HOWO 24ton Water Foam Tanker Fire Engine

BRIEF

The HOWO 24-ton water foam tanker fire engine produced by CSCTRUCK Fire Rescue Truck is a heavy-duty, high-capacity firefighting vehicle designed for rapid response and sustained fire suppression in industrial, urban, and large-scale emergency scenarios. Built on the robust ZZ5447TXFV466MF1 chassis from SINOTRUK, this 4-axle fire engine combines strong load-bearing capacity, stable performance, and advanced firefighting features. With a gross vehicle weight of 42,000 kg and a rated payload of 24,000 kg, it is capable of carrying substantial amounts of water and foam to effectively combat fires over extended periods.

The vehicle features a tank capacity of 20,000 liters of water and 4,000 liters of foam, enabling high-efficiency fire suppression. The fire engine is equipped with a PL8/80 fire monitor delivering a flow rate of 80 L/s at 1 MPa, with water projecting up to 80 meters and foam up to 70 meters. The vehicle-mounted CB10/100 fire pump ensures rapid water intake (≤35 s from a 7 m depth) and high-pressure output (1.0 MPa), driven by a sandwich-type full-power PTO system.

Powered by an MC11.44-60 diesel engine producing 297 kW, the fire engine achieves a top speed of 90 km/h, while its robust suspension (4/5 leaf springs) and wide track widths (front 2,110 mm, rear 1,830 mm) provide excellent stability and maneuverability over various terrains. The full steel-welded cabin accommodates 2 personnel and offers enhanced durability, with optional stainless steel tank construction.

Additional design features include aluminum roller shutter doors on equipment compartments, foldable side and rear steps with gas springs, and a comprehensive lighting and signaling setup including PTO indicator lights, LED lights, outline lamps, and rear work lights. With its combination of high-capacity firefighting capability, rapid deployment features, and durable construction, the HOWO 24-ton water foam tanker fire engine represents a reliable solution for modern firefighting operations requiring both efficiency and safety.

FEATURES

1. High-Capacity Firefighting Tanks – Carries 20,000 liters of water and 4,000 liters of foam, enabling extended firefighting operations and efficient fire suppression over large areas.
2. Powerful Fire Pump and Monitor – Equipped with a CB10/100 fire pump (rapid water intake ≤35 s) and PL8/80 fire monitor, delivering 80 L/s at 1 MPa, with water reaching 80m and foam 70m for effective fire control.
3. Robust and Reliable Chassis – Built on the SINOTRUK ZZ5447TXFV466MF1 4-axle chassis, with a gross weight of 42,000 kg and a rated payload of 24,000 kg, providing strong load-bearing capacity, stability, and off-road maneuverability.
4. Durable and Ergonomic Design – Features a full steel-welded cabin for 2 personnel, an optional stainless steel tank, aluminum roller shutter doors on compartments, foldable side/rear steps, and a comprehensive lighting and signaling system for safe and practical operation.
5. High-Performance Engine and Mobility – Powered by a 297 kW MC11.44-60 diesel engine, achieving speeds up to 90 km/h, with 4/5 leaf spring suspension and wide track widths (front 2,110 mm, rear 1,830 mm) for excellent stability and maneuverability across varied terrains.

SPECIFICATION
