BRIEF
The HOWO 6×6 15000L fire truck water tank produced by CSCTRUCK Fire Rescue Truck is a heavy-duty, high-capacity firefighting vehicle designed for demanding emergency response operations in urban, industrial, rural, and off-road environments. Built on the reliable SINOTRUK HOWO ZZ1250 chassis, this fire truck combines strong mobility, rugged construction, and excellent water-carrying capacity, making it ideal for municipal fire brigades, mining sites, airports, factories, and large-scale fire protection tasks.
Powered by the proven Weichai WP10.340.E32 diesel engine, the HOWO 6×6 15000L fire truck water tank delivers 250 kW of power with a displacement of 9,726 ml, ensuring dependable performance even under heavy loads and difficult terrain conditions. Its 6×6 all-wheel-drive configuration provides superior traction and stability on muddy roads, mountainous regions, construction zones, and disaster areas where ordinary fire engines may struggle. With a top speed of 95 km/h, it can respond quickly to emergencies while carrying a full 15,000-liter water load.
The HOWO 6×6 15000L fire truck water tank has a gross vehicle weight of 25,000 kg, a curb weight of 9,500 kg, and a payload capacity of 15,000 kg. Measuring 11,000 × 2,500 × 3,550 mm with a wheelbase of 4,350 + 1,350 mm, it offers a balanced combination of maneuverability and stability. The tank is manufactured from durable Q235 carbon steel with 5 mm thickness, featuring internal anti-surge baffles and advanced anti-corrosion treatment for long service life. Stainless steel construction is also available as an option.
For firefighting performance, it is equipped with the CB20.10/30.60 medium and low-pressure fire pump, capable of delivering 60 L/s at 1.0 MPa and 30 L/s at 2.0 MPa. The roof-mounted fire monitor provides an effective water range of over 70 meters, allowing operators to tackle fires from a safe distance. Spacious pump rooms, aluminum alloy roller shutters, and practical equipment compartments further enhance efficiency and readiness during emergency operations.
FEATURES
- High-Capacity 15,000L Water Tank
Equipped with a large 15,000-liter water tank, this HOWO 6×6 fire truck provides extended firefighting endurance, reducing refill frequency and improving efficiency during large-scale fire emergencies. - Powerful 6×6 Off-Road Performance
Built on the robust SINOTRUK HOWO ZZ1250 chassis with a 6×6 all-wheel-drive system, it offers excellent traction and stability on rough roads, muddy terrain, mountainous areas, and disaster zones. - Reliable Weichai Diesel Engine
Powered by the proven Weichai WP10.340.E32 engine, the truck delivers 250 kW of power, ensuring strong acceleration, dependable hauling ability, and consistent performance under heavy loads. - Efficient Firefighting System
Fitted with the CB20.10/30.60 medium and low-pressure fire pump, it delivers up to 60 L/s water flow, while the roof-mounted fire monitor reaches over 70 meters for safe and effective fire suppression. - Durable and Practical Design
The tank is constructed from corrosion-resistant Q235 carbon steel with anti-surge baffles for safer transport. Spacious equipment compartments, pump rooms, and aluminum alloy roller shutters improve operational readiness and storage convenience.
SPECIFICATION
| Total quality | 25,000 (Kg) | Volume of tank | 15CBM |
| Load rating | 15,000 (kg) | Overall dimension mm | 11,000X2,500X3,550 |
| Curb weight | 9,500(kg) | Number of bridges | 2+4 |
| Number of shafts | 3 | Wheelbase (mm) | 4,350+1,350 |
| Axle weight (Kg) | 7,500/16,000 | Top speed | 95(Km/h) |
[Chassis technical parameters] |
|||
| Chassis models | ZZ1250 | ||
| Fuel type | Diesel | Tire size | 12.00 |
| Emission standards | Euro III | ||
| Engine type | Engine manufacturer | Displacement(ml) | Power(Kw) |
| WP10.340.E32 | Weichai engine | 9726 | 250 |
| Bridge instruction | Full metal enclosed cab with flat head, panoramic curved windshield. New front face mask, front bumper, front assembly lamps, car doors, and windows. | ||
| tanks | Q235 quality carbon steel (5mm) material, welded structure, with vertical and horizontal anti-swing plate built in, has been treated with high-tech anti-corrosion. Choose stainless steel material. | ||
| The pump room | Central or rear pump, pump room on the left and right side, equipment box on the left side of the new, easy-to-pull high-strength aluminum alloy shutter door. | ||
| Equipment boxes | With the introduction of European technology to produce aluminum alloy profiles for the hidden tower technology manufacturing, the whole socket structure was changed. | ||
| Volume of tank | 4.0m3; Tank size (length x width x height): 2,190 x 1,900 x 1,000(mm); | ||
| Gun range | Water 70 m or more | ||
| Fire pump model | CB20.10/30.60 medium and low-pressure vehicle fire pump | ||
| Rated flow/pressure | 60L/[email protected], 30L/[email protected] | ||
