BRIEF
The ISUZU Light Support Fire Truck, manufactured by CSCTRUCK FIRE RESCUE TRUCK, epitomizes cutting-edge technology and efficient design in fire response vehicles. With a 50kW electric generator providing robust power, this fire truck ensures uninterrupted operation even in the most demanding situations.
Powered by the 4HK1-TCG40 engine model, boasting 139kW maximum power output and adhering to the EURO IV emission standard, the ISUZU Fire Truck delivers not only formidable performance but also maintains environmental consciousness.
The vehicle’s 3-seat cab provides ample space for the firefighting crew, enabling swift coordination and response during emergencies. Coupled with a 4×2 drive type, the fire truck offers optimal maneuverability in varied terrains, ensuring it can swiftly reach the scene of the incident.
With a driving speed of 95km/h, this fire truck can swiftly navigate through urban areas and highways to reach the site of a fire or emergency promptly. Equipped with a FIRECO SRL pneumatic lifting poker capable of lifting heights exceeding 12 meters and a payload capacity of 200kg, the ISUZU Light Support Fire Truck facilitates efficient firefighting operations, enabling personnel to access elevated locations with ease and precision.
Additionally, the inclusion of the FI/CB/16.0MH lifting lighting control cabinet ensures that the firefighting team has adequate illumination to carry out operations effectively during low-light conditions or at night.
The meticulous engineering and advanced features of the ISUZU Light Support Fire Truck underscore its suitability for modern firefighting needs. Whether combating urban blazes or providing support during rescue missions, this vehicle stands as a beacon of reliability, efficiency, and safety in fire response operations.
FEATURES
1. Efficient Power Generation: The ISUZU light support fire truck manufactured by CSCTRUCK FIRE RESCUE TRUCK is equipped with a robust 50kW electric generator, providing ample power for various firefighting equipment and auxiliary functions, ensuring uninterrupted operations during emergencies.
2. Powerful Engine Performance: Featuring a 4HK1-TCG40 engine model, this fire truck delivers a rated power of 139 kW and a maximum power output of 139 kW, offering reliable and robust performance essential for swift response and effective firefighting tasks.
3. Advanced Emission Standards: Compliant with EURO IV emission standards, the ISUZU fire truck by CSCTRUCK FIRE RESCUE TRUCK demonstrates a commitment to environmental sustainability by minimizing harmful emissions during its operation, contributing to cleaner air and reduced environmental impact.
4. Flexible and Spacious Cab Design: With a spacious 3-seat cab configuration, firefighters can navigate to emergency sites comfortably, ensuring swift response. The ergonomic layout allows for efficient communication and coordination among crew members during critical operations.
5. Enhanced Operational Capabilities: Equipped with a FIRECO SRL pneumatic lifting poker capable of lifting heights ≥12 meters and with a payload capacity of 200 kg, coupled with the FI/CB/16.0MH Lifting lighting control cabinet, this fire truck enables firefighters to access elevated areas and illuminate the scene effectively, enhancing overall operational efficiency and safety during rescue missions.
SPECIFICATION
| Vehicle | Item | Unit | Value |
| Dimension (L×W×H) | mm | 6,705×2,200×3,210 | |
| Gross weight | kg | 8,150 | |
| Complete vehicle shipping mass | kg | 3,925 | |
| Electric generator-rated power | kW | 50 | |
| Seat (inc. driver) | 3 | ||
| Rated power | kW | 139 | |
| Chassis | Manufacturer | Isuzu | |
| Model | QL11009KARY | ||
| Drive Type | 4×2 | ||
| Cab | Original X-P301 | ||
| Wheelbase | mm | 3,815 | |
| Max. speed | km/h | 95 | |
| Min. turning diameter | ＜15 | ||
| Engine type | In-line four-cylinder, high-pressure common rail, water inter-cooling | ||
| Model | 4HK1-TCG40 | ||
| Max. power | kW | 139 | |
| Max. torque | N•m | 510 | |
| Emission standard | EURO IV | ||
| Clutch | Diaphragm spring, monolithic, dry, hydraulic power-assisted | ||
| Gearbox model | Manual, 6 forward gear | ||
| Pneumatic lifting poker | Manufacturer | FIRECO SRL | |
| Model | CI3912NI | ||
| Lift height | m | ≥12 | |
| Contraction | m | 2 | |
| Diameter | mm | 250 | |
| Load | kg | 200 | |
| Main lighting system | 50kw electric generator, 2x8kw main lamp, pneumatic lifting poker, holder, controller, air compressor, power distribution system, auxiliary lighting. | ||
| Lifting lighting control cabinet3 | Model | FI/CB/16.0MH | |
| Intelligent electric meters | Voltage, current, frequency | ||
| Aviation waterproof plug | 1x Electric supply input | ||
| 2x electric generator | |||
| Power: 6KW | |||
| Panel intelligent control | 2x Main light open | ||
| 1x pitching | |||
| Panel emergency control | |||
| Internally installed | Wireless receiver | ||
| Holder | Model | TT31626 | |
| Rotation angle | ° | 360 | |
| Pitching angle | ° | 300 | |
| Load | kg | 150 | |
| Auxiliary lighting (2x halogen lamp) | Power: | W | 2×1,500 |
| Voltage: | VAC | 220 | |
| Air compressor | Model: | QW-400 | |
| Type: | Maintenance-free mute oilless air compressor | ||
| Power: | kW | 2.5 | |
| Flow: | L/min | 260 | |
| Air supply management: | oil-water separator pressure regulating valve | ||
