MAN 4×4 5000L Water Foam Fire Tender

BRIEF

The MAN 4×4 5000L Water Foam Fire Tender produced by CSCTRUCK Fire Rescue Truck is a compact yet highly capable emergency response unit designed for rapid intervention in urban, industrial, and off-road firefighting scenarios. Built on a rugged MAN 4×4 chassis, it integrates strong mobility with advanced firefighting systems, enabling reliable operation across challenging terrains while maintaining high stability and payload efficiency.

Powered by a D0836LFL90 diesel engine delivering 290 hp (213 kW), the vehicle ensures strong acceleration and sustained performance under full load. The automatic PowerMatic 08.13 OD gearbox and 4×4 drivetrain provide excellent traction and maneuverability. With a 4,200 mm wheelbase and spring suspension, it balances off-road capability with on-road comfort. The medium cabin accommodates 6 crew members and includes air conditioning and a 7-inch reversing camera for enhanced safety and operational awareness.

The fire tender carries a 4,000 L water tank and 400 L foam tank, supported by a Godiva P2A 2010 centrifugal pump for efficient discharge performance. Its roof-mounted water-foam cannon delivers adjustable flow rates from 800 to 2,400 L/min, while the foam system supports 3%–6% mixing ratios. Additional equipment includes a 5.4 m LED lighting mast, 9,979 kg electric winch, 26,000 lumen front beam light, under-chassis sprinkler system, and a 60 m hose reel. With full firefighting equipment and a versatile storage layout, it supports a crew of 6 for extended emergency operations.

The MAN 4×4 5000L Water Foam Fire Tender combines durability, versatility, and advanced firefighting technology, making it suitable for municipal fire brigades, industrial plants, airports, and emergency rescue teams. Its integrated water and foam system ensures rapid suppression of Class A and Class B fires, while its off-road capability guarantees access to remote or difficult locations. With robust construction, efficient pump performance, and comprehensive safety features, it delivers dependable emergency response capability in critical situations.

FEATURES

• Built on a rugged MAN 4×4 chassis, the fire tender delivers strong off-road mobility, high stability, and reliable performance across urban, industrial, and rough terrain environments.
• Powered by a D0836LFL90 diesel engine producing 290 hp (213 kW), it ensures fast response capability and consistent power output even under full firefighting load conditions.
• Equipped with a 4,000 L water tank and 400 L foam tank, supported by a high-performance centrifugal pump, it provides efficient dual-agent fire suppression for Class A and Class B fires.
• Features an advanced roof-mounted water-foam cannon with adjustable flow rates (800–2,400 L/min) plus a 3%–6% foam mixing system, enabling flexible and precise firefighting operations.
• Designed by CSCTRUCK Fire Rescue Truck, it includes a 6-person crew cabin, LED lighting mast, hose reel, winch, and full rescue equipment for extended emergency missions.

SPECIFICATION

1. General Information

2. Engine & Performance

3. Cabin & Controls

4. Transmission & Drivetrain

5. Chassis & Suspension

6. Axles & Tires

7. Additional Equipment & Remarks
