IVECO 6×6 13000L Water Foam Fire Vehicle

BRIEF

The IVECO 6×6 13,000L Water Foam Fire Vehicle, produced by CSCTRUCK Fire Rescue Truck, is a high-capacity firefighting apparatus engineered for rapid emergency response, industrial fire protection, municipal firefighting, and operations in challenging terrains. Built on a rugged IVECO 6×6 all-wheel-drive chassis, this vehicle combines exceptional mobility, powerful firefighting performance, and large extinguishing agent capacity to handle complex fire incidents efficiently.

Powered by the renowned IVECO Cursor 13 diesel engine, the truck delivers 470 hp (349 kW) of power, ensuring reliable performance under demanding operating conditions. The engine complies with the EURO-3 emission standard and is paired with a durable ZF16S2520TO manual transmission and NH/4C PTO, providing smooth power transfer to both the drivetrain and firefighting equipment. The vehicle features a comfortable left-hand-drive sleeper cab equipped with air conditioning, enhancing crew comfort during extended emergency deployments.

The firefighting system consists of an 11,000-liter water tank and a 1,100-liter foam tank, providing a total extinguishing agent capacity of 12,100 liters. At the heart of the system is a reliable Maleco fire pump, capable of delivering 4,000 L/min at 10 bar in medium-pressure mode and 250 L/min at 40 bar in high-pressure mode. A roof-mounted monitor provides an impressive 2,400 L/min discharge rate, enabling effective suppression of large-scale fires from a safe distance. The integrated foam proportioning system offers 3% and 6% mixing ratios, allowing efficient firefighting against flammable liquid and hydrocarbon fires.

Built on a 4,500 mm wheelbase with a 33,500 kg GVW, the IVECO 6×6 13,000L Water Foam Fire Vehicle features heavy-duty spring suspension and robust 325/95R24 tires across all three driven axles. Measuring 10,000 × 2,600 × 3,550 mm, the truck balances maneuverability with operational capacity. Additional features such as electric-driven 50-meter hose reels, practical 2+2+1 locker configuration, and a 390-liter fuel tank further enhance operational readiness and firefighting effectiveness.

FEATURES

1. High-capacity water & foam system
   Equipped with an 11,000L water tank and 1,100L foam tank (12,100L total), it enables sustained firefighting operations for large-scale industrial and municipal fire incidents.
2. Powerful firefighting pump and monitor system
   The Maleco pump delivers up to 4,000 L/min at 10 bar and a roof monitor reaching 2,400 L/min, ensuring strong, long-range fire suppression capability with both medium and high-pressure modes.
3. Heavy-duty 6×6 all-terrain mobility
   Built on a rugged IVECO 6×6 chassis, the vehicle provides excellent off-road performance, stability, and traction in difficult terrains such as industrial sites, forests, and disaster zones.
4. High-performance powertrain for emergency response
   Powered by the Cursor 13 diesel engine (470 hp / 349 kW) with ZF16S transmission, it ensures reliable acceleration, strong load handling, and continuous operation under demanding emergency conditions.
5. Integrated firefighting equipment and operational readiness
   Produced by CSCTRUCK Fire Rescue Truck, it includes electric hose reels, foam proportioning (3%/6%), multiple storage lockers, and a 50-meter hose system for fast deployment and efficient crew operation.
