BRIEF
The SHACMAN F3000 15 CBM mobile foam concentrate supply vehicle, produced by CSCTRUCK Fire Rescue Truck, is a high-capacity, purpose-built firefighting support unit designed for efficient foam concentrate transport and rapid deployment in emergencies. Built on the robust SHACMAN F3000 chassis, the vehicle features a 4-point hydraulic suspension cab that enhances driver comfort and stability, even in demanding operational environments. The cab is equipped with modern conveniences such as automatic air conditioning, power windows, central locking, and a hydraulically adjustable main seat.
Powered by a reliable Weichai WP10.380E22 diesel engine, the vehicle delivers 380 horsepower (280 kW) and strong torque output, ensuring dependable performance during long-distance transport and intensive firefighting support operations. The 6-cylinder, in-line, turbocharged engine, combined with a FAST 10-speed manual transmission, provides excellent drivability and fuel efficiency. With a wheelbase of 4,575 + 1,400 mm and heavy-duty axles (7.5T front and 16T dual rear), the truck offers outstanding load-bearing capacity and road stability.
The SHACMAN F3000 15 CBM mobile foam concentrate supply vehicle is equipped with a 15 cubic meter foam concentrate tank, making it ideal for large-scale firefighting scenarios, including industrial fires, petrochemical facilities, and airport operations. Its integrated CB10/60 fire pump, with a rated flow of 60 L/s and 1.0 MPa pressure, ensures reliable water and foam delivery. The PS50 fire monitor provides a flow rate of 50 L/s and a jet range of at least 65 meters, enabling effective long-distance firefighting.
Additional features include a comprehensive fire equipment package, an air brake system with exhaust braking, a 24V electrical system, and customizable configurations such as foam or dry powder systems. With flexible right- or left-hand drive options and a durable export-standard build, this SHACMAN F3000 15 CBM mobile foam concentrate supply vehicle is a versatile and dependable solution for modern fire rescue operations.
FEATURES
- Robust SHACMAN F3000 Heavy-Duty Chassis
Built on the durable SHACMAN F3000 platform, the vehicle features a 4-point hydraulic suspension cab that enhances driving comfort, stability, and vibration reduction during demanding emergency operations. - Powerful Engine with Strong Drivetrain Performance
Equipped with a 380 HP turbocharged diesel engine paired with a FAST 10-speed manual transmission, it delivers high torque output, excellent fuel efficiency, and reliable performance for long-distance and heavy-load missions. - Large-Capacity 15 CBM Foam Concentrate Tank
The 15 cubic meter foam tank provides substantial foam storage capacity, making it highly suitable for large-scale fire incidents such as petrochemical plants, industrial zones, and airport fire emergencies. - High-Performance Fire Suppression System
Integrated with a CB10/60 fire pump (60 L/s flow rate) and a PS50 fire monitor with a jet range of at least 65 meters, ensuring strong and stable foam-water discharge for effective long-range firefighting. - Heavy-Duty Configuration and Operational Versatility
Designed with 7.5T front and 16T rear axles, an air brake system with exhaust braking, and customizable configurations, it is a versatile emergency support unit manufactured by CSCTRUCK Fire Rescue Truck for reliable global fire rescue deployment.
SPECIFICATION
| Model Name | SHACMAN F3000 15 CBM Mobile Foam Concentrate Supply Vehicle | ||
| Cab | SHACMAN F3000 4-point hydraulic suspension cab, electric automatic constant temperature air conditioner, power window, ordinary air filter, central lock, hydraulic major seat, tilt, metal bumper. | ||
| Engine(HP) | 380 | ||
| Power(kW) | 280 | ||
| Wheelbase(mm) | 4,575+1,400 | ||
| Front/Rear Suspension(mm) | 1,525/2,560 | ||
| Steering | Power steering | ||
| Approach/departure angle | 16/10 | ||
| Wheels & tire | 12.00R20 | ||
| Tire number | 10+1 | ||
| Tank Dimensions(mm) | |||
| Cubage(m3) | 15 | ||
| RHD or LHD | Optional | ||
| Overall Dimensions(mm)(LxWxH) | 10,060×2,550×3,650 | ||
| Curb weight (Kg) | 14,550 | ||
| Engine | Model | WP10.380E22 | |
| Horsepower(HP) | 380 | ||
| Maximum output(kW) | 280 | ||
| Maximum torque(N.m) | |||
| Type | 6 cylinders, in-line,4-stroke, turbo inter-cooling, diesel engine | ||
| Displacement | 9.726L | ||
| Weichai brand, Euro 2 | |||
| Driving passenger | 2+4 | ||
| Transmission | FAST 10 speed forward and 2 reverse, manual | ||
| Front Axle | 7.5T | ||
| Rear Axle | 16Tx2 | ||
| Brake System | Air brake, exhaust brake | ||
| Color and LOGO | Customized | ||
| Electric system | 24V | ||
| Fire equipment part | Fire pump | CB10/60, rated pressure 1.0MPa, flow60L/s | |
| Fire gun | PS50, flow 50L/s, jet distance≥65m | ||
| Standard configuration | National standard equipment box, with national standard fire-fighting equipment, fire pump, fire gun, fire power take off, sliding gate, row type lights, reel, common tools, rear climbing ladder, water tank. | ||
| Optional configuration | Foam type, dry powder type, and other requirements. | ||
| Delivery date | Within 40 days after receipt advance | ||
| Packing | Nude Pack. The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, and be suitable for long-distance transportation by ocean and land. The Seller shall take measures against moisture, shocks, and rust according to the special needs of the commodity. | ||
