BRIEF
The VOLVO 50m water tower fire truck, the latest innovation from CSCTRUCK FIRE RESCUE, integrates cutting-edge elements from both domestic and international fire truck designs, coupled with innovative features honed through real-world firefighting experience. This 3rd-generation vehicle boasts remarkable performance, operating with agility and effectiveness. Elevating firefighting capabilities to new heights, it offers a maximum working height of 50 meters, an outreach extending up to 44 meters, and a remarkable working depth of -32 meters.
Equipped with a powerful water pump capable of delivering 9,000 liters per minute at 1.03 MPa, the VOLVO 50m water tower fire truck ensures rapid and substantial water deployment when combating fires. Additionally, it accommodates a substantial agent capacity of 4 tons, further enhancing its firefighting prowess. With a firefighting radius extending up to 125 meters, this formidable vehicle proves invaluable in tackling fires across diverse environments, including but not limited to petroleum facilities, petrochemical plants, urban areas, and warehouses.
The vehicle’s design embodies a fusion of innovative engineering and practical firefighting expertise, resulting in swift and efficient operations. Its impressive specifications make it a versatile and indispensable asset in firefighting scenarios where large-scale and high-reaching capabilities are essential. Whether addressing industrial infernos or urban conflagrations, the VOLVO 50m water tower fire truck stands ready as a reliable and potent ally in the ongoing battle against fires, ensuring enhanced safety and protection for communities and critical infrastructures alike.
FEATURES
1. With its elevated operational height and broad outreach, the VOLVO 50m water tower fire truck facilitates firefighting across expansive areas.
2. Boasting a sophisticated intelligent vehicle control system, it manages boom deployment and retraction, outrigger extension, and leveling effortlessly, and offers intelligent wired and wireless control functionalities.
3. Housing an effective Class B foam system, the vehicle incorporates an integrated control panel known for its high flow capacity, minimal pressure loss, user-friendly operation, and exceptional firefighting efficacy.
4. With 18 comprehensive safety measures in place, the vehicle prioritizes reliability and safety at all times.
5. The boom is constructed with high-strength steel and follows an RZ-type framework, showcasing a sleek and cohesive design that swiftly unfolds.
SPECIFICATION
Operating Performance Spec. |
||
| Brand | VOLVO | |
| Model | FM540 8 4R B 8×4 | |
| Fire pump | USA Hale CB10/170-8FC | |
| Fire monitor | USA Akron PLKD10/80B-5177(Made in Germany) | |
| Foam system | Hale Smart ATP 125 Auto foam proportioner | |
| Agent capacity | Water of 2,430kg, foam of 1,430kg | |
| Boom structure | 6 sections articulating boom | |
| Outrigger | X type with auto extending, level, and retraction | |
| Hydraulic system | World-class variable pump+ Proportional valve load sensory system | |
| Control system | CAN bus-based intelligent control | |
| Waterway system | Larger flow rate, lower pressure loss aluminum alloy and stainless steel all-hard pipe system, aluminum alloy telescopic pipe | |
| Bodywork | Light corrosion-resistant、Anodized all aluminum alloy corrosion-resistant body frame+ aluminum sheet cover. | |
Main Technical Specification |
||
Overall Dimensions |
||
| LxWxH | 11,970×2,540×3,950mm | |
| Outrigger span(V×H） | 8,885/9,260×9,335mm | |
Operating Performance |
||
| Max Working Height | 50m | |
| Max Working Outreach | 44m | |
| Rated a load of boom | 200kg | |
| Boom operating time | ≤180s | |
| Outrigger leveling time | ≤40s | |
| Max allowed wind speed | ≤12.5(level 6) m/s | |
Driving and Dynamic Performance |
||
| GVW | 41,000kg | |
| Engine net power | 405kw | |
| Cab seat | 2 people | |
| Emission Standard | EURO 6 | |
Firefighting Performance |
||
| Max flow of fire monitor | 9,[email protected] L/min@MPa | |
| Flow at maximum working height | 4,[email protected] L/min@MPa | |
| Max flow of fire monitor | 4,[email protected] L/min@MPa | |
| Water tank capacity | 2,500kg | |
| Foam tank capacity | 1,450kg | |
| Rated spraying reach of fire monitor | ≥74m for water
≥68m for foam |
|
| Max firefighting radius | ≥125m | |
| Fire Monitor Rotation Angle | -30~+30° | |
| Fire Monitor Pitching Angle | -90~+30° | |
Chassis |
||
| Chassis model | Volvo FM540 84R B 8×4 | |
| Engine Model | D13K540 in-line cylinder turbocharger with inter-cooling and electronic control fuel injection | |
| Engine power | Rated power of 406kw, Net power of 405kw | |
| Engine Torque | 2,650Nm/(1,400r/min hour) | |
| Max speed | 185km/h(speed limit control by chassis) | |
| Wheelbase | 1,995+4,205+1,370mm | |
| Emission standard | Euro 6 | |
| Gearbox | Manual | |
| Electric system | Electric generator: 28v/150A
Battery: 2×12V/225Ah |
|
| Fuel system | ≥300L | |
| Braking system | Brake Operation: Compressed air type, independent dual-circuit front and rear axles, disc brakes, with a load-sensitive valve installed on the drive axle, steel air reservoir, air dryer, and brake muffler. Automatic brake adjustment, equipped with anti-lock braking system (ABS)/electronic braking system (EBS)/electronic stability program (ESP)/traction control system (TCS).
Parking Brake: Spring-loaded parking brake applied to the rear axle. Auxiliary Brake: Engine cylinder internal brake retarder (VEB+). |
|
| Tire | Tubeless Radial Tires
Front: 385/65 R22.5 Rear: 315/80 R22.5 Spare: 315/80 R22.5 |
|
Superstructure |
||
Boom |
||
| No of section | 6 sections | |
| Boom material | High strength steel | |
| Boom structure | Articulating boom | |
| End boom working range | The working angle range of the end boom is from 180° to -30°, with the fifth and sixth sections forming a straight line at 0°. The working angle range of the end boom is 210° | |
| Boom operating method | Safety switch + handle step-less control; electronic control forced operation; manual forced operation | |
| Synchronizing of boom and pump | Synchronized, during firefighting, each section of the boom can move independently, and it does not affect the flow. | |
| Turntable | With water, electricity, and a hydraulic integrated central rotary device, any 360-continuous action | |
Outrigger |
||
| Type | X type | |
| Outrigger (VxH) | 8885 (front)/9240 (rear)x 9335 (vertical)mm (tolerance±1%) | |
| Operating control | Auto mode of extending and retraction, electronic control+manual mode, manual override mode | |
Waterway System |
||
| Fire monitor model | Akron PLKD10/80B-5177 (Made in Germany) | |
| Fire pump model | USA Hale CB10/170-8FC | |
| Foam system | Hale Smart ATP 125 Auto Class B foam proportioner | |
| Max flow of fire pump | 9,[email protected] (L/min@MPa) | |
| Flow at maximum working height | 4,[email protected] (L/min@MPa) | |
| Max flow of fire monitor | 4,[email protected] (L/min@MPa) | |
| Control of fire monitor | Electronic control, can achieve horizontal rotation, and pitch and change the shape of the water flow | |
| Water tank capacity | 2,500kg | |
| Foam tank capacity | 1,450kg | |
| Tank material | Stainless steel 304, bottom thickness of 5mm, side thickness of 4mm, top thickness of 3mm | |
| Pressure capacity of boom pipe | ≥2.5MPa | |
| Other pipelines | Aluminum alloy + stainless steel hard pipes | |
Couplings |
||
| Water suction | DN150(Left and right side) | |
| Water inlet | DN80(Left and right side) | |
| Water outlet Or Inlet for the boom | DN80(Left and right side) | |
| Foam inlet | DN50(Left side) | |
Electrical system |
||
| Control system | CAN bus intelligent control system (controller + display screen + control program) | |
|
Console |
Handheld remote control panel
vehicle rear operating console |
|
| Operating mode | Close control: 50 meters wired, equipped with a dedicated cable reel with a 50-meter cable.
Remote control: 150 meters wireless |
|
| Screen | High brightness LCD color display, located in the turntable operation table and cage operating table, Vehicle rear operation panel | |
| Display screen | Industrial-grade display screens are durable, waterproof, and shock-resistant, suitable for harsh operating environments such as high and low temperatures.
A 12-inch high-brightness LCD color display is located on the vehicle’s rear operating console. A 7-inch high-brightness LCD color display is located on the handheld remote control panel. |
|
| Illumination system | The top of the boom is equipped with an LED searchlight.
The boom is configured with high-brightness illumination lights. The storage compartment is equipped with lighting. The outriggers are equipped with warning lights. The outriggers are equipped with lighting for illuminating the supporting area underneath.”
|
|
| Alarm and illumination system | An extended row of warning lights is set on the driver’s cabin roof.
The upper left and right sides of the vehicle body are equipped with rectangular red strobe warning lights. The rear of the vehicle has left and right rectangular red strobe warning lights. The warning lights and sirens are integrated for operation inside the driver’s cabin. The siren has multiple functions, including a firefighting alarm, siren sound, and external announcements, with a power rating of 200 watts. |
|
| Cables and connectors | Applied with imported connector with waterproof standard up to IP67.
Applied with world-class brand cable. |
|
| Automatic disconnect charging device | The vehicle can be charged using 220V mains electricity to recharge the batteries.
The charging plug automatically disconnects when the fire truck is started. |
|
| Reversing assist system | With a reversing alarm buzzer, reversing camera, and cab monitor. | |
| Boom auto operation | Boom operation of extending and retraction can be operated by one key. | |
| Fire site monitor system | Infrared cameras, linked with the monitor head, provide a 48-hour surveillance recording of the fire site. | |
| Outriggers can be deployed and positioned freely (optional) | Arbitrary outrigger support control technology allows the outriggers to be deployed with any span, and the boom extends to the corresponding range for firefighting operations, without being constrained by the site. | |
Security protection system |
||
| Boom buffer protection | Limit position and sudden handle, the system can automatically accelerate and decelerate | |
| Boom limit protection | Based on different positions of the outrigger support, the program automatically restricts the movement of the boom to allow working postures | |
| Boom rotation limit protection | When the boom turns to the position where the outrigger tends to unstable, the system will cut off the turning action in the dangerous direction | |
| Rotation buffer protection | The system can effectively realize buffering when the rotation stops suddenly | |
| Rotation alignment | When the rotation is close to the middle, Automatic speed reduction to ensure accurate center alignment | |
| Body anti-collision | To prevent the boom from colliding with the vehicle body, when the boom turns to a small angle of variation, it will automatically stop the dangerous direction of turning | |
| Interlock | The booms are not allowed to operate when the outriggers are not extended, the outriggers are not allowed to operate when the boom has extended | |
| Emergency function | Both the control valve and outrigger valve on the superstructure are equipped with emergency manual operation; the system is equipped with an emergency power unit which is applied in the condition of retracting the boom and outriggers in case of malfunction for the engine or pump | |
| Outrigger alarm | When the outriggers are in operation, an automatic audio and visual alarm is triggered to prevent accidental contact and ensure safety | |
| Outrigger unstable protection | When the boom is in motion if the outriggers are lifted off the ground, an automatic audio and visual alarm will be activated, and the boom will be only allowed to move within a safe direction | |
| Outrigger retracting position check | The legs are not retracted in the right position; the light will automatically alarm to prevent accidents | |
| Over-pressure protection | When the water monitor inlet pressure exceeds the safe value, an alarm is triggered, and the engine acceleration is restricted. In case of excess pressure in the water circuit, the safety valve overflows | |
| Water tank protection | In addition to setting overflow outlets with a sufficiently large diameter, a tank pressure relief device is installed. This prevents accidental overpressure during tank replenishment | |
| Engine speed limit | During boom operations, the engine speed is automatically restricted. When the water pump is in operation, to prevent water circuit overpressure or pump overspeed, the engine speed is automatically limited | |
| Wind speed warning | When the wind speed exceeds 12.5 m/s, an automatic audio and visual alarm is triggered | |
| Roller shutter | If the roller shutter door is not closed, the automatic light alarm will be activated | |
| Filter block warning | When the filter is blocked, the automatic light alarm will be activated | |
| Hydraulic oil over-temperature protection | When the temperature is excessively high, the radiator will be automatically activated | |
Hydraulic system |
||
| Overview | World-class brand of variable pump+proportional valve load-sensitive system | |
| Max pressure capacity | 35MPa | |
| Boom operating valve | Original world-class brand, high-performance electromagnetic proportional valve with the hydraulic pilot
The engine speed will be automatically adjusted during the boom operation |
|
| Emergency unit | Petrol engine | |
| Filter | Original world-class brand, one pipe filter at the pump outlet
The hydraulic tank is equipped with a return line filter with a filter clog detection indicator |
|
| Hydraulic oil | Normal area: Great wall low temperature 32
Extremely cold area: Kunlun No. 10 ground aviation |
|
Bodywork |
||
| General | The vehicle body is applied with a variety of high-strength aluminum profiles for the frame, providing high load-bearing capacity and excellent corrosion resistance. The skin cover is bonded using aviation adhesive for high bonding strength, vibration reduction, and noise reduction | |
| Structure | The body frame is constructed using high-strength aluminum alloy profiles with concealed lap joint technology. The body panels are bonded with high-strength structural adhesive | |
| Climbing ladder | Articulated ladder applied | |
| Painting | The exposed surfaces of the vehicle body are coated with firefighting red paint
The external surface of the water tank features decorative paint The roof of the vehicle is covered with aluminum cladding chequered with anti-corrosion and anti-slippery |
|
| Roller shutter | Equipped with lockable aluminum roller shutter doors, each operated with a single key for easy and flexible opening and closing. The doors provide excellent sealing, waterproof, and dustproof functions. Each equipment compartment is equipped with interior lighting controlled by the roller shutter door. | |
