BRIEF
The 7-ton water foam fire truckproduced by CSCTRUCK Fire Rescue Truck is a medium-duty, multi-purpose firefighting vehicle designed for fast response and efficient fire suppression in urban areas, industrial facilities, warehouses, and logistics parks. Built on the reliable Dongfeng EQ1185DJ9CDF 4×2 chassis, this fire engine offers a balanced combination of maneuverability, power, and operational stability.
Powered by the B6.2NS6B230 diesel engine delivering 169 kW, the vehicle provides strong driving performance with a top speed of 95 km/h, ensuring rapid arrival at emergency scenes. The 9-speed manual transmission and 4,700 mm wheelbase enhance driving comfort and load distribution, while 295/80R22.5 tires ensure dependable road grip and durability under demanding conditions.
The firefighting system features a Shanghai CB10/40 fire pump paired with a WEST PW8/30 fire monitor, capable of projecting water or foam to a distance of ≥60 meters. A full-power, water-cooled PTO guarantees stable pump operation during prolonged firefighting tasks. The tank configuration includes 5 tons of water and 2 tons of foam, enabling flexible response to both conventional fires and flammable liquid incidents.
The tank body is constructed from high-quality Q235 carbon steel with longitudinal and transverse anti-surge baffles and treated with epoxy anti-corrosion coating. The foam tank is standard 304 stainless steel, with an optional stainless-steel water tank for enhanced corrosion resistance and extended service life.
Equipped with a double-row, 4-door enclosed cab, this fire truck ensures crew comfort and safety. Thoughtfully designed equipment compartments with aluminum alloy roller shutter doors, European-technology equipment racks, and a comprehensive warning and lighting system make the 7-ton water foam fire truck a reliable, efficient, and professional solution for modern firefighting operations.
FEATURES
- High-Performance Dongfeng Chassis
Built on the proven Dongfeng EQ1185DJ9CDF 4×2 chassis, the fire truck offers excellent maneuverability, stable load distribution, and reliable performance, making it well suited for urban streets, industrial zones, and logistics parks. - Powerful and Efficient Drivetrain
Equipped with a B6.2NS6B230 diesel engine delivering 169 kW and a 9-speed manual transmission, the vehicle achieves a top speed of 95 km/h, ensuring rapid emergency response while maintaining strong driving comfort and fuel efficiency. - Professional Firefighting Pump & Monitor System
The Shanghai CB10/40 fire pump combined with a WEST PW8/30 fire monitor provides stable, high-flow output with a water or foam jet range of ≥60 meters. The full-power, water-cooled PTO ensures continuous and reliable operation during extended firefighting missions. - Large-Capacity Water and Foam Tanks
Featuring a practical tank layout of 5 tons of water and 2 tons of foam, this fire truck supports both conventional firefighting and flammable liquid fire suppression, offering operational flexibility for diverse emergency scenarios. - Durable Construction and Ergonomic Design
The Q235 carbon steel water tank with anti-surge baffles and epoxy anti-corrosion treatment, paired with a 304 stainless steel foam tank, ensures long service life. The double-row enclosed cab, aluminum roller shutter compartments, and well-organized equipment layout enhance crew safety, efficiency, and ease of operation.
SPECIFICATION
1. Chassis Parameters
| Item | Specification |
|---|---|
| Chassis Model | EQ1185DJ9CDF |
| Chassis Manufacturer | Dongfeng Motor Co., Ltd. |
| Engine Model | B6.2NS6B230 |
| Engine Power | 169 kW |
| Engine Displacement | 6,200 ml |
| Maximum Speed | 95 km/h |
| Tire Size | 295/80R22.5 |
| Number of Tires | 6 + 1 (spare) |
| Drive Type | 4×2 |
| Transmission | 9-speed manual |
| Wheelbase | 4,700 mm |
| Tank Capacity | 5 tons water + 2 tons foam |
2. Firefighting Monitor & Pump System Parameters
| Item | Specification |
|---|---|
| Fire Pump Model | Shanghai CB10/40 |
| Fire Monitor Model | WEST PW8/30 |
| Fire Monitor Range | ≥ 60 meters |
| Power Take-Off (PTO) | Full-power PTO, water-cooled |
3. Overall Vehicle Configuration
| Item | Description |
|---|---|
| Cab | Original factory double-row, four-door flat-head all-metal enclosed cab; panoramic curved windshield; front bumper; combined front lamps; electric windows; lower front panel |
| Tank Body | Made of high-quality carbon steel (Q235), welded structure with longitudinal and transverse anti-surge baffles; epoxy anti-corrosion treatment. Foam tank standard with 304 stainless steel; water tank optionally available in 304 stainless steel |
| Equipment Compartments | Fire pump mounted centrally or rear; four water outlets on both sides of the pump room; equipment compartments on both sides and rear equipped with new pull-up high-strength aluminum alloy roller shutter doors |
| Equipment Racks | Aluminum alloy profiles manufactured using European technology; concealed ladder-type structure; full internal hex-bolt connections; durable and aesthetically pleasing |
| Electrical System | 100W long-row siren and warning light mounted on the front roof of the cab; one 24V/60W rear fire scene light; red-and-blue strobe lights on both upper sides; safety marker lights on lower sides; interior lighting installed in crew cabin, equipment compartments, and pump room; rotary control switches and reserved communication equipment interfaces. |
