4×4 6 CBM Water Fire Truck

BRIEF

The 4×4 6 CBM water fire truck produced by CSCTRUCK Fire Rescue Truck is a robust and versatile firefighting vehicle, ideal for rapid response in various emergencies. Designed with both power and efficiency in mind, this truck features the Tri-ring chassis, with a model STQ2181L07Y2E6, and a 4×4 traction type suitable for different terrains. With an overall dimension of 7,470 mm (L) x 2,360 mm (W) x 3,310 mm (H), the vehicle has a Gross Vehicle Weight (GVW) of 14,900 kg, and a curb weight of 8,150 kg, offering substantial load capacity.

The truck is powered by a YCS04200-68 engine, offering 200 horsepower (147 kW), ensuring reliable performance during operations. The engine meets Euro 3 emission standards and has a displacement of 4,156 ml. Its 7-speed forward gearbox provides smooth and efficient gear shifts, while the dual-circuit compressed air brake system and power spring parking brake enhance safety during operation.

Equipped with a 6 cubic meter (CBM) water tanker, the fire truck is capable of holding and efficiently dispensing large amounts of water for firefighting. The water pump is a CB10/40 model, capable of a flow rate of 40 liters per second (L/S) with a pressure of 1.0 MPa and a suction depth of up to 7 meters. Additionally, the truck includes a PL8/32 fire monitor, which offers a flow rate of 32 L/S and a pressure of 1.0 MPa, with a range exceeding 55 meters. This monitor features a full 360° horizontal rotation and pitch angle ranging from -35° to 70°, ensuring comprehensive coverage.

The 4×4 6 CBM water fire truck‘s configuration also includes a sandwich PTO, a pipeline system, an equipment box, and a pump box, making it a fully equipped and highly capable firefighting unit.

FEATURES

1. Powerful Engine and Performance: The truck is powered by a YCS04200-68 engine delivering 200 horsepower (147 kW), ensuring reliable performance in emergencies. The engine complies with Euro 3 emission standards and features a 7-speed gearbox for smooth operation.
2. Large Water Capacity: Equipped with a 6 cubic meter (CBM) water tank, the fire truck can hold and dispense a substantial amount of water for firefighting operations, making it highly effective for various fire-related emergencies.
3. Efficient Water Pump and Fire Monitor: The CB10/40 water pump provides a high flow rate of 40 L/S at a pressure of 1.0 MPa, with a suction depth of up to 7 meters. The PL8/32 fire monitor can discharge 32 L/S with a pressure of 1.0 MPa and has a long-range (over 55 meters), offering a full 360° horizontal rotation and adjustable pitch angle (-35° to 70°).
4. All-Terrain Capability: Built on a robust Tri-ring chassis with a 4×4 traction type, the truck is designed to handle various terrains and challenging environments, ensuring flexibility and stability in diverse emergency scenarios.
5. Enhanced Safety Features: The truck includes a dual-circuit compressed air brake system, a power spring parking brake, and a sandwich PTO, ensuring safety and reliability during firefighting operations, as well as a smooth transition between vehicle functions.

SPECIFICATION
