ISUZU 8t Water Foam Tanker Fire Truck

BRIEF

The ISUZU 8t water foam tanker fire truck (model CSCWFTFT008) is a highly capable and efficient firefighting vehicle, produced by CSCTRUCK Fire Rescue Truck. Designed to meet the demands of modern firefighting, it combines powerful performance with robust construction for rapid response in emergencies.

This truck is built on the reliable ISUZU QL1160AMFRY chassis, with an overall dimension of 8,160 mm in length, 2,500 mm in width, and 3,460 mm in height. It has a gross weight of 15,560 kg, a curb weight of 9,560 kg, and a rated payload of 5,550 kg. The vehicle’s 4×2 driving type ensures good traction and maneuverability, while its 2-axle configuration and tire specifications (10.00-20-16PR, 10.00R20-16PR, 11.00R20-16PR) provide excellent stability.

Under the hood, the ISUZU 8t is powered by a 240HP 6HK1-TCL diesel engine, offering a maximum speed of 95 km/h and meeting EURO 5 emission standards. This powerful engine is complemented by a water tank capacity of 6,000 kg and a foam tank capacity of 2,000 kg, making the truck capable of handling a wide range of fire scenarios. The fire pump, manufactured by Shanghai Rongshen (CB20.10/30.60), provides a low-pressure water flow of 30 L/s and a medium-pressure flow of 60 L/s.

The fire monitor, a West PL48 model, delivers a powerful flow of 48L/S, with water jet and foam jet distances of 60m and 55m, respectively. The truck is also equipped with an electronic alarm and a high-visibility alarm lamp for safety during operations.

This fire truck offers an effective and versatile solution for firefighting needs, combining durability, performance, and advanced firefighting equipment.

FEATURES

1. Powerful Engine and Performance: The fire truck is powered by a 240HP 6HK1-TCL diesel engine, delivering reliable performance with a maximum speed of 95 km/h and meeting EURO 5 emission standards.
2. High Water and Foam Capacity: Equipped with a 6,000 kg water tank and a 2,000 kg foam tank, this truck provides substantial firefighting resources for tackling various fire scenarios effectively.
3. Advanced Fire Pump and Monitor: The fire truck includes a Shanghai Rongshen CB20.10/30.60 fire pump, offering low-pressure water flow of 30 L/s and medium-pressure flow of 60 L/s. It is also fitted with a West PL48 fire monitor, capable of delivering 48 L/s with a water jet range of 60m and a foam jet range of 55m.
4. Durable and Stable Construction: Built on the ISUZU QL1160AMFRY chassis, the truck has an overall dimension of 8,160 mm (L) x 2,500 mm (W) x 3,460 mm (H) and a gross weight of 15,560 kg, providing excellent stability and maneuverability, especially with its 4×2 drive type.
5. Safety and Visibility Features: For enhanced safety during operations, the truck comes with an electronic alarm, a high-visibility alarm lamp, and a robust, easy-to-operate design, ensuring maximum efficiency during emergency responses.

SPECIFICATION
