BRIEF
The HOWO 4×4 8000L water foam tanker fire truck, produced by CSCTRUCK Fire Rescue Truck, is a high-performance emergency response vehicle designed for firefighting operations in urban areas, industrial zones, and challenging off-road environments. Built on the reliable Sinotruk HOWO 4×4 chassis, this fire truck combines strong mobility, durability, and advanced firefighting capability in one dependable platform.
With overall dimensions of 8,100 × 2,496 × 3,080 mm and a 4,300 mm wheelbase, the vehicle offers excellent stability and maneuverability. Its 4×4 drivetrain allows it to travel through rough terrain, muddy roads, construction sites, and rural locations where conventional fire trucks may struggle. The approach and departure angles of 19° and 24° further enhance off-road access during rescue missions.
Powered by the Sinotruk WD615.69 diesel engine, this fire truck delivers 336 horsepower through an HW19710 gearbox with 10 forward and 2 reverse gears. The engine features turbocharging, intercooling, and water cooling for reliable performance under heavy-duty conditions. With a maximum driving speed of 90 km/h, the truck can respond quickly to emergency calls while maintaining strong hauling power.
The firefighting body is equipped with an 8,000-liter combined tank system, consisting of a 6,000-liter water tank and a 2,000-liter foam tank. This configuration enables firefighters to effectively combat both ordinary combustible fires and flammable liquid fires. The tank body is engineered for durability and balanced weight distribution, ensuring safe driving and operational efficiency.
A powerful fire pump rated at 60 liters per second at 1.0 MPa provides high-volume water and foam discharge. The monitor can project water over 65 meters and foam over 60 meters, enabling effective long-range firefighting operations.
Additional features include ZF hydraulic power steering, reinforced diaphragm clutch, all-steel radial tires, and a triple braking system with service, parking, and auxiliary exhaust brakes. Altogether, the HOWO 4×4 8000L water foam tanker fire truck is a dependable and versatile solution for modern fire rescue services.
FEATURES
- Reliable 4×4 Off-Road Mobility
Built on the durable Sinotruk HOWO 4×4 chassis, this fire truck delivers excellent traction and maneuverability, making it ideal for urban streets, muddy roads, construction zones, and remote rescue locations. - Large 8,000L Water & Foam Capacity
Equipped with a combined 6,000-liter water tank and 2,000-liter foam tank, the vehicle can efficiently handle both standard fires and flammable liquid emergencies. - Powerful 336HP Engine Performance
Powered by the Sinotruk WD615.69 diesel engine, the truck provides strong output, dependable torque, and a top speed of 90 km/h for rapid emergency response. - High-Efficiency Firefighting System
The truck features a 60L/s fire pump and a long-range fire monitor capable of spraying water up to 65 meters and foam up to 60 meters, ensuring effective firefighting coverage. - Enhanced Safety & Driver Comfort
Designed with ZF hydraulic power steering, reinforced clutch, radial tires, and a triple braking system including service, parking, and exhaust brakes for safer and smoother operation.
SPECIFICATION
| Vehicle Main Dimensions | (L x W x H)mm | 8,100X2,496X3,080 | |
| Wheel base(mm) | 4,300 | ||
| Approach/Departure angle(°) | 19/24 | ||
| Weight in KGS | Tare Weight | 12,680 | |
| Loading Capacity | 28,320 | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | Sinotruk | |
| Model | WD615.69 | ||
| Type | 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging, and inter-cooling | ||
| Horse Power(HP) | 336HP | ||
| Emission standard | Euro II | ||
| Gearbox | HW19710, 10 forwards & 2 reverse | ||
| Clutch | Reinforced diaphragm clutch, diameter 430mm | ||
| Steering Gear | ZF 8098, power steering, hydraulic steering with power assistance | ||
| Tire | 1315/80R22.5 All steel radial tire, 11 pieces including one spare tire | ||
| Brakes | Service brake: Dual circuit compressed air brake Parking brake: (Emergency brake): Spring energy, compressed air operating on rear wheels Auxiliary brake: Engine exhaust valve brake |
||
| Fire Fighting Tanker Body | |||
| Water Tanker Volume | 6,000L | ||
| Foam Tanker Volume | 2,000L | ||
| Fire Pump Flow | 60L/S/1.0MPa | ||
| Fire Pump Distance | Water | >65m | |
| Foam | >60m | ||
