BRIEF
The IVECO 3000 liters small water tender fire truck, produced by CSCTRUCK Fire Rescue Truck, is a versatile and efficient vehicle designed for rapid fire response. It features an IVECO chassis, ensuring reliable performance and durability in various firefighting situations. The truck is equipped with a 4×2 drive type and is capable of carrying a total load of 12,000 kilograms. It can reach a maximum driving speed of 90 km/h, allowing for swift deployment to emergency scenes.
Powering the truck is a robust 205kW engine, providing the necessary force for both driving and pumping operations. The water tank, made of durable PP composite material, has a capacity of 3,000 liters, ensuring ample water supply for firefighting activities.
The tanker fire truck is fitted with a high-performance water pump capable of delivering a 30 liters per second flow rate at 1 MPa pressure. Additionally, it has a water absorption depth of 7 meters, enabling it to draw water from deep sources. The roof-mounted fire monitor has a flow rate of 30 liters per second at 10 bar, with a water shooting range of 55 meters or more, providing excellent reach for tackling fires in hard-to-access areas.
Overall, the IVECO 3000 liters small water tender fire truck combines speed, power, and advanced firefighting capabilities, making it a reliable choice for small to medium-sized fire emergencies.
FEATURES
1. Water Tank Capacity: 3000 liters, made from PP(polypropylene) composite material for durability and lightweight performance.
2. Performance and Engine Power: Powered by a 205kW engine, with a top speed of 90 km/h, suitable for rapid response during emergencies.
3. Water Pump and Flow Rate: The water pump delivers a flow rate of 30 liters per second at 1 MPa pressure, ensuring effective water discharge for firefighting.
4. Roof Fire Monitor: Equipped with a fire monitor that has a flow rate of 30 L/s at 10 bar and a water shooting range of ≥55 meters, allowing efficient fire suppression from a distance.
5. Chassis and Drive Type: Built on an IVECO chassis with a 4×2 drive configuration and a rated loading capacity of 12,000 kg, offering a balance between maneuverability and load-carrying capability.
SPECIFICATION
Vehicle Parameters
1 Overall Dimensions(LxWxH): 6,900×2,300×3,700mm
2 The total mass of full load: 12,000kg
3 Number of crew: 5
4 Maximum speed: 90km/h
5 Emission Standard: National V
6 Liquid tank capacity: 3,000L of water
7 Fire pump flow: 30L/s
8 Fire monitor flow: 30L/s
Water Pump, Fire Monitor, Water Tank
| 1 | Water Pump | |
| 1.1 | Brand | Optional |
| 1.2 | Model | Optional |
| 1.3 | Rated Flow Rate | 30L/s @ 1Mpa |
| 1.4 | Vacuum Pump | Electric |
| 1.5 | Priming Manner | Automatic |
| 1.6 | Suction Height | 7m |
| 1.7 | Priming Time | ≤30s |
| 1.8 | Location | Rear-mounted |
| 2 | Roof Fire Monitor | |
| 2.1 | Brand | Optional |
| 2.2 | Model | Optional |
| 2.2 | Flow Rate | 30L/s at 10bar |
| 2.3 | Shoot Range | Water ≥ 55m |
| 2.4 | Location | On top of the tank |
| 2.5 | Control Manner | Manual |
| 2.6 | Horizontal Rotation Angle | 0°~360° |
| 2.7 | Pitch Rotation Angle | -15°~60° |
| 3.3 | Liquid Tank | |
| 3.3.1 | Capacity | 3,000L Water |
| 3.3.2 | Material | PP composite material and Never Rust |
| 3.3.3 | Structure | Two Tank Manholes; One Overflow Device/Pressure Relief Device; 2 Liquid Level Indicators; 1 Foam tank Drain Outlet with Valves; One Water tank Drain Outlet with Valves. |
| 3.4 | Fire Fighting Control System | |
| 3.4.1 | Structure | Each fire extinguishing system is controlled by a PLC, and different standardized control modules can be selected. IP56 protection level |
| 3.4.2 | Location | Rear pump room |
