Hytrans Fire System 1400

BRIEF



The Hytrans Fire System 1400 is a highly capable mobile pumping solution designed for demanding emergency response and water transfer operations. It is powered by a robust marine diesel engine and utilizes an advanced heat exchanger cooling system. By eliminating the need for a traditional radiator and cooling fan, this design reduces overall noise levels during operation while also saving valuable space within the containerized unit. This compact and efficient configuration makes it particularly suitable for deployment in environments where space and noise control are critical considerations. However, it is important to note that the system is not available in regions with strict emissions regulations due to its engine specifications.

The Hytrans Fire System 1400 is equipped with three portable, hydraulically driven submersible pumps that work in coordination with a main boost pump installed within the container housing. This combination ensures efficient water intake and high-capacity pumping performance, even in challenging conditions such as low water levels or difficult terrain. The entire unit is designed for mobility and ease of transport, typically mounted on a truck fitted with a hook arm lift system, allowing for quick deployment and retrieval.

The Hytrans Fire System 1400 is versatile and can be used across a wide range of applications. These include large-scale firefighting operations, industrial fire protection, and wildfire suppression. In addition, it is highly effective for flood control, dewatering tasks, and providing emergency or backup water supply. Its adaptability and high-performance capabilities make it a valuable asset for emergency services, industrial facilities, and disaster response teams requiring reliable, large-volume water movement.



FEATURES



1. High-Performance Marine Diesel Engine
   The system is powered by a robust marine diesel engine, delivering reliable and consistent performance for demanding firefighting and large-volume water transfer operations.
2. Advanced Heat Exchanger Cooling System
   It utilizes a heat exchanger instead of a traditional radiator and cooling fan, significantly reducing operational noise while also saving internal space within the containerized unit.
3. Integrated Multi-Pump Configuration
   Equipped with three portable, hydraulically driven submersible pumps working in tandem with a main boost pump, the system ensures efficient water intake and high-capacity pumping even in challenging conditions.
4. Mobile and Rapid Deployment Design
   The unit is containerized and typically mounted on a truck with a hook arm lift system, enabling quick transportation, easy deployment, and fast retrieval in emergencies.
5. Versatile Multi-Application Capability
   Suitable for a wide range of uses, including large-scale firefighting, industrial fire protection, wildfire suppression, flood control, dewatering, and emergency water supply operations.



SPECIFICATION



Foam injection

An integrated Hytrans PowerFoam system is available, allowing foam premixing up to 1-3% or at 6% at reduced capacity. The electronically controlled, hydraulically driven foam pump provides accuracy and a stepless choice of foam percentage.

Accessibility

The 60-meter hydraulic hose length ensures access to almost all open waters, with a combined distance of up to 60 meters and/or 10-15 meters vertically.

Capacity

• At 10 meters or 32 ft pump lift: 45.000 lpm at 12 bar (11,885 GPM at 175 psi)

Control instruments

• Hytrans control system
• Vital parameters are monitored and logged (e.g., oil pressure, oil temperature, fuel level, motor temperature, etc.)
• Audible and visible alarms are generated when a parameter falls outside its setting
• Machine status light, surround illumination, and working light
• Automatic water pressure regulation (option)
