BRIEF
The SITRAK 10 CBM Mobile Decontamination Unit, manufactured by CSCTRUCK Fire Rescue Truck, is a professional emergency response vehicle designed for chemical hazardous material leakage, nuclear, biological, and chemical (NBC) accident response, as well as other special disaster scenarios. Built on a reliable SINOTRUK heavy-duty truck chassis, this vehicle combines powerful mobility, large-capacity liquid storage, and advanced decontamination technology to provide rapid and effective cleaning solutions for personnel, equipment, and contaminated environments.
Equipped with a 10 m³ independent tank system, the vehicle features separate storage compartments for clean water and multiple decontamination agents. The tank configuration includes a 7,000-liter water tank and two 1,500-liter decontamination agent tanks, allowing flexible preparation of different chemical treatment solutions according to emergency requirements. This independent compartment design improves operational efficiency and ensures safe transportation and use of various decontamination materials.
The SITRAK mobile decontamination unit integrates a professional chemical decontamination system, high-performance firefighting pump, long-range firefighting monitor, emergency lighting system, and rescue winch. It can perform multiple functions, including chemical cleaning, emergency spraying, firefighting assistance, nighttime operation support, and rescue equipment handling. With optional pump configurations providing 40–80 L/s flow rates and 1–4 MPa pressure, the vehicle delivers strong spraying performance with a maximum monitor range of up to 96 meters.
Powered by a EURO VI diesel engine and featuring a 27,000 kg gross vehicle weight, the vehicle offers excellent durability and heavy-duty operation capability. Its reinforced protection structure, Q235 carbon steel rear protection device, standard ABS braking system, and optional ZF EBS electronic braking system enhance driving stability and operational safety.
With its combination of large decontamination capacity, multifunctional emergency equipment, and robust heavy-duty performance, the SITRAK 10 CBM Mobile Decontamination Unit is an ideal solution for hazardous chemical emergency teams, fire departments, industrial safety organizations, and specialized disaster response units requiring reliable NBC decontamination capability.
FEATURES
1. Professional NBC Decontamination Capability
Designed for chemical hazardous material leakage, nuclear, biological, and chemical (NBC) emergencies, the SITRAK 10 CBM Mobile Decontamination Unit provides rapid and efficient decontamination solutions for personnel, vehicles, equipment, and contaminated areas. It is suitable for fire departments, industrial emergency teams, and disaster response organizations.
2. Large-Capacity Independent Tank System
The vehicle is equipped with a 10 m³ independent liquid storage system, including a 7,000-liter water tank and two 1,500-liter decontamination agent tanks. The separated compartments allow different cleaning agents to be stored safely and provide extended operation capability during large-scale emergency missions.
3. Multifunctional Emergency Equipment Integration
The unit combines a chemical decontamination system, high-performance firefighting pump, long-range firefighting monitor, lighting system, and rescue winch in one vehicle. This multifunctional design enables decontamination, firefighting assistance, emergency spraying, night operations, and rescue support.
4. Heavy-Duty SINOTRUK Chassis with Strong Performance
Built on a reliable SINOTRUK heavy-duty truck chassis, the vehicle offers excellent load capacity, durability, and mobility in challenging environments. Powered by a EURO VI diesel engine with a 27,000 kg GVW, it is capable of long-duration and high-intensity emergency operations.
5. Enhanced Safety and Operational Reliability
The SITRAK decontamination vehicle features an integrated protection structure, reinforced Q235 carbon steel rear underrun protection, and a standard ABS braking system. The optional ZF EBS electronic braking system further improves active safety, vehicle stability, and operational confidence in complex rescue scenarios.
SPECIFICATION
1. Product Overview
| Item | Description |
|---|---|
| Product Name | SITRAK 10 CBM Mobile Decontamination Unit |
| Application | Designed for chemical hazardous material leakage, nuclear, biological, and chemical (NBC) accidents, and other special disaster scenarios |
| Main Functions | Rapid and thorough decontamination of personnel, equipment, and contaminated environments |
| Tank System | Equipped with large-capacity independent water tank and decontamination agent tanks for separate storage |
| Special Equipment | Integrated chemical decontamination system, high-pressure firefighting pump, firefighting monitor, lighting system, and winch |
| Chassis | Based on a mature SINOTRUK heavy-duty truck chassis |
| Power System | Available with multiple high-power engine options for strong performance and heavy-duty operations |
| Working Capability | Suitable for rapid deployment and long-duration, high-intensity decontamination missions |
2. Product Features
| Feature | Description |
|---|---|
| Independent Compartment Tank | Equipped with a total tank capacity of 10 m³, allowing separate storage of water and multiple decontamination agents |
| Professional Decontamination System | Integrated chemical decontamination equipment enables fast and efficient decontamination operations |
| Safety Protection Structure | Adopts an integrated side protection structure and reinforced rear underrun protection to improve driving and operation safety |
| Advanced Brake System (Optional) | Optional EBS electronic braking system improves active vehicle safety performance |
3. Technical Specifications
A. Vehicle Specifications
| Parameter | Specification |
|---|---|
| Overall Dimensions (L × W × H) | 10,410 × 2,530 × 3,850 mm |
| Gross Vehicle Weight (GVW) | 27,000 kg |
| Curb Weight | 16,550 kg |
| Number of Axles | 3 |
| Wheelbase Options | 4,800+1,400 mm |
| Number of Tires | 10 |
| Tire Options | 385/65R22.5 + 315/80R22.5 or 385/65R22.5 + 12.00R20 |
| Fuel Type | Diesel |
| Emission Standard | EURO VI |
B. Body Modification Specifications
| Parameter | Specification |
|---|---|
| Total Tank Capacity | 10.000 m³ |
| Water Tank Capacity | 7.000 m³ |
| Water Tank Type | Special-shaped tank |
| Water Tank Dimensions | 1,793 × 2,492 × 1,675 mm |
| Decontamination Agent Tank 1 Capacity | 1.500 m³ |
| Decontamination Agent Tank 1 Type | Special-shaped tank |
| Decontamination Agent Tank 1 Dimensions | 780 × 1,246 × 1,675 mm |
| Decontamination Agent Tank 2 Capacity | 1.500 m³ |
| Decontamination Agent Tank 2 Type | Special-shaped tank |
| Decontamination Agent Tank 2 Dimensions | 780 × 1,246 × 1,675 mm |
| Rear Protection Material | Q235 Carbon Steel |
| Rear Protection Cross Section | 120 × 120 mm |
| Rear Protection Connection | Bolted connection |
| Rear Protection Ground Clearance | 460 mm |
| ABS System Model | 4460046300 |
| ABS Manufacturer | ZF Commercial Vehicle Control Systems (Qingdao) Co., Ltd. |
4. Standard Configuration
| Standard Equipment | Description |
|---|---|
| Side Protection Structure | Integrated side protection design |
| Rear Protection Device | Q235 steel rear protection with bolted connection |
| ABS System | Standard anti-lock braking system |
| Chemical Decontamination System | Main special-purpose equipment for chemical cleaning and decontamination |
| Fire Pump | High-performance firefighting pump |
| Fire Monitor | Equipped for long-range water/agent spraying |
| Lighting System | Provides illumination for night operations and emergency scenes |
| Winch | Used for rescue assistance and equipment handling |
5. Optional Configuration
| Optional Item | Specification |
|---|---|
| Fire Pump Flow Rate | 40–80 L/s |
| Fire Pump Pressure Range | 1–4 MPa |
| Fire Monitor Flow Rate | 40–80 L/s |
| Fire Monitor Range | 55–96 m |
| Electronic Braking System | Optional EBS system |
| EBS Model | EBS3 |
| EBS Manufacturer | ZF Commercial Vehicle Control Systems (Qingdao) Co., Ltd. |
Key Selling Points Summary
| Advantage | Description |
|---|---|
| Multi-Function Emergency Vehicle | Combines chemical decontamination, firefighting, spraying, lighting, and rescue functions |
| Large Decontamination Capacity | 10 m³ independent tank system supports extended field operations |
| Strong Heavy-Duty Performance | SINOTRUK heavy chassis provides excellent load capacity and reliability |
| Chemical Disaster Response Capability | Designed for hazardous chemical leakage and NBC emergency response |
| High Safety Level | Integrated protection structure and optional EBS electronic braking system enhance operational safety. |
