BRIEF
The MAN 4WD 5,000L Small Water Foam Fire Truck, produced by CSCTRUCK Fire Rescue Truck, is a compact yet highly capable emergency response unit designed for rapid intervention in urban, industrial, and semi-off-road environments. Built on a rugged MAN 4×4 chassis, it combines strong mobility, advanced firefighting systems, and reliable engineering to ensure performance under demanding conditions.
Powered by the MAN D2676LF66 Euro-6 diesel engine, this fire truck delivers an impressive 500 hp (368 kW), ensuring rapid acceleration and stable performance even when fully loaded. The 4×4 drivetrain, spring suspension system, and 18,000 kg gross vehicle weight provide excellent terrain adaptability and structural durability. With a 3,600 mm wheelbase and overall dimensions of 8,000 × 2,550 × 3,900 mm, the vehicle maintains a balance between maneuverability and operational capacity.
The firefighting system is centered around a 4,000 L water tank and 550 L foam tank, supported by a high-performance centrifugal pump system capable of delivering up to 3,000 L/min. The integrated water/foam monitor offers a jet reach of up to 60 meters for water and 45 meters for foam, with joystick-controlled operation from both the cabin and rear control panel. Dual 30-meter high-pressure hose reels further enhance firefighting versatility.
The cabin is designed for operational efficiency, featuring a day-type layout, left-hand drive configuration, automatic transmission with TipMatic 12.28 OD gearbox, and integrated safety technologies such as a reverse camera system and MAN media radio. Additional equipment includes a 200 L fuel tank, a 35 L AdBlue tank, air conditioning, and onboard rescue tools such as cutting and entry equipment.
Overall, this MAN 4WD fire truck represents a well-balanced solution for fast-response firefighting missions, combining powerful engine performance, advanced pump technology, and practical field equipment integration.
FEATURES
- Powerful Euro-6 Engine Performance
Equipped with a MAN D2676LF66 diesel engine delivering 500 hp (368 kW), ensuring rapid acceleration and reliable performance even under full firefighting load. - High Mobility 4×4 Chassis System
Built on a rugged MAN 4WD off-road chassis with a 3,600 mm wheelbase and 18,000 kg GVW, providing excellent stability and terrain adaptability in urban and semi-off-road conditions. - Dual-Agent Firefighting Capacity
Integrated 4,000 L water tank + 550 L foam tank, enabling flexible fire suppression for both ordinary fires and hydrocarbon-based industrial fires. - High-Performance Pump & Monitor System
Centrifugal pump delivers up to 3,000 L/min flow rate, paired with a water/foam monitor capable of reaching 60 m (water) and 45 m (foam) for long-range firefighting. - Advanced Operator-Centric Cabin Design
Features automatic TipMatic transmission, reverse camera, air conditioning, and integrated control systems, improving safety, driving comfort, and operational efficiency during emergency response.
SPECIFICATION
🏷️ General Information
| Parameter | Specification |
|---|---|
| Brand | MAN |
| Construction | Fire Fighter Truck |
| Construction Volume | 4,000 Ltr. |
| Fuel Type | Diesel |
| Model Year | 2019 |
| Vehicle Status | New |
⚙️ Engine & Performance
| Parameter | Specification |
|---|---|
| Engine Type | D2676LF66 |
| Emission Code | EURO-6 |
| Engine Power | 500 hp / 368 kW |
🛋️ Cabin & Controls
| Parameter | Specification |
|---|---|
| Cabin Type | Day |
| Steering | Left-hand drive |
| Transmission | Automatic |
| Gearbox | TipMatic 12.28 OD |
| PTO | Flywheel |
🚛 Chassis & Dimensions
| Parameter | Specification |
|---|---|
| Wheelbase | 3,600 mm |
| GVW | 18,000 kg |
| Axle Configuration | 4×4 |
| Suspension | Spring |
| External Dimensions | 8,000 x 2,550 x 3,900 mm |
🛞 Axles & Wheels
| Axle | Steering | Tires | Brakes | Suspension | Driven | Tire Size |
|---|---|---|---|---|---|---|
| Axle 1 | Yes | Single | Drum | Spring | Yes | 14.00R20 |
| Axle 2 | No | Single | Drum | Spring | Yes | 14.00R20 |
🔧 Additional Equipment & Remarks
| Category | Details |
|---|---|
| Fuel Tank | 200 Ltr. |
| AdBlue Tank | 35 Ltr. |
| Air Conditioning | Yes |
| Media System | MAN Media Truck Radio |
| Safety | Reverse camera with extra display |
| Mileage | Demo units: ~2,800 km |
🚒 Fire Fighting System (Volkan Equipment)
| Component | Specification |
|---|---|
| Pump System | Central pumping unit VFPN-H 10-400/40-250 |
| Pump Type | Centrifugal pump with 2 self-priming steps |
| Tank System | 4,000 L water + 550 L foam |
| Control System | Cabin + rear external control panel |
| Water/Foam Monitor | WG3000SE |
| Flow Rate | 3,000 L/min |
| Control Type | Joystick (in-cabin) |
| Jet Adjustment | Adjustable via joystick |
| Water Jet Range | Up to 60 m |
| Foam Jet Range | Up to 45 m |
| Monitor Movement | Vertical: -50° to +45° / Horizontal: 270° |
| Hose Reels | 2 × 30 m high-pressure reels |
| Rescue Equipment | Entry tools, cutting equipment, and electrical rescue tools |
| Additional Tools | Fire extinguishing delivery systems, ladders (extendable & general use) |
