BRIEF
The HOWO 60M Mobile Smoke Exhaust Fire Truck, produced by CSCTRUCK Fire Rescue Truck, is a high-performance emergency response vehicle specially designed for smoke extraction, ventilation, cooling, and firefighting support in large and complex fire scenes. Built on a reliable HOWO chassis and meeting EURO VI emission standards, the vehicle combines powerful smoke exhaust, long-distance air supply, water mist spraying, lighting, and firefighting capabilities in one integrated platform.
The truck has overall dimensions of 8,820 × 2,500 × 3,900 mm and is equipped with a powerful 75 kW exhaust engine. Its main smoke exhaust system can achieve an impressive smoke emission capacity of 351,000 m³/h, allowing it to rapidly remove dense smoke from tunnels, underground facilities, industrial plants, warehouses, and large buildings. The exhaust system provides a 60 m spray range under no-wind or downwind conditions, with a spray pressure of 0.7–1.0 MPa.
For long-distance ventilation operations, the vehicle provides both positive-pressure air supply and negative-pressure smoke extraction, each reaching 70,000 × 2 m³/h. The maximum positive-pressure air supply distance is 200 m, while the maximum negative-pressure draft distance reaches 100 m, helping firefighters improve visibility and working conditions in smoke-filled environments.
The truck is also equipped with a 128 kW generator and a powerful mobile lighting system featuring four 1,000 W lights, providing up to 80,000 lm of luminous flux and a maximum lifting height of 8 m. Its fire pump delivers 20 L/s at 1.0 MPa, while an optional high-power foam system supports a flow rate of 16 L/s and a foaming ratio of 201–1,000.
With one-click intelligent control, plus wired remote, intelligent, and manual control modes, the HOWO 60M Mobile Smoke Exhaust Fire Truck offers flexible and efficient operation for demanding emergency rescue missions.
FEATURES
- Ultra-High Smoke Exhaust Capacity
Equipped with a powerful 75 kW exhaust engine, the truck provides an impressive smoke exhaust capacity of up to 351,000 m³/h, enabling rapid smoke removal from tunnels, underground facilities, warehouses, and industrial buildings. - 60-Meter Water Mist Spray Range
The integrated water mist system offers a spray range of up to 60 meters with a pressure of 0.7–1.0 MPa, helping suppress heat, cool fire scenes, and improve visibility during firefighting operations. - Long-Distance Positive & Negative Pressure Ventilation
The vehicle supports both positive-pressure air supply and negative-pressure smoke extraction, with each reaching 70,000 × 2 m³/h. Air supply can reach 200 m, while negative-pressure smoke extraction reaches up to 100 m. - Powerful Generator & Mobile Lighting System
A 128 kW generator powers four 1,000 W lighting units, producing up to 80,000 lm of luminous flux. The lighting system can be raised to 8 meters, providing effective illumination for nighttime and low-visibility rescue operations. - Intelligent Multi-Mode Control
The HOWO 60M features one-click intelligent control and supports wired remote, intelligent, and manual operating modes, allowing firefighters to quickly adjust ventilation, smoke exhaust, water mist, lighting, and other systems according to different emergency conditions.
SPECIFICATION
|
ITEM
|
VALUE
|
|
|
Finished car
|
Model
|
CSCMSEFT060
|
|
Emission standard
|
EURO VI
|
|
|
Outline size(LxWxH)
|
8,820×2,500×3,900mm
|
|
|
Exhaust smoke capacity
|
351,000m³/h
|
|
|
Liquid carrying capacity
|
1,150kg
|
|
|
Generator power
|
128kW
|
|
|
Main exhaust system
|
Exhaust engine power (kW))
|
75
|
|
Exhaust engine rated voltage(V)
|
380
|
|
|
Distance from ground(m)
|
4
|
|
|
Pitch Angle(°)
|
-42~+50
|
|
|
Horizontal turning Angle (°)
|
±360(unlimited rotation)
|
|
|
Smoke emission (m³/h)
|
351,000
|
|
|
Spray pressure (MPa)
|
0.7-1.0
|
|
|
Spray range (m)
|
60(when there is no wind or downwind)
|
|
|
Water mist flow (L/s)
|
2
|
|
|
Long distance positive and negative pressure air supply and smoke exhaust
|
Positive pressure remote air supply (m³/h)
|
70,000×2
|
|
Maximum positive pressure supply (m)
|
200
|
|
|
Negative pressure remote air supply (m³/h)
|
70,000×2
|
|
|
Maximum negative pressure draft (m)
|
100
|
|
|
Positive pressure distance water mist flow (L/s)
|
5
|
|
|
Long range positive Pressure spray Range (m)
|
20
|
|
|
Main parameters of generator
|
Generator power (kW)
|
128
|
|
Generator speed (r/min)
|
1,500
|
|
|
Generator voltage (V)
|
AC400
|
|
|
Main parameters of moving and lifting lighting
|
Horizontal turning Angle (°)
|
380
|
|
Vertical turning Angle (°)
|
330
|
|
|
Lighting Power (W)
|
1,000×4
|
|
|
Luminous flux (Im)
|
80,000
|
|
|
Maximum ground lift (m)
|
8
|
|
|
Voltage (V)
|
220
|
|
|
Fire pump
|
Rated pressure (MPa)
|
1.0
|
|
Flow rate (L/s)
|
20
|
|
|
Working water pressure (MPa)
|
0.3~1.0
|
|
|
High power foam
(Selection)
|
Flow volume L/s
|
16
|
|
Foaming ratio
|
201~1,000
|
|
|
Mixing ratio (%)
|
3~9
|
|
|
Control meth
|
1-click full function intelligent control
3 control modes: wired remote control +
intelligent control + manual control
|
