MAN 10 Wheelers 8000L Aircraft Fire Truck

BRIEF

The MAN 10 wheelers 8000L aircraft fire truck produced by CSCTRUCK Fire Rescue Truck is a high-performance airport rescue and firefighting vehicle engineered for rapid response, high efficiency, and operational reliability in aviation emergency scenarios. Built on a robust 6×4 drive chassis, the truck features an overall dimension of 9,200 × 2,550 × 3,850mm and a gross vehicle weight of 25,000kg, ensuring excellent stability and load-bearing capacity during high-speed deployment and firefighting operations.

Powered by the MAN D2066LF06 diesel engine, the vehicle delivers a strong output of 294 kW (400 HP), enabling a maximum speed of up to 90 km/h. This ensures quick arrival at incident sites within airport environments. The 3,900 + 1,350 mm wheelbase configuration enhances maneuverability and balance, while the 315/80R22.5 tires provide durability and traction on various terrains. The cabin accommodates up to 6 personnel (1+1+4), supporting coordinated firefighting operations.

The truck is equipped with a built-in 6,000-liter water tank and a 2,000-liter foam tank, allowing it to effectively combat both conventional and fuel-based fires. Its CB20.10/30.60 fire pump, mounted at the rear, delivers a rated flow of 60 L/s at 1.0 MPa and 30 L/s at 2.0 MPa, supported by a vacuum pump for rapid priming. The fire system includes 6 water outlets and precision monitoring instruments for pressure and vacuum control.

Additionally, the PL48-64YZ water and foam monitor provides an adjustable flow rate of 48–64 L/s, with a range of up to 60 meters for water and 55 meters for foam. Featuring a full 360° rotation and elevation angles from -30° to +70°, the monitor ensures comprehensive coverage. With a reliable PTO system and optimized approach/departure angles, this aircraft fire truck is a dependable solution for modern airport firefighting needs.

FEATURES

1. Powerful Engine & High-Speed Response
   Equipped with the MAN D2066LF06 diesel engine delivering 294 kW (400 HP), the truck achieves a top speed of 90 km/h, ensuring rapid deployment to emergency sites within airport environments.
2. Large-Capacity Fire Suppression System
   The vehicle features a combined 8,000L capacity (6,000L water + 2,000L foam), enabling effective handling of both standard and fuel-based aviation fires.
3. High-Performance Fire Pump System
   Fitted with a CB20.10/30.60 fire pump, it delivers a strong output of 60 L/s at 1.0 MPa and 30 L/s at 2.0 MPa, supported by a vacuum system for fast and reliable priming.
4. Advanced Fire Monitor with Wide Coverage
   The PL48-64YZ water foam monitor offers adjustable flow (48–64 L/s), 360° rotation, and long-range performance up to 60 meters (water), ensuring comprehensive firefighting coverage.
5. Stable 6×4 Chassis with Optimized Mobility
   Built on a durable 6×4 drive chassis with a 25,000 kg GVW and optimized wheelbase (3,900 + 1,350 mm), the truck provides excellent stability, maneuverability, and traction across airport terrains.

SPECIFICATION
