BRIEF
The ISUZU FVR 6-ton water foam tanker fire truck produced by CSCTRUCK Fire Rescue Truck is a high-performance firefighting vehicle designed for urban firefighting, industrial facilities, petrochemical zones, warehouses, and highway emergency response. Built on the reliable ISUZU QL1180EQFRY chassis by Qingling Motors, it combines strong power, excellent stability, and professional fire suppression capability.
Power is provided by the proven ISUZU 6HK1-TCG61 diesel engine, delivering 177 kW of output with a large 7.79-liter displacement, ensuring rapid acceleration and dependable performance even under full load. Paired with a FAST 8-speed manual transmission and a 4×2 drive configuration, the vehicle achieves a maximum speed of 95 km/h, allowing for a quick response to emergency scenes. The 5,550 mm wheelbase and 295/80R22.5 16PR tires provide solid load-carrying capacity and driving stability.
The fire truck is equipped with a 6-ton total tank capacity, consisting of 4 tons of water and 2 tons of foam, suitable for suppressing both conventional fires and flammable liquid fires. The tank body is manufactured from high-quality Q235 carbon steel, featuring internal anti-sloshing baffles and epoxy anti-corrosion treatment. The foam tank, on the other hand, is made of 304 stainless steel for enhanced durability and chemical resistance.
Its firefighting system features a Shanghai CB10/40 fire pump and a WEST PS8/30 fire monitor with a spraying range of ≥60 meters, ensuring efficient water and foam delivery. A full-power, water-cooled PTO guarantees stable pump operation.
The vehicle adopts an original four-door double-row ISUZU cab, offering comfortable seating for the crew. Well-organized equipment compartments with aluminum alloy roller shutter doors, European-style equipment racks, and a comprehensive warning and lighting system further enhance operational efficiency and safety. Overall, this fire truck delivers reliability, efficiency, and professional performance for modern firefighting needs.
FEATURES
- Powerful ISUZU Engine & Reliable Drivetrain
Powered by the ISUZU 6HK1-TCG61 diesel engine with 177 kW output and 7.79 L displacement, the truck delivers strong torque, rapid acceleration, and reliable performance under full load. The FAST 8-speed manual gearbox and 4×2 drive ensure smooth power transmission and efficient highway response. - Large-Capacity Dual Firefighting Tanks
Equipped with a total 6-ton tank capacity (4 tons water + 2 tons foam), the vehicle is well-suited for both conventional fires and flammable liquid fires. The Q235 carbon steel water tank with anti-corrosion treatment and the 304 stainless steel foam tank ensure long service life and operational reliability. - High-Efficiency Firefighting System
The Shanghai CB10/40 fire pump combined with the WEST PS8/30 fire monitor delivers powerful and stable water or foam discharge, with a spraying range of ≥60 meters. The full-power water-cooled PTO ensures consistent pump performance during continuous firefighting operations. - Stable Chassis & Excellent Mobility
Built on the ISUZU QL1180EQFRY chassis with a 5,550 mm wheelbase and 295/80R22.5 16PR tires, the fire truck offers excellent load-carrying capacity, driving stability, and maneuverability in urban streets, industrial zones, and highway environments. - Crew-Oriented Design & Operational Safety
The four-door double-row ISUZU cab provides comfortable seating for the firefighting crew. Aluminum alloy roller-shutter compartments, European-style equipment racks, and a complete warning and lighting system improve equipment access, on-scene efficiency, and operational safety.
SPECIFICATION
1. Chassis Parameters
| Item | Specification |
|---|---|
| Chassis Model | QL1180EQFRY |
| Chassis Manufacturer | Qingling Motors Co., Ltd. |
| Engine Model | 6HK1-TCG61 |
| Engine Power | 177 kW |
| Engine Displacement | 7,790 ml |
| Maximum Speed | 95 km/h |
| Tire Size | 295/80R22.5 16PR |
| Number of Tires | 6 + 1 |
| Drive Type | 4×2 |
| Transmission | Manual 8-speed (FAST 8-speed gearbox) |
| Wheelbase | 5,550 mm |
| Tank Capacity | 4 tons water + 2 tons foam |
2. Firefighting System Parameters
| Item | Specification |
|---|---|
| Fire Pump Model | Shanghai CB10/40 |
| Fire Monitor Model | WEST PS8/30 |
| Fire Monitor Range | ≥ 60m |
| Power Take-Off (PTO) | Full-power PTO, water-cooled |
3. Overall Vehicle Configuration
| Item | Description |
|---|---|
| Cab | Four-door flat-head all-metal enclosed cab, original factory double-row cab, panoramic curved windshield, front bumper, combined front lamps, electric windows, and lower front panel |
| Tank Body | Made of high-quality carbon steel (Q235), welded structure with longitudinal and transverse anti-sloshing baffles, epoxy anti-corrosion treatment; foam tank standard with 304 stainless steel, water tank optional 304 stainless steel |
| Equipment Compartments | Fire pump located centrally or rear-mounted; four water outlets on both sides of the pump room; equipment compartments on both sides and rear fitted with new-style easy-lift high-strength aluminum alloy roller shutter doors |
| Equipment Racks | Aluminum alloy profiles manufactured using European technology, concealed tower-type structure, full internal hexagonal connections, durable, and aesthetically pleasing |
| Electrical System | 100W long-row siren and warning light mounted on the front of the cab roof; one 24V/60W rear fire scene light; red and blue strobe lights on the upper sides of the vehicle; safety marker lights on the lower sides; interior lighting in the crew cab, equipment compartments, and pump room; rotary control switches and pre-installed communication equipment interfaces. |
