Mercedes Benz 80M Ventilation Fire Vehicle

BRIEF

The Mercedes-Benz 80M Ventilation Fire Vehicle, manufactured by CSCTRUCK Fire Rescue Truck, is a high-performance emergency support vehicle designed for smoke extraction, ventilation, and air supply operations in large-scale fire rescue scenarios. Built on the reliable Mercedes-Benz Arocs 3358 6×4 chassis, this vehicle combines powerful driving capability, advanced ventilation technology, and multi-functional emergency support performance, making it ideal for urban firefighting, underground rescue, tunnel incidents, industrial fires, and complex disaster response missions.

Equipped with a powerful 162kW smoke exhaust system, the vehicle delivers an impressive full exhaust capacity of up to 800,000 m³/h, allowing rapid removal of smoke, toxic gases, and high-temperature air from fire scenes. Its positive pressure ventilation system provides an effective exhaust distance of more than 80 meters under windless or downwind conditions, helping firefighters quickly establish a safer working environment. The vehicle also supports remote air supply operations, with a single air duct delivering 120,000 m³/h and a double air duct reaching 240,000 m³/h, with a maximum air supply distance of up to 300 meters.

For negative pressure smoke extraction, the Mercedes-Benz 80M Ventilation Fire Vehicle offers a single duct suction capacity of 110,000 m³/h and a double duct capacity of 220,000 m³/h, with an extraction distance of up to 150 meters. These capabilities make it highly effective for enclosed spaces such as tunnels, basements, warehouses, and underground facilities.

The vehicle is powered by a Mercedes-Benz diesel engine meeting EURO 5 emission standards, delivering strong performance while maintaining reliability in demanding environments. With overall dimensions of 10,365 × 2,520 × 3,920 mm and a 2,050kg water loading capacity, it integrates firefighting support and logistics functions into one advanced platform.

As a professional ventilation and smoke removal solution, the Mercedes-Benz 80M Ventilation Fire Vehicle from CSCTRUCK Fire Rescue Truck provides firefighters with powerful airflow management, enhanced operational safety, and efficient disaster response capabilities for modern emergency rescue applications.

FEATURES

1. Powerful Smoke Extraction & Ventilation Performance
   Equipped with a 162kW high-power smoke exhaust system, the Mercedes-Benz 80M Ventilation Fire Vehicle provides an outstanding exhaust capacity of up to 800,000 m³/h, enabling rapid removal of smoke, toxic gases, and high-temperature air from fire scenes to improve visibility and rescue efficiency.
2. Long-Distance Positive & Negative Pressure Air Management
   The vehicle supports both positive pressure air supply and negative pressure smoke extraction operations. It delivers up to 240,000 m³/h air supply through dual ducts with a distance of 300 meters, while negative pressure extraction reaches 220,000 m³/h with an extraction distance of up to 150 meters.
3. Reliable Mercedes-Benz Arocs 6×4 Chassis
   Built on the durable Mercedes-Benz Arocs 3358 6×4 chassis, this ventilation fire vehicle offers excellent power, stability, and off-road adaptability for demanding emergency environments, including tunnels, industrial facilities, underground spaces, and large-scale fire rescue operations.
4. Multi-Functional Emergency Support Capability
   Designed as a professional logistics support and ventilation rescue vehicle, it integrates smoke removal, air supply, and firefighting support functions. With a 2,050kg water loading capacity, it provides additional operational support during complex disaster response missions.
5. Advanced Fire Rescue Solution for Complex Environments
   Featuring a robust EURO 5 Mercedes-Benz diesel engine, large airflow capacity, and efficient ventilation technology, the Mercedes-Benz 80M Ventilation Fire Vehicle helps firefighters create safer working conditions in high-risk areas such as tunnels, warehouses, basements, and industrial fire sites.

SPECIFICATION
