BRIEF
The SITRAK 24-People modular accommodation unit, developed by CSCTRUCK Fire Rescue Truck, is a specialized mobile support solution designed to provide safe, comfortable, and reliable living conditions during extended emergency response missions, disaster relief operations, and field deployments. Built on a robust Sitrak chassis with a 4×2 drive type, the vehicle offers both stability and maneuverability, making it suitable for various terrains and operational environments. With a maximum driving speed of 110 km/h, it ensures rapid deployment to critical locations when urgent accommodation is required.
This unit fully complies with the EURO VI emission standard, reflecting its environmentally responsible design and reduced emissions performance. Equipped with a 5 kW onboard power supply generator and a 220V rated voltage system, it guarantees stable and independent energy for lighting, air conditioning, and other onboard electrical facilities, while also being compatible with external power sources when available.
The accommodation module is specifically designed to house 24 personnel, making it ideal for fire rescue teams, emergency crews, or field staff. Inside, the unit is structured with modular bunk arrangements that maximize available space while ensuring individual comfort. Ventilation systems, climate control features, and essential amenities support long-term living conditions in challenging environments.
Functioning as a mobile base of operations, the SITRAK 24-People modular accommodation unit not only enhances living standards for frontline personnel but also contributes to operational efficiency by keeping teams well-rested and organized. Compact yet highly functional, it represents the integration of modern engineering, sustainability, and human-centered design to meet the growing demands of field-based rescue and support missions.
FEATURES
- The SITRAK 24-People modular accommodation unit is designed for high mobility and excellent off-road performance, ensuring reliable operation in diverse terrains. Its expandable side cabins, available in both manual and automatic options, create a significantly larger interior space for improved comfort and usability.
- A large-capacity water tank with a centralized sewage collection system supports extended field operations, while the integrated onboard generator, combined with compatibility for external power input, guarantees a stable and flexible energy supply.
- Inside, the bunk bed layout is complemented by a TV, air conditioning, and other essential living facilities, providing a comfortable and functional environment for occupants. The body is constructed from lightweight yet durable aluminum alloy, offering insulation, fire-retardant properties, environmental friendliness, and easy cleaning for long-term serviceability.
- For safety and operational support, the vehicle is equipped with flashing warning lights, floodlights, external storage compartments, and anti-slip flooring, ensuring secure and efficient use in both day and night conditions.
SPECIFICATION
General Vehicle Parameters
| Item | Specification |
|---|---|
| Product Brand | CSCTRUCK Fire Rescue Truck |
| Announcement Batch | 372 (Extended) |
| Product Name | Accommodation Vehicle |
| Model | CSCMAU024 |
| Gross Vehicle Weight (Kg) | 18,000 |
| Tank Volume (m³) | – |
| Rated Load Capacity (Kg) | – |
| Dimensions (mm) | 10,440 × 2,550 × 3,990 |
| Curb Weight (Kg) | 17,870 / 17,805 |
| Cargo Compartment Size (mm) | – |
| Rated Passenger Capacity | – |
| Permissible Towed Mass (Kg) | – |
| Cab Passenger Capacity | 2 / 3 |
| Saddle Max. Load (Kg) | – |
| Approach/Departure Angle (°) | 16 / 9 |
| Front/Rear Overhang (mm) | 1450/3190, 1450/3390 |
| Axle Load (Kg) | 6500 / 11,500 |
| Max. Speed (Km/h) | 110 |
| Notes | ABS Model: 4460046300 (WABCO Shanghai). Chassis wheelbase options: 5,600mm, 5,800mm. Optional exterior, rear structure, internal layout. Side/rear protection: Q235 steel, 120×120mm, bolt connection, 460mm ground clearance. The top is fully enclosed and non-openable. Equipped with beds, cabinets, and a TV for field accommodation. Side/rear lights are only usable during operation. |
Chassis Parameters
| Item | Specification |
|---|---|
| Chassis Model | ZZ5186XXYN561GF1 |
| Chassis Name | Van Truck Chassis |
| Brand | SITRAK |
| Manufacturer | CNHTC Jinan Commercial Vehicle Co., Ltd. |
| Axles | 2 |
| Tires | 6 |
| Wheelbase (mm) | 3,600 / 3,800 / 4,200 / 4,500 / 4,700 / 5,000 / 5,200 / 5,600 / 5,800 / 6,300 |
| Tire Size | 295/80R22.5, 12R22.5, 11.00R20, 10.00R20, 275/80R22.5, 295/60R22.5, 315/60R22.5, 12.00R20 (all 18PR) |
| Leaf Springs | Multiple options (2–11) |
| Front Track (mm) | 1900 / 1950 / 1998 / 2015 / 2035 |
| Rear Track (mm) | 1850 |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2018 EURO VI |
Engine Options
| Engine Model | Manufacturer | Displacement (ml) | Power (kW) |
|---|---|---|---|
| MC07.29-60 / MC07.31-60 / MC07.33-60 / MC07.25-60 / MC07.34-60 / MC07.27-60 / MC05H.25-60 / MC07.25-61 / MC07.27-61 / MC07.29-61 / MC07H.31-61 / MC07H.33-61 / MC07H.35-61 / MC07H.35P-61 | CNHTC | 4,910–7,360 | 180–258 |
| WP7.270E61 / WP6H245E61 / WP8.350E61 / WP7.300E61 / WP6H270E61 / WP7H270E62 / WP7H300E62 / WP7H320E62 | Weichai Power | 6,220–7,800 | 180–257 |
Functional Configuration
- Accommodation: 12 sets of bunk beds, 24-person capacity.
- Sanitary Facilities: Independent shower, toilet, washbasin, forced ventilation, dual-layer outward windows with automatic ventilation.
- Power Supply: 5 kW generator, 220V, 4–6 hours single run. External power input compatible.
- Living Facilities: Air conditioning, heating, TV, audio system, lighting, lockers, bedside lamps, and sockets.
Applications
- Improves field accommodation and mission support capability.
- Widely used in the military, police, firefighting, medical, emergency rescue, and disaster relief.
- Supports 8–24 people for camping, rescue, or field operations.
