BRIEF
The 6×6 5CBM off road water fire truck produced by CSCTRUCK Fire Rescue Truck is a rugged and highly capable emergency response vehicle designed for firefighting operations in challenging off-road and remote environments. Built on a durable 6×6 drivetrain platform, this fire truck is engineered to deliver strong traction, stability, and mobility across rough terrains such as mountains, rural roads, construction sites, and disaster-affected areas where standard fire engines may struggle to operate effectively.
Powered by a 210 HP (155 kW) diesel engine with a 5.9L displacement, turbocharged and inter-cooled for enhanced performance, the vehicle provides reliable power output and torque up to 720 N·m. It is equipped with a FAST 8-speed manual transmission with transfer case, ensuring smooth gear transitions and adaptable driving performance in both on-road and off-road conditions. The truck features a 5,000-liter water tank capacity, making it suitable for medium-scale firefighting missions and rapid water supply support.
The cab design features a Tianjin double-row structure with air conditioning and ergonomic instrument layout, accommodating up to 2+4 passengers for efficient crew deployment. Safety and control are enhanced through a power steering system, air brake system, and exhaust brake function, ensuring stable handling under heavy-load emergency conditions. With an overall dimension of 8,500 × 2,500 × 3,700 mm and a curb weight of 9,000 kg, the truck balances capacity and maneuverability effectively.
Firefighting performance is strengthened by a CB10/40 fire pump with a rated flow of 40 L/s and a PS40 fire monitor capable of reaching over 60 meters, ensuring powerful water discharge for rapid fire suppression. Standard equipment includes a national-standard fire equipment box, sliding gate storage, reel system, rear climbing ladder, and auxiliary tools. Optional configurations such as foam and dry powder systems further enhance operational flexibility, making this 6×6 5CBM off road water fire truck a versatile solution for modern fire and rescue missions.
FEATURES
- Powerful 6×6 Off-Road Mobility
Built on a heavy-duty 6×6 drivetrain, the truck delivers strong traction, stability, and maneuverability, enabling reliable operation on mountains, rural roads, construction sites, and disaster zones. - High-Performance Diesel Powertrain
Equipped with a 210 HP (155 kW) turbocharged and inter-cooled diesel engine with 5.9L displacement, providing strong torque and dependable power output for demanding firefighting missions. - Efficient Water Firefighting System
Features a 5,000-liter water tank paired with a CB10/40 fire pump (40 L/s) and a PS40 fire monitor with a reach of over 60 meters for fast and effective fire suppression. - Robust Transmission and Control System
Uses a FAST 8-speed manual transmission with transfer case, along with power steering, air brakes, and exhaust braking for safe and controlled driving under heavy loads. - Functional Crew and Equipment Design
Double-row cab accommodates 2+4 firefighters with air conditioning and ergonomic layout, while integrated equipment storage, sliding doors, reel system, and optional foam/dry powder systems enhance operational versatility.
SPECIFICATION
| Model | CSCWFT005 | ||
| Cab | Tianjin double row cab, channel type instrument panel, air conditioner, allowable 2+4 passengers | ||
| Engine(Hp) | 210 | ||
| Power(Kw) | 155 | ||
| Wheelbase | 3,500+1,250mm | ||
| Front/Rear Suspension | 1,440/2,280mm | ||
| Steering | Power steering | ||
| Approach/departure angle | 33/11 | ||
| Wheels & tire | 12R22.5 | ||
| Tire number | 6+1 | ||
| Tank Dimensions(mm) | |||
| Cubage (m3) | 5 | ||
| RHD or LHD | Optional | ||
| Overall Dimensions(mm) | 8,500×2,500×3,700 | ||
| Curb weight (Kg) | 9,000 | ||
| Engine | Model | B210 33 | |
| Horsepower | 210 | ||
| Maximum output Kw | 155 | ||
| Maximum torque N.m | 720 | ||
| Type | 6 cylinders, in-line,4-stroke,turbo inter-cooling, diesel engine | ||
| Displacement | 5.900L | ||
| Cummins brand, Euro 3 | |||
| Driving passenger | 2+4 | ||
| Transmission | FAST 8 speed forward and one reverse, manual with transfer case | ||
| Front Axle | 5T | ||
| Rear Axle | 5Tx2 | ||
| Brake System | Air brake Exhaust brake |
||
| Color and LOGO | Customized | ||
| Electric system | 24V | ||
| Fire equipment part | Fire pump | CB10/40, rated pressure 1.0MPa, flow 40L/s | |
| Fire gun | PS40, flow 40L/s, jet distance ≥60m | ||
| Standard configuration | National standard equipment box, with national standard fire-fighting equipment, fire pump, fire gun,fire power take off, sliding gate, row type lights, reel, common tools ,rear climbing ladder, water tank. | ||
| Optional configuration | Foam type, dry powder type, other requirements. | ||
