BRIEF
The Ford 10-People Fire Rescue Van, produced by CSCTRUCK Fire Rescue Truck, is a versatile emergency response vehicle designed to transport firefighters, rescue personnel, and essential firefighting equipment efficiently to incident locations. Built on a reliable Ford chassis, this fire rescue van combines passenger capacity, mobility, and practical emergency-response performance, making it suitable for fire stations, industrial facilities, airports, municipalities, and other emergency service applications.
The vehicle measures 6,703 × 2,164 × 2,920 mm, with a gross vehicle mass of 5,000 kg and a kerb weight of 3,580 kg. It provides seating for 10 passengers, allowing an entire response team to travel together while carrying necessary rescue equipment. The 3,750 mm wheelbase and six-tire configuration provide a stable platform for emergency operations.
For safe and reliable driving, the van is equipped with ABS (Anti-lock Braking System). Its approach and departure angles of up to 19° and 12°, respectively, provide useful mobility when accessing uneven roads, facility entrances, rural areas, and other challenging emergency-response environments. Depending on the configuration, the vehicle can reach a maximum speed of up to 150 km/h, supporting rapid deployment when time is critical.
The Ford chassis uses a diesel engine that meets the EURO VI emissions standard, offering a modern and environmentally conscious powertrain for professional emergency services. The vehicle features 195/75R16C tires, a front track of 1,740 mm, and a rear track of 1,702 mm.
Overall, the Ford 10-People Fire Rescue Van is a practical solution for organizations requiring a multi-person emergency transport and fire rescue vehicle with dependable Ford chassis performance, high passenger capacity, modern safety features, and rapid-response mobility.
FEATURES
1. 10-Person High-Capacity Cabin
The Ford Fire Rescue Van provides seating for 10 passengers, allowing firefighters, rescue personnel, and emergency teams to reach incident locations together. Its spacious configuration also supports the transportation of essential rescue tools and firefighting equipment.
2. Reliable Ford Chassis & EURO VI Engine
Built on a dependable Ford chassis, the vehicle is powered by a diesel engine meeting EURO VI emission standards. This combination provides reliable road performance while meeting modern environmental requirements for professional emergency services.
3. Rapid Emergency Response Performance
With a maximum speed of up to 150 km/h, the van is designed for rapid deployment when response time is critical. Its 3,750 mm wheelbase and 6-tire configuration provide a stable driving platform for emergency operations.
4. Strong Mobility on Challenging Roads
The vehicle features approach and departure angles of 19° and 12°, respectively, helping it access uneven roads, rural areas, industrial facilities, and other locations with difficult entry conditions. The 195/75R16C tires further support dependable road mobility.
5. Modern Safety & Practical Design
Equipped with ABS (Anti-lock Braking System), the Ford Fire Rescue Van provides improved braking control during emergency driving. With dimensions of 6,703 × 2,164 × 2,920 mm, a 5,000 kg GVM, and practical emergency equipment capacity, it offers a balanced combination of safety, passenger transport, and rescue functionality.
SPECIFICATION
| Basic Vehicle Parameters | |
| Product Number | CSCFRV |
| Product Name | Ford 10-People Fire Rescue Van |
| Overall Dimensions(Length×Width×Height)(mm) | 6,703×2,164×2,920 |
| Gross Vehicle Mass(GVM)(kg) | 5,000 |
| Kerb Weight(kg) | 3,580 |
| Rated Passengers | 10 |
| Front Overhang/Rear Overhang(mm) | 1,023/2,097, 1,023/1,930 |
| Approach Angle/Departure Angle(°) | 19/11, 19/12 |
| Axle Load(kg) | 1,720/3,280 |
| Anti-lock Braking System (ABS) | YES |
| Fuel Consumption | – |
| Maximum Speed(km/h) | 150, 100 |
| Chassis Parameters | |
| Chassis Brand | Ford |
| Chassis Model | / |
| Number of Axles | 2 |
| Wheelbase(mm) | 3,750 |
| Number of Tires | 6 |
| Tire Specification | 195/75R16C |
| Front Track(mm) | 1,740 |
| Rear Track(mm) | 1,702 |
| Number of Leaf Springs | -/3 |
| Fuel Type | Diesel |
| Emissions Standard | EURO VI |
