MAN 8000L Airport Rescue Fire Truck

BRIEF

The MAN 8000L airport rescue fire truck produced by CSCTRUCK Fire Rescue Truck is a high-performance emergency response vehicle specifically engineered for rapid intervention in airport and aviation-related fire incidents. Built on a robust 6×4 drive chassis with a gross vehicle weight of 25,000 kg, the truck combines durability, speed, and advanced firefighting capabilities to meet the demanding requirements of airport rescue operations.

Powered by a MAN D2066LF06 engine delivering 294 kW (400 HP), the vehicle ensures strong acceleration and reliable performance, with a maximum speed of 90 km/h. Its optimized wheelbase of 3,900 + 1,350 mm provides stability and maneuverability, essential for navigating airport runways and tight operational zones. The cabin accommodates up to 6 personnel (1+1+4), enabling efficient team deployment during emergencies.

The airport fire truck is equipped with a built-in 8,000-liter firefighting system, consisting of a 6,000-liter water tank and a 2,000-liter foam tank, allowing it to handle various fire scenarios, including fuel and chemical fires. Its CB20·10/30·60 fire pump, installed at the rear, delivers impressive performance with a rated flow of 60 L/s at 1.0 MPa and 30 L/s at 2.0 MPa, supported by a vacuum pump for rapid water priming.

A key feature is the PL48-64YZ water/foam monitor, capable of delivering 48–64 L/s with a water range of ≥60 meters and foam range of ≥55 meters. The monitor offers full 360° rotation and a wide elevation range (-30° to +70°), ensuring comprehensive fire coverage. Additional features include multiple water outlets, precision pressure gauges, and a full-power PTO system, making this fire truck a reliable and efficient solution for airport firefighting and rescue missions.

FEATURES

1. High-Performance MAN Powertrain
   Equipped with a MAN D2066LF06 engine delivering 294 kW (400 HP), this fire truck offers strong acceleration, reliable power output, and a maximum speed of 90 km/h—essential for rapid emergency response in airport environments.
2. Large-Capacity Firefighting System
   The integrated 8,000-liter system includes a 6,000L water tank and a 2,000L foam tank, enabling effective handling of diverse fire scenarios such as aviation fuel and chemical fires.
3. Advanced Fire Pump Technology
   Fitted with a CB20·10/30·60 fire pump, the truck delivers high efficiency with flow rates of 60 L/s at 1.0 MPa and 30 L/s at 2.0 MPa, supported by a vacuum pump for fast water priming and continuous operation.
4. Powerful 360° Fire Monitor
   The PL48-64YZ water/foam monitor provides a flow rate of 48–64 L/s, with a long-range reach (≥60 m for water, ≥55 m for foam), full 360° rotation, and wide elevation angles (-30° to +70°) for comprehensive fire suppression coverage.
5. Stable and Crew-Oriented Design
   Built on a durable 6×4 chassis with a 25,000 kg GVW and optimized wheelbase, the vehicle ensures excellent stability and maneuverability. The spacious cabin accommodates up to 6 crew members, supporting efficient and coordinated emergency operations.

SPECIFICATION
