6 CBM Water Foam Tanker Fire Truck

BRIEF

The 6 CBM water foam tanker fire truck, produced by CSCTRUCK Fire Rescue Truck, is a medium-duty firefighting vehicle designed for rapid response in urban, industrial, and rural fire scenarios. Built on the robust Dongfeng EQ1185DJ9CDF cargo truck chassis, this fire truck integrates powerful firefighting capabilities with reliable mobility and safety features. With a gross vehicle weight of 16,000 kg and a rated payload of 6,100 kg, it balances high capacity with maneuverability, achieving a maximum speed of 95 km/h.

The truck features a 6.061 m³ total tank volume, divided into a 4.1 m³ water tank and a 1.961 m³ foam tank, enabling efficient firefighting using both water and foam agents. The vehicle is equipped with a CB10/40 fire pump and a PL32 fire monitor, providing water and foam spray ranges of ≥55 m and ≥50 m, respectively, ensuring effective fire suppression even at a distance. The chassis supports a 6-tire configuration, a 4,700 mm wheelbase, and leaf springs (8 front, 10+7 rear) for durability and stability on varied terrain.

Safety and operational features include ABS/ASR braking (4S/4M, 24V), integrated side protection, and a Q235 steel rear protection frame with bolted connection. The cab accommodates 3 + 3 personnel, and the vehicle offers ground clearance of 402 mm with approach and departure angles of 21° / 11°, enabling moderate off-road performance.

Powered by a 6.2 L Dongfeng Cummins B6.2NS6B230 diesel engine, delivering 169 kW of power, the truck meets EURO VI emission standards. Optional equipment, such as a rear ladder frame, enhances firefighting versatility. Overall, the 6 CBM water foam tanker fire truck provides a reliable, high-capacity, and well-equipped solution for firefighting operations, combining mobility, safety, and effective fire suppression capabilities in one integrated platform.

FEATURES

1. Dual-Agent Firefighting Capability – Equipped with a 6.061m³ tank (4.1 m³ water + 1.961 m³ foam), a CB10/40 fire pump, and a PL32 fire monitor, providing water and foam spray ranges of ≥55m and ≥50m for effective fire suppression.
2. Robust Chassis and Mobility – Built on the Dongfeng EQ1185DJ9CDF cargo truck chassis with a 6-tire configuration, 4,700 mm wheelbase, leaf spring suspension, 402 mm ground clearance, and approach/departure angles of 21°/11°, ensuring stability and moderate off-road performance.
3. Powerful Engine – Powered by a 6.2 L Dongfeng Cummins B6.2NS6B230 diesel engine producing 169 kW, meeting EURO VI emission standards, and enabling a maximum speed of 95 km/h.
4. Safety and Operational Features – Includes ABS/ASR braking (4S/4M, 24V), integrated side protection, a Q235 steel rear protection frame, and cab accommodation for 3 + 3 personnel, ensuring safe operation in various environments.
5. Versatile and High-Capacity Design – With a gross vehicle weight of 16,000 kg and rated payload of 6,100 kg, the truck balances capacity and maneuverability; optional equipment like a rear ladder frame further enhances firefighting versatility.

SPECIFICATION

Remarks:

• An optional rear ladder frame is available
• Total tank volume: 6.061 m³
  • Water tank: 4.100 m³ (1,255 × 2,400 × 1,425 mm)
  • Foam tank: 1.961 m³ (600 × 2,400 × 1,425 mm)
• Integrated side protection structure
• Rear protection material: Q235 steel
  • Section size: 120 × 120 mm
  • Ground clearance: 402 mm
  • Connection: Bolted
• ABS manufacturer: Xiangyang Dongfeng Longcheng Machinery Co., Ltd.
  • Model: ABS/ASR-24V-4S/4M
• Firefighting equipment:
  • CB10/40 fire pump
  • PL32 fire monitor
  • Water range ≥ 55 m
  • Foam range ≥ 50 m

Chassis Technical Specifications
