MAN 4×4 5000L Water Foam Fire Tanker Truck

BRIEF

The MAN 4×4 5000L Water Foam Fire Tanker Truck, produced by CSCTRUCK Fire Rescue Truck, is a modern emergency response vehicle designed for high-performance firefighting operations in urban, industrial, and off-road environments. Built on a rugged MAN 4×4 chassis, it combines strong mobility, advanced firefighting technology, and durable engineering to ensure reliable performance in critical situations.

Powered by the EURO-6-compliant MAN D0836LFLBI diesel engine, the truck delivers 320 hp (235 kW), offering an excellent balance between power and efficiency. The engine is paired with a TipMatic 12-speed automatic transmission and gearbox-dependent PTO system, enabling smooth driving behavior and efficient power delivery to the firefighting equipment. Its 4×4 drivetrain and reinforced spring suspension allow it to operate effectively on rough terrain, narrow city streets, and emergency disaster zones.

The MAN 4×4 5000L Water Foam Fire Tanker Truck features a crew cab configuration with seating for 5+1 firefighters, ensuring rapid deployment of personnel. With a GVW of 18,000 kg and compact yet robust dimensions (8,300 × 2,500 × 3,700 mm), it provides a stable platform while maintaining maneuverability. The integrated safety systems, including a rear-view camera, parking assistance, and in-cab monitoring, enhance operational safety during emergency response.

The firefighting system, supplied by Volkan equipment, includes a 4,000-liter water tank and a 200-liter foam tank, supported by a high-capacity pump system capable of delivering up to 3,000 L/min at low pressure and 250 L/min at high pressure. A roof-mounted water/foam monitor, dual hose reels, and a Fireco 5-meter telescopic lighting mast ensure effective fire suppression and night-time visibility.

Additional features such as air conditioning, infotainment navigation, acoustic and optical warning systems, and centralized in-cab control enhance usability and crew comfort. Overall, this MAN 4×4 fire tanker represents a highly capable, reliable, and well-equipped solution for modern firefighting missions requiring speed, endurance, and versatility.

FEATURES

1. Powerful EURO-6 Engine Performance
   Equipped with a MAN D0836LFLBI diesel engine delivering 320 hp (235 kW), the truck ensures strong, efficient, and environmentally compliant performance for demanding firefighting missions.
2. Advanced 4×4 Off-Road Mobility
   The rugged MAN 4×4 chassis with reinforced suspension and high ground clearance allows reliable operation across urban streets, industrial zones, and challenging off-road disaster environments.
3. High-Capacity Water & Foam System
   Features a 4,000L water tank and 200L foam tank combined with a high-performance pump system capable of up to 3,000 L/min low-pressure output, ensuring rapid and effective fire suppression.
4. Professional Crew & Safety Design
   A 5+1 crew cab layout provides efficient personnel transport, supported by safety systems such as rear-view camera, parking assistance, and in-cab monitoring for safer emergency operations.
5. Integrated Firefighting & Control Equipment
   Includes a roof-mounted water/foam monitor, dual hose reels, telescopic lighting mast, and centralized in-cab controls, enabling efficient nighttime operation and improved firefighting precision.

SPECIFICATION

🚒 MAN Fire Fighter Truck Specifications

⚙️ Engine & Performance

🛋️ Cabin & Transmission

🚛 Chassis & Dimensions

🛞 Axles & Running Gear

🔧 Operational Details & Equipment

🚒 Fire Fighting System (Volkan Equipment)
