BRIEF
The SITRAK 10 Wheelers 20T Swap Body Fire Vehicle, manufactured by CSCTRUCK Fire Rescue Truck, is a high-performance modular emergency response vehicle designed for large-scale firefighting, rescue operations, and specialized disaster management missions. Based on the reliable SITRAK heavy-duty chassis platform, this vehicle combines powerful driving capability, a high-capacity hook lift system, and flexible swap body technology to provide multiple emergency response solutions with one carrier vehicle.
With overall dimensions of 9,000 mm in length, 3,700 mm in height, and 2,550 mm in width, the vehicle offers a robust structure while maintaining excellent road mobility. The 23,750 kg gross vehicle weight allows it to carry heavy firefighting modules, rescue equipment, water tanks, foam systems, command units, or other customized containers, depending on operational requirements.
Powered by a 341 kW high-performance engine, the SITRAK 10-wheel fire vehicle can achieve a maximum speed of 100 km/h, ensuring rapid deployment to emergency locations. Its power-to-weight ratio reaches 14 kW/t, providing strong acceleration and reliable performance even under heavy loads.
The key feature of this vehicle is its 20-ton hook lift system, which enables fast loading and unloading of various swap bodies. Container loading takes about 50 seconds, while unloading takes only 56 seconds, significantly improving operational efficiency and reducing preparation time during emergencies. This modular design allows firefighting departments to quickly change mission-specific equipment and adapt to different scenarios, including urban fires, industrial accidents, hazardous material incidents, and disaster relief operations.
In addition, the vehicle is equipped with a powerful towing system featuring a 75 kN rated single-line pulling force, a 34-meter tow cable, and an 11.5 mm cable diameter, providing reliable recovery and rescue capability for damaged vehicles and heavy equipment.
The SITRAK 10 Wheelers 20T Swap Body Fire Vehicle represents an advanced solution for modern emergency services, offering flexibility, durability, and multi-functional capability for professional firefighting and rescue teams worldwide.
FEATURES
1. Advanced Modular Swap Body Design
The SITRAK 10 Wheelers 20T Swap Body Fire Vehicle adopts a flexible modular design that allows 1 carrier vehicle to operate with multiple specialized firefighting modules. Different swap bodies, including water tank modules, foam firefighting modules, rescue equipment modules, command units, and hazardous material response units, can be quickly installed according to different emergency scenarios.
2. Powerful 20-Ton Hook Lift System
Equipped with a heavy-duty 20-ton hook lift system, this vehicle enables efficient loading and unloading of various firefighting containers. The container loading time is only about 50 seconds, and unloading takes approximately 56 seconds, greatly improving deployment speed and operational efficiency during urgent rescue missions.
3. High-Performance SITRAK Heavy-Duty Chassis
Built on a reliable SITRAK 10-wheel chassis, the vehicle delivers excellent stability, durability, and mobility. Powered by a 341 kW engine, it reaches a maximum speed of 100 km/h, allowing rapid response to urban fires, industrial accidents, natural disasters, and large-scale emergency situations.
4. Large Load Capacity and Multi-Purpose Operation
With a gross vehicle weight of 23,750 kg, the vehicle can carry heavy firefighting equipment, rescue systems, and customized emergency modules. Its high payload capability makes it suitable for complex operations requiring large amounts of water, foam, specialized tools, or additional rescue equipment.
5. Reliable Towing and Recovery Capability
The vehicle features an integrated towing system with a 75 kN rated single-line pulling force, a 34-meter tow cable, and an 11.5 mm cable diameter. This provides strong recovery capability for accident vehicles, damaged equipment, and heavy rescue operations, enhancing overall emergency response performance.
SPECIFICATION
| Category | Item | Unit | Specification |
|---|---|---|---|
| Dimension Parameters | Overall Vehicle Length | mm | 9,000 |
| Overall Vehicle Height | mm | 3,700 | |
| Overall Vehicle Width | mm | 2,550 | |
| Weight Parameters | Gross Vehicle Weight | kg | 23,750 |
| Driving Parameters | Maximum Speed | km/h | 100 |
| Rated Power | kW | 341 | |
| Power-to-Weight Ratio | kW/t | 14 | |
| Hook Lift System | Maximum Lifting Capacity | t | 20 |
| Container Loading Time | s | 50 | |
| Container Unloading Time | s | 56 | |
| Towing System | Rated Single-Line Pulling Force | kN | 75 |
| Tow Cable Length | m | 34 | |
| Tow Cable Diameter | mm | 11.5 |
Notes:
- Hook Lift System = refers to the hydraulic hook-loader mechanism used for Swap Body Fire Trucks, allowing quick installation and removal of different firefighting modules (water tank module, foam module, rescue equipment module, command module, etc.).
- Container Loading Time = time required to load the swap body/container onto the vehicle.
- Container Unloading Time = time required to unload/remove the swap body/container.
- Towing System = parameters referring to the winch/towing equipment installed on the vehicle.
