BRIEF
The CSCWTFT005 is a 4×4 5 CBM Water Tanker Fire Truck produced by CSCTRUCK Fire Rescue Truck, designed for efficient firefighting in various emergencies. It is powered by a Yuchai YCF25160-66B 160 HP diesel engine with a displacement of 2.488L, offering a maximum output of 116 kW. The engine is a 4-cylinder, in-line, 4-stroke, water-cooled unit, ensuring reliable performance under demanding conditions. The vehicle features power steering and an air brake system, providing smooth handling and control.
With a 5 cubic meter water tank, the tanker fire truck ensures a substantial water supply for firefighting operations. The fire pump (CB10/40) has a rated pressure of 1.0 MPa and can deliver a flow of 40L/s, while the PS8/40 fire gun offers a ≥65m jet distance at a flow rate of 40L/s, allowing for effective fire suppression from a distance.
The truck’s Dongfeng double cabin accommodates 3+3 passengers, making it suitable for a crew of 6. It has a wheelbase of 3,600mm, and the overall dimensions of the truck are 6,390×2,160×3,190 mm. The truck’s weight is 3,850 kg, making it a robust and reliable vehicle for firefighting and rescue operations.
Other essential features include a 24V electric system, a national standard equipment box, and a variety of firefighting tools such as a sliding gate, row-type lights, rear climbing ladder, and more. This fire truck is available in LHD (left-hand drive) configuration, with customizable color and logo to suit various user needs.
This truck is a versatile, durable, and highly effective solution for fire-fighting missions, especially in urban and industrial environments.
FEATURES
- Powerful Engine Performance: Equipped with a Yuchai YCF25160-66B 160 HP diesel engine (2.488L displacement), providing 116 kW of output for reliable performance during demanding firefighting tasks.
- Efficient Firefighting Capability: The truck is fitted with a 5 cubic meter water tank and a CB10/40 fire pump, capable of delivering 40L/s at a rated pressure of 1.0 MPa, ensuring a robust water supply for fire suppression.
- Long-Range Firefighting: The PS8/40 fire gun has a ≥65m jet distance at a flow rate of 40L/s, enabling effective firefighting from a safe distance, ideal for handling large fires.
- Spacious and Practical Crew Cabin: The Dongfeng double cabin design accommodates a 3+3 passenger configuration, providing space for a six-person crew to operate efficiently in challenging situations.
- Advanced Firefighting Tools & Equipment: Includes a variety of essential tools such as a sliding gate, row-type lights, and a rear climbing ladder, along with a 24V electric system and a national standard equipment box, ensuring readiness for diverse firefighting and rescue missions.
SPECIFICATION
| Model No. | CSCWTFT005 | ||
| Cab | Dongfeng double cabin 3+3 | ||
| Engine(HP) | 160 | ||
| Power(kW) | 116 | ||
| Wheelbase(cm) | 3,600 | ||
| Steering | Power steering | ||
| Approach/departure angle(°) | 23/17 | ||
| Wheels & tire | 8.25R16 | ||
| Tire number | 6+1 | ||
| Tank Dimensions(mm) | |||
| Water Tank Capacity(m3) | 5 | ||
| RHD or LHD | LHD | ||
| Overall Dimensions(mm)(LxWxH) | 6,390×2,160×3,190 | ||
| Curb weight(kg) | 3,850 | ||
| Engine | Model | YCF25160-66B | |
| Horsepower | 160 | ||
| Maximum output kW | 116 | ||
| Maximum torque N.m | / | ||
| Type | 4 cylinders, in-line, 4-stroke, water-cooled, turbo inter-cooling, diesel engine | ||
| Displacement | 2.488L | ||
| Yuchai brand, Euro 6 | |||
| Driving passenger | 3+3 | ||
| Brake System | Air brake Exhaust brake |
||
| Color and LOGO | Customized | ||
| Electric System | 24V | ||
| Fire equipment part | Fire pump | CB10/40 , rated pressure 1.0MPa, flow 40L/s | |
| Fire gun | PS8/40 , flow 40L/s , jet distance water ≥65m | ||
| Standard configuration | National standard equipment box, standard fire-fighting equipment, fire pump, fire gun, fire power take off, sliding gate, row type lights, common tools, rear climbing ladder, water tank. | ||
