BRIEF
The HOWO Crew Cab 25t Water Tanker Fire Truck produced by CSCTRUCK Fire Rescue Truck is a heavy-duty emergency response vehicle engineered for large-scale firefighting, municipal protection, and rapid water supply operations. Built on a rugged HOWO chassis, it integrates high-capacity water storage, strong pumping performance, and durable multi-axle mobility, making it suitable for demanding urban, industrial, and rural fire scenarios.
At the core of its firefighting system is a CB10/60 low-pressure fire pump delivering a flow rate of 60 L/s at 1.0 MPa pressure, ensuring rapid and continuous water discharge during critical operations. The system provides a maximum suction head of 10 meters and a diversion time of under 35 seconds, allowing fast response and efficient deployment. With a large 25,000 kg water tank capacity, the truck supports prolonged firefighting missions without frequent refilling. Its water jet range of ≥70 meters significantly improves operational reach and firefighter safety in high-risk environments.
The chassis configuration emphasizes strength and stability. Powered by a 327 kW diesel engine and matched with a 12–16-speed transmission, the vehicle delivers strong torque output and adaptable driving performance under heavy load conditions. The 4-axle layout with 12 tires ensures excellent weight distribution and road grip, while the air braking system enhances safety during high-intensity operations. Axle loads of 6.2 tons at the front and 12.3 tons on the rear double axle further reinforce balance and durability.
In terms of structure, the HOWO Crew Cab 25t Water Tanker Fire Truck measures 11,990 × 2,550 × 3,560 mm and features a wheelbase of 1,950 + 4,600 + 1,400 mm, offering both stability and maneuverability. The crew cab accommodates up to seven personnel, providing sufficient space for firefighting teams. Equipped with 315/80R22.5 tires, the vehicle maintains strong traction and reliability across varied and challenging terrain conditions.
FEATURES
- High-capacity water storage (25,000 kg)
Equipped with a large 25-ton water tank, it enables long-duration firefighting missions and reduces the need for frequent refilling during large-scale emergencies. - High-performance CB10/60 fire pump system
Delivers a flow rate of 60 L/s at 1.0 MPa pressure, ensuring strong and continuous water discharge for rapid fire suppression in critical situations. - Powerful heavy-duty chassis and drivetrain
Built on a robust HOWO multi-axle chassis powered by a 327 kW diesel engine with a multi-speed transmission, providing strong torque and reliable performance under full load. - Excellent mobility and operational stability
The 4-axle configuration with 12 tires and an air braking system ensures balanced weight distribution, strong traction, and safe handling across urban, industrial, and rough terrain conditions. - Spacious 7-person crew cab design
The integrated crew cabin accommodates up to seven firefighters, offering sufficient space for rapid deployment teams and improving operational coordination during emergency response.
SPECIFICATION
|
Vehicle Technical Parameters
|
|
|
Product Name
|
HOWO Crew Cab 25t Water Tanker Fire Truck
|
|
Fire Pump
|
CB10/60 low-pressure fire pump
|
|
Fire Pump Flow Rate
|
60L/s
|
|
Fire Pump Pressure
|
1.0MPa
|
|
Max Persons Allowed in the Cab
|
7
|
|
Overall Dimensions (mm)
|
11,990X2,550X3,560MM
|
|
Maximum Suction Head of Fire Pump(m)
|
10
|
|
Fire Pump Diversion Time
|
<35s
|
|
Range
|
Water ≥ 70m
|
|
Water Tank Capacity (kg)
|
Water: 25,000kg
|
|
Chassis Technical Parameters
|
|
|
Chassis Brand
|
HOWO
|
|
Fuel Type
|
Diesel oil
|
|
Front/Rear Axle(t)
|
6.2/Rear Double 12.3
|
|
Number of Axles
|
4
|
|
Number of tires
|
12
|
|
Brakes
|
Air Brake
|
|
Engine Power(KW)
|
327
|
|
Transmission
|
12-16-Speed Transmission
|
|
Wheelbase(mm)
|
1,950+4,600+1,400
|
|
Tire Size
|
315/80R22.5
|
