting vehicle engineered to deliver a rapid water supply in demanding environments. Designed on the proven HOWO/ZZ5357TXFV464MF5 chassis, this truck combines exceptional strength with reliable performance, making it well-suited for municipal fire brigades, industrial complexes, airports, and rural operations where large water volumes are critical.
At the heart of the truck is an MC11.44-60 diesel engine, delivering 327 kW of power while complying with the EURO VI emission standard, ensuring both powerful operation and environmental responsibility. Its 6×4 drive configuration and carefully balanced suspension provide excellent traction and stability, enabling the vehicle to maintain control across paved and unpaved surfaces. With a maximum road speed of 95 km/h, it can reach incident sites quickly, even across extended distances.
The centerpiece of the tanker fire truck is its 18 CBM (18,000 L) water tank, offering a substantial reservoir for firefighting operations in areas without immediate access to hydrants or additional supply. Complementing this capacity is a CB10/60 water pump, built for efficiency and high-volume flow, paired with a PS50 water monitor that delivers a water jet with a reach of ≥60 m. This allows crews to attack flames from a safe distance, control large-scale blazes, or supply water to auxiliary firefighting equipment.
Ergonomic controls, reinforced bodywork, and optimized weight distribution ensure reliability and ease of operation. The water tender’s heavy-duty design supports sustained use under tough conditions, while its emissions-compliant engine reflects modern environmental standards. Altogether, the HOWO 10-wheel 18 CBM water tender fire truck offers fire services a durable and efficient solution for transporting and deploying large volumes of water, helping protect lives and property in both urban and remote firefighting scenarios.
BRIEF
- High-Capacity Water Tank – Equipped with an 18 CBM (18,000 liters) water tanker, ensuring ample supply for firefighting and emergency water delivery operations.
- Robust Chassis and Drive – Built on the HOWO/ZZ5357TXFV464MF5 chassis with a 6×4 drive configuration, providing durability, strength, and stability on varied terrains.
- Powerful and Efficient Engine – Powered by an MC11.44-60 engine delivering 327 kW of output and meeting the EURO VI emission standard, combining performance with environmental compliance.
- Advanced Pumping and Discharge System – Fitted with a CB10/60 water pump and PS50 water monitor, capable of delivering strong, consistent water flow for efficient firefighting.
- Extended Water Jet Range – Features a water monitor with ≥60 m effective range, allowing crews to tackle fires from a safe distance and cover wide areas quickly.
SPECIFICATION
| Item | Details |
|---|---|
| Chassis Brand | HOWO |
| Producer | CSCTRUCK Fire Rescue Truck |
| Product Name | HOWO 10 Wheelers 18 CBM Water Tender Fire Truck |
| Gross Vehicle Weight (kg) | 33,400 |
| Tank Capacity (m³) | 17.600 |
| Rated Load (kg) | 17,600 |
| Dimensions (L×W×H, mm) | 10,290 × 2,540 × 3,770 |
| Curb Weight (kg) | 15,350 |
| Cargo Compartment Size (mm) | N/A |
| Cab Seating Capacity (persons) | 2 + 4 |
| Approach / Departure Angle (°) | 15 / 10 |
| Front / Rear Overhang (mm) | 1,500 / 2,790 |
| Axle Load (kg) | 8,500 / 12,450 / 12,450 |
| Max Speed (km/h) | 95 |
| Remarks | Water tank capacity: 17.6 m³, irregular shape. Front size: 1,500×1,400×1,550 mm; rear size: 3,950×2,450×1,550 mm. Integrated side guard; rear guard material: Q23**, section size: 120×120 mm, bolted connection, clearance 447 mm. ABS by WABCO (Shanghai), model 4460046300. Main equipment: CB10/60 fire pump, PS50 water monitor, water jet ≥60 m. |
Chassis Technical Parameters
| Item | Details |
|---|---|
| Chassis Model | ZZ5357TXFV464MF5 |
| Chassis Name | Fire Truck Chassis |
| Brand | HOWO |
| Manufacturer | China National Heavy Duty Truck Group Jinan Truck Co., Ltd. |
| Axle Count | 3 |
| Tire Count | 10 |
| Wheelbase (mm) | 4300+1400, 4325+1350, 4600+1400, 4625+1350, 5200+1400, 5225+1350, 5800+1400, 5825+1350 |
| Tire Specification | 385/65R22.5 / 315/80R22.5 18PR, 385/65R22.5 / 12.00R20 18PR |
| Leaf Springs | 10/12, 4/12, 4/5, 4/-/- |
| Front Track (mm) | 2,110 |
| Rear Track (mm) | 1,830/1,830; 1,850/1,850 |
| Fuel Type | Diesel |
| Emission Standard | EURO VI |
| Engine Model | MC11.44-60 |
| Engine Manufacturer | CNHTC Group |
| Displacement (mL) | 10,518 |
| Power (kW) | 327 |
