Unimog U4023 4×4 Brush Fire Truck​

BRIEF

The Unimog U4023 4×4 brush fire truck, produced by CSCTRUCK Fire Rescue Truck, is a high-mobility, off-road firefighting vehicle designed specifically for tackling wildland and brush fires in rugged environments. Built on the robust Unimog U4023 chassis, this vehicle delivers exceptional versatility and reliability, ensuring firefighters can access and operate effectively in remote or uneven terrains where standard fire trucks cannot reach.

Equipped with a 1,800-liter water tank and a 200-liter foam tank, the rescue fire truck provides sufficient firefighting capacity for rapid attack and prolonged operations. Its high-performance fire pump delivers a flow rate of 50 liters per second at 10 bar, ensuring strong water pressure for both direct fire suppression and long-distance hose operations. With a suction height of up to 7 meters, the pump can draw water from natural sources such as rivers or ponds, allowing flexible operations in areas without hydrant systems.

Powered by the OM 934 LA engine, generating 170 kW of engine power, and supported by a 4×4 drive system, the Unimog U4023 maintains outstanding traction and performance across steep, muddy, or sandy terrain. It achieves a maximum speed of 90 km/h, ensuring swift deployment to emergency sites. Additionally, the truck is fitted with a 6,129 kg-capacity winch, which enhances recovery and rescue capabilities in challenging environments.

The Unimog U4023 brush fire truck combines durability, agility, and advanced firefighting technology into one powerful unit. Its compact yet rugged design, superior off-road handling, and reliable fire suppression system make it ideal for forest services, rural communities, and emergency response teams operating in difficult terrain conditions. This vehicle exemplifies CSCTRUCK Fire Rescue Truck’s commitment to providing efficient, adaptable, and high-performance firefighting solutions for diverse operational needs.

FEATURES

1. High Off-Road Capability:
   Built on the robust Unimog U4023 4×4 chassis, this fire truck delivers exceptional off-road performance, making it ideal for wildfire and rough-terrain firefighting operations.
2. Powerful Engine Performance:
   Equipped with the OM 934 LA engine producing 170 kW of power, it ensures strong traction and consistent performance even under heavy load or extreme conditions.
3. Efficient Firefighting System:
   Features a 50L/s @ 10 bar fire pump with a 7-meter suction height, enabling rapid water and foam delivery for effective fire suppression in remote areas.
4. Dual Tank Configuration:
   Carries a 1,800-liter water tank and a 200-liter foam tank, providing balanced firefighting resources for both water-based and foam-based extinguishing operations.
5. Enhanced Utility and Safety:
   Integrated with a 6,129 kg traction winch, it assists in vehicle recovery or debris removal during emergency operations, while maintaining a maximum speed of 90 km/h for quick response to fire scenes.

SPECIFICATION

1. The Whole Fire Truck

2. Chassis of the Special Fire Truck

3.


   Superstructure
