BRIEF
The MAN 4×4 6,000L Off-Road Water Foam Fire Tender, produced by CSCTRUCK Fire Rescue Truck, is a modern emergency response vehicle engineered for high-performance firefighting in off-road, industrial, and urban environments. With a 2025 production year and 2026 model designation, it is a brand-new platform designed for durability, rapid deployment, and operational reliability under extreme conditions.
It is powered by the MAN D0836LFL90 EURO-5 diesel engine, delivering 290 hp (213 kW), combined with a PowerMatic 08.13 OD automatic transmission and a gearbox-dependent PTO system, ensuring stable and efficient power delivery during firefighting operations and auxiliary pump work.
Built on a rugged 4×4 drivetrain, the MAN 4×4 6,000L Off-Road Water Foam Fire Tender offers a GVW of 17,500 kg and a 4,500 mm wheelbase, supported by heavy-duty spring suspension for enhanced stability on uneven terrain. This configuration ensures strong traction and mobility across difficult landscapes such as industrial sites, forests, and disaster zones.
Its compact yet functional structure measures 7,990 × 2,550 × 3,640 mm, with an empty weight of 10,430 kg, balancing maneuverability with sufficient capacity for firefighting systems and equipment integration.
The firefighting system includes a 5,000 L water tank and a 500 L foam tank, powered by a rear-mounted JOHSTADT TO 3001 centrifugal pump compliant with EN 1028 standards. It delivers 10/15 bar normal pressure and up to 40 bar high pressure, with a 2,400 L/min water/foam monitor, a 50 m high-pressure hose reel, and a nozzle output of 150 L/min for precise fire suppression.
The crew cabin accommodates 5+1 personnel in a crew cab layout, featuring left-hand drive, air conditioning, and an integrated PA system with a 100W speaker and multi-tone siren for emergency coordination.
The MAN 4×4 6,000L Off-Road Water Foam Fire Tender runs on 14.00R20 tires with drum brakes on both axles, and is equipped with a 300 L fuel tank and 27 L AdBlue tank, ensuring extended operational endurance in continuous mission scenarios.
FEATURES
- High-Performance Firefighting Powertrain
Equipped with a MAN D0836LFL90 EURO-5 diesel engine delivering 290 hp (213 kW), paired with a PowerMatic automatic transmission and PTO system for reliable pump operation and consistent power delivery in emergency conditions. - Large Dual-Agent Fire Suppression System
Features a 5,000 L water tank and 500 L foam tank, supported by a JOHSTADT TO 3001 centrifugal pump (EN 1028 compliant), capable of up to 2,400 L/min monitor output and both normal (10–15 bar) and high-pressure (up to 40 bar) modes. - Rugged 4×4 Off-Road Capability
Built on a heavy-duty 4×4 drivetrain with 17,500 kg GVW, reinforced suspension, and 14.00R20 tires, ensuring strong traction and stability on forests, industrial zones, and rough terrain environments. - Compact Yet Mission-Optimized Structure
With dimensions of 7,990 × 2,550 × 3,640 mm, the vehicle balances maneuverability with operational capacity, making it suitable for both urban access routes and off-road emergency deployments. - Advanced Crew & Emergency Response Systems
A 5+1 crew cab with air conditioning, left-hand drive layout, PA system (100W speaker), and multi-tone siren enhances coordination, safety, and rapid response efficiency during firefighting missions.
SPECIFICATION
🏷️ General Information
| Parameter | Specification |
|---|---|
| Brand | MAN |
| Construction | Fire Fighter Truck |
| Construction Volume | 5,500 Ltr. |
| Fuel Type | Diesel |
| Production Year | 2025 |
| Model Year | 2026 |
| Vehicle Status | New |
⚙️ Engine System
| Parameter | Specification |
|---|---|
| Engine Type | D0836LFL90 |
| Emission Code | EURO-5 |
| Engine Power | 290 hp / 213 kW |
🛋️ Cabin & Controls
| Parameter | Specification |
|---|---|
| Cabin Type | Crew Cab |
| Steering | Left-hand Drive |
| Transmission Type | Automatic |
| Gearbox | PowerMatic 08.13 OD |
| PTO | Gearbox dependent |
🚛 Chassis & Performance
| Parameter | Specification |
|---|---|
| Wheelbase | 4,500 mm |
| GVW | 17,500 kg |
| Axle Configuration | 4×4 |
| Suspension Type | Spring |
📏 Dimensions & Weight
| Parameter | Specification |
|---|---|
| External Dimensions | 7,990 × 2,550 × 3,640 mm |
| Empty Weight | 10,430 kg |
🛞 Axle Details
Axle 1
| Parameter | Specification |
|---|---|
| Steering | Yes |
| Tires | Single |
| Tire Size | 14.00R20 |
| Brakes | Drum |
| Suspension | Spring |
| Driven | Yes |
Axle 2
| Parameter | Specification |
|---|---|
| Steering | No |
| Tires | Single |
| Tire Size | 14.00R20 |
| Brakes | Drum |
| Suspension | Spring |
| Driven | Yes |
🔧 Additional Equipment & Remarks
| Parameter | Specification |
|---|---|
| Fuel Tank | 300 L |
| AdBlue Tank | 27 L |
| Air Conditioning | Equipped |
🚨 Fire Fighting System
| Component | Specification |
|---|---|
| Crew Capacity | 5+1 seats |
| Locker Layout | 2+2+1 |
| Water Tank | 5,000 L |
| Foam Tank | 500 L |
| Pump Type | JOHSTADT TO 3001 (rear-mounted) |
| Centrifugal Pump | EN 1028 compliant |
| Pump Pressure | 10/15 bar (normal), 40 bar (high pressure) |
| Water/Foam Monitor Flow | 2,400 L/min @ 10 bar |
| Hose Reel | 1-inch, 50 m high-pressure |
| Nozzle Output | 150 L/min jet/spray |
| Roof Equipment | Red light bar + PA system |
| PA System | 100W speaker, microphone, multi-tone siren |
