BRIEF
The 10 Wheelers 12 CBM Water Tender Fire Truck produced by CSCTRUCK Fire Rescue Truck is a heavy-duty emergency response vehicle engineered for efficient firefighting operations in urban, industrial, and municipal environments. Built on a reliable Dongfeng 6×4 chassis, this firefighting truck combines strong carrying capacity, advanced fire suppression performance, and dependable mobility to meet demanding rescue missions.
With an overall dimension of 10,280×2,520×3,620 mm and a total vehicle mass of 33,900 kg, the truck offers excellent stability and operational efficiency during emergency deployments. The 12 CBM water tank provides a large onboard water supply, enabling extended firefighting operations without the need for frequent refilling. Its rated payload capacity of 17,800 kg further highlights its robust transport capability for firefighting equipment and water resources.
Powered by a high-performance 356 kW diesel engine, the 10 Wheelers 12 CBM Water Tender Fire Truck delivers strong driving power and reliable performance across various terrains and road conditions. The 6×4 drive configuration, combined with a wheelbase of 4,350+1,350 mm and durable 11.00R20 tires, ensures superior traction, maneuverability, and road stability. The air brake system enhances driving safety and braking efficiency, especially during high-speed emergency response situations.
Equipped with a PL8/80 fire water monitor, the truck provides a powerful water flow rate of 80 L/s at a working pressure of 1.0 MPa. The fire monitor can achieve an impressive water jet range of up to 80 meters, allowing firefighters to control fires from a safer distance and cover larger fire zones effectively.
The spacious crew cab with a 3+3 seating layout accommodates 6 firefighters comfortably, making the 10 Wheelers 12 CBM Water Tender Fire Truck highly suitable for rapid deployment and coordinated firefighting operations.
FEATURES
- Large 12 CBM Water Capacity
Equipped with a 12 CBM water tank, the 10 Wheelers Water Tender Fire Truck provides a substantial onboard water supply for prolonged firefighting operations. This large-capacity tank reduces refill frequency and improves emergency response efficiency in urban, industrial, and municipal fire incidents. - Powerful Fire Suppression Performance
The truck features a high-efficiency PL8/80 fire water monitor with a flow rate of 80 L/s at 1.0 MPa working pressure. Its impressive water jet range of up to 80 meters enables firefighters to combat fires effectively from a safer distance while covering large fire zones quickly. - Strong Heavy-Duty Chassis and Engine
Built on a reliable Dongfeng 6×4 chassis and powered by a 356 kW diesel engine, the vehicle delivers outstanding driving power, durability, and operational stability. The robust drivetrain ensures dependable performance even under demanding emergency and rescue conditions. - Excellent Mobility and Driving Safety
The 6×4 drive configuration, combined with a 4,350+1,350 mm wheelbase and durable 11.00R20 tires, provides superior traction, maneuverability, and road stability. The advanced air brake system further enhances braking performance and driving safety during high-speed emergency responses. - Spacious Crew Cab for Rapid Deployment
Designed with a comfortable 3+3 seating layout, the spacious crew cab accommodates up to 6 firefighters, allowing rapid team deployment and coordinated firefighting operations. The ergonomic cabin design improves crew comfort and operational readiness during long emergency missions.
SPECIFICATION
| [Technical Parameters of the Entire Vehicle] | |
| Product Name | Fire Fighting Truck |
| Total mass(Kg) | 33,900 |
| Rated load mass (Kg) | 17,800 |
| Curb weight (Kg) | 15,650 |
| Dimensions(mm)(LxWxH) | 10,280×2,520×3,620 |
| Tank volume (m3) |
12 |
| Fire water gun(model) | PL8/80 |
| Fire water gun range(m) | 80 |
| Pressure(Mpa) | 1.0 |
| flow(L/S) | 80 |
| Cab Capacity | 3+3 |
| [Chassis Technical Parameters] | |
| Chassis brand | Dongfeng |
| Brake | Air Brake |
| Type of Fuel | Diesel |
| Front Axle/Rear Axle(t) | 7/13 |
| Engine Power(kw) | 356 |
| Number of Axles | 2 |
| Drive form | 6×4 |
| Wheelbase (mm) | 4,350+1,350 |
| Tire Size | 11.00R20 |
