BRIEF
The Ziegler 4×4 7000L airfield fire truck, produced by CSCTRUCK Fire Rescue Truck, is a high-performance emergency response vehicle designed to meet the rigorous demands of modern airport firefighting operations. Built on a robust Ziegler chassis, this vehicle combines speed, power, and advanced fire suppression technology to ensure rapid response to incidents on airfields and runways.

Equipped with a 6,000-liter water tank, an 800-liter foam tank, and a 250 kg dry powder system, the truck is capable of handling a wide range of fire scenarios, from flammable liquid spills to aircraft fires. The integration of these 3 firefighting agents allows responders to quickly adapt to complex emergencies, providing effective suppression of Class A, B, and C fires. Its advanced pumping and proportioning systems guarantee precise delivery of extinguishing agents, even under extreme conditions.

Powering the truck is a Scania DC16 engine delivering 566 kW (770 hp), enabling outstanding acceleration and top-tier performance. The vehicle achieves 0–80 km/h in under 20 seconds, a critical capability when rapid intervention is essential to safeguard passengers, crew, and infrastructure. With a maximum speed of 120 km/h, the fire truck ensures swift deployment across large airport environments.

The 4×4 drive configuration enhances off-road mobility, allowing the truck to traverse uneven or unpaved surfaces commonly found in airfield perimeters. Its ergonomic cab design offers optimal visibility and easy access to operational controls, supporting efficient crew performance during high-stress situations.
Overall, the Ziegler 4×4 7000L airfield fire truck represents a fusion of reliability, advanced engineering, and firefighting versatility. Purpose-built for aviation safety, it ensures airports are equipped with a dependable, high-speed firefighting solution capable of responding decisively to the most demanding airfield emergencies.
FEATURES
- High-Capacity Fire Suppression System – Equipped with a 6,000 L water tank, 800 L foam tank, and 250 kg dry powder unit, enabling rapid response to diverse fire scenarios on airfields.
- Robust Chassis and Drivetrain – Built on a Ziegler chassis with 4×4 drive, ensuring excellent off-road mobility and stability across runways, taxiways, and rough terrain.
- Powerful Performance – Powered by a Scania DC16 engine delivering 566 kW (770 hp), allowing the truck to accelerate from 0–80 km/h in under 20 seconds and reach a maximum speed of 120 km/h.
- Specialized Airfield Design – Optimized for aviation emergencies, combining high-speed response capability with large agent storage to control aircraft fires quickly.
- Durable and Efficient Construction – Engineered for reliability under demanding conditions, with components designed to withstand continuous heavy-duty operations at airports.
SPECIFICATION
| Item | Specification |
|---|---|
| Vehicle Type | Ziegler 4×4 7000L Airfield Fire Truck |
| Engine Model / Engine Power | Scania DC16, 566 kW (770 hp) |
| Drive / Performance | Permanent 4×4, 0–80 km/h in <20 s, Max speed 120 km/h |
| Transmission | Continuously variable, fully automatic |
| Wheelbase | 4,750 mm |
| Permissible Gross Weight | 26,000 kg |
| Axle Load | 13,000 kg |
| Dimensions (L × W × H) | 10,200 × 3,000 × 3,700 mm |
| Cab / Crew | ZIEGLER Safety Cabin Z-Cab AiR / up to 1 + 5 |
| Bodywork | ALPAS (latest generation) |
| Fire Pump | ZIEGLER FPN 10-6000, PTO-driven (optional FPN 10-8000, bronze pump or stainless steel piping) |
| Foam Proportioning System | ZIEGLER EAD |
| Water Tank | 6,000 L (corrosion-resistant GRP) |
| Foam Tank | 800 L (corrosion-resistant GRP) |
| Monitors | Front: ZT-2000 (optional lowering), Roof: ZT-6000 (optional ZT-8000) |
| Additional Extinguishing Systems | High-pressure pump, 250 kg dry powder system, quick attack reels, 120 kg CO₂ system, CAFS |
| Optional Equipment | Assistance systems (rollover protection, navigation), camera systems (IR, color, BirdView, mirror replacement), extra lights (work, ambient, flashing), light mast, handhelds for turret control, fall protection |
| Standards | ICAO, EASA, NFPA, ADV, EC, CCCF |
| Manufacturer | CSCTRUCK Fire Rescue Truck |
