SHACMAN F3000 12 CBM Water Foam Tanker Fire Truck

BRIEF

The SHACMAN F3000 12 CBM Water Foam Tanker Fire Truck, produced by CSCTRUCK Fire Rescue Truck is a high-performance emergency response vehicle designed for municipal, industrial, and large-area firefighting operations. Built on a robust 6×4 drivetrain chassis, it delivers strong traction, stability, and load-carrying capability, making it suitable for demanding terrain and rapid deployment scenarios.

The vehicle features overall dimensions of 10,320 × 2,550 × 3,850 mm, with a wheelbase of 4,375 + 1,400 mm. It is equipped with a heavy-duty 16T HD dual casting axle with a 4.266 ratio, ensuring reliable power transmission and operational durability. The truck complies with EURO II emission standards and utilizes a reinforced multi-leaf spring suspension system (front and rear, 4-bolt saddle design), balancing payload stability and driving comfort under full load conditions.

Its fire suppression system is centered around a 12 CBM tank configuration, consisting of a 10 m³ water tank and a 2 m³ foam tank. The tank body is constructed from durable aluminum alloy materials designed to resist corrosion and extend service life. The integrated fire pump provides a flow rate of 60 L/s at a pressure of 1.0 MPa, enabling rapid and efficient fire attack capability.

The vacuum pump system adopts a piston-type design with a water diversion time of ≤35 seconds and a water absorption depth of ≥7 meters. It maintains a maximum working pressure of ≥85 kPa, ensuring fast priming and reliable water intake in various environments. The pipeline system includes a DN150 suction line, a DN100 roof-mounted fire cannon outlet, and additional DN80 and DN65 outlets on both sides of the pump room for flexible operation.

A WESTE PL8/48W fire cannon is installed on the roof, delivering a working range of ≥70 meters for water and ≥65 meters for foam, providing strong long-distance suppression capability for high-risk fire scenarios.

FEATURES

1. High-capacity dual-agent fire suppression system
   The truck is equipped with a 12 CBM tank configuration (10 m³ water + 2 m³ foam), allowing simultaneous or independent use of water and foam for versatile firefighting across urban and industrial scenarios.
2. Powerful 6×4 heavy-duty chassis performance
   Built on a robust 6×4 drivetrain with a 16T HD dual casting axle (4.266 ratio), it delivers strong traction, stability, and load-bearing capacity, making it suitable for rough terrain and high-demand emergency deployments.
3. High-efficiency fire pump system
   The integrated pump delivers up to 60 L/s at 1.0 MPa pressure, ensuring rapid water discharge for fast fire suppression and improved response efficiency in critical situations.
4. Long-range roof-mounted fire cannon
   Fitted with a WESTE PL8/48W monitor, the system provides a water reach of ≥70 meters and foam reach of ≥65 meters, enabling effective long-distance fire attack and control of high-risk fire zones.
5. Fast priming and a reliable water intake system
   The piston-type vacuum pump achieves water diversion in ≤35 seconds with a suction depth of ≥7 meters, ensuring quick deployment and dependable operation even in challenging water-source conditions.
