BRIEF
The 4×4 off-road 5CBM water tank fire engine (Model No. CSCWTFE005) produced by CSCTRUCK Fire Rescue Truck is a powerful, versatile firefighting vehicle designed for off-road conditions and emergencies in rugged environments. Built on the Dongfeng double-row chassis, it can carry up to 6 passengers (3+3), providing ample space for a firefighting team and equipment. The engine is a Yuchai YCS04180-68 diesel engine, producing 180 horsepower (132 kW) with a maximum torque output, offering reliability and power in challenging conditions. Its 4.156L, 4-cylinder, in-line engine is Euro 6 compliant, making it both powerful and environmentally responsible.
This fire engine is designed for demanding operations with robust specifications. It features a wheelbase of 4,200 mm, a front/rear suspension of 1,300/1,730 mm, and a 9.0R20 tire configuration, providing excellent off-road capabilities. The truck’s overall dimensions are 7,230 mm (L) × 2,360 mm (W) × 3,300 mm (H), and it has a curb weight of 8,180 kg. The fire engine is equipped with an air brake system and a fire pump (CB10/40) with a rated pressure of 1.0MPa and a flow of 40L/s, along with a fire gun (PS40) capable of spraying up to 60 meters. The 5,000-liter water tank ensures sustained firefighting capability in the field.
For additional versatility, the tanker fire engine offers optional configurations such as foam or dry powder tanks, a stainless steel water tank, and other customizations. The vehicle also includes a national standard fire equipment box, a sliding gate, row-type lights, a rear climbing ladder, and various firefighting tools, ensuring readiness for emergencies in diverse scenarios. The system is powered by a 24V electrical setup and features an 8-speed manual transmission for precise control.
FEATURES
- Off-Road Capability: Built on a Dongfeng double-row chassis with a robust 4×4 traction type, this fire engine is specifically designed to perform in rugged, off-road conditions, making it ideal for firefighting in challenging environments.
- Powerful Engine and Performance: Equipped with a Yuchai YCS04180-68 diesel engine producing 180 horsepower (132 kW), this fire engine offers high torque and reliability for demanding operations. The engine is also Euro 6 compliant, making it both powerful and environmentally friendly.
- Firefighting Efficiency: The truck features a CB10/40 fire pump with a rated pressure of 1.0 MPa and a flow rate of 40L/s, alongside a PS40 fire gun that can spray water up to 60 meters, ensuring effective firefighting capabilities in the field.
- Customizable Tank Options: The 5,000-liter water tank can be customized with options like foam or dry powder tanks and a stainless steel water tank, providing flexibility to meet different firefighting needs.
- Complete Emergency Readiness: This fire engine is equipped with essential firefighting tools, including a national standard fire equipment box, row-type lights, a rear climbing ladder, and other accessories. It also has a 24V electrical system, an 8-speed manual transmission, and ample space for a 6-person firefighting team.
SPECIFICATION
| Model No.: | CSCWTFE005 | ||
| Cab | Dongfeng double row, allowable 3+3 passengers | ||
| Engine(Hp) | 180 | ||
| Power(kW) | 132 | ||
| Wheelbase(mm) | 4,200 | ||
| Front/Rear Suspension(mm) | 1,300/1,730 | ||
| Steering | Power steering | ||
| Approach/departure angle | 18/16 | ||
| Wheels & tire | 9.0R20 | ||
| Tire number | 6+1 | ||
| Tank Dimensions(mm) | |||
| Water Tank Capacity(m3) | 5 | ||
| RHD or LHD | Optional | ||
| Overall Dimensions(mm)(LxWxH) | 7,230×2,360×3,300 | ||
| Curb weight (kg) | 8,180 | ||
| Engine | Model | YCS04180-68 | |
| Horsepower | 180 | ||
| Maximum output(kW) | 132 | ||
| Maximum torque(N·m) | |||
| Type | 4 cylinders, in-line,4-stroke, diesel engine | ||
| Displacement | 4.156L | ||
| Yuchai brand, Euro 6 | |||
| Driving passenger | 3+3 | ||
| Transmission | 8 speeds forward and one reverse, manual | ||
| Front Axle | 4.5T | ||
| Rear Axle | 8T | ||
| Brake System | Air brake, exhaust brake | ||
| Color and LOGO | Customized | ||
| Electric system | 24V | ||
| Fire equipment part | Fire pump | CB10/40, rated pressure 1.0MPa, flow 40L/s | |
| Fire gun | PS40, flow 40L/s, jet distance ≥60m | ||
| Standard configuration | National standard equipment box, full units national standard fire-fighting equipment, fire pump, fire gun, fire power take off, sliding gate, row type lights, reel, common tools, rear climbing ladder, water tank. | ||
| Optional configuration | Foam type, dry powder type, stainless tank, and other requirements. | ||
