BRIEF
The Foton 6-ton water fire truck, produced by CSCTRUCK Fire Rescue Truck, is a robust and reliable solution for urban and rural firefighting operations. Designed with a 6-ton water tank, this tanker fire truck provides an ample water supply for extinguishing medium to large-scale fires, making it ideal for municipal fire departments, industrial sites, and emergency response teams. Its FOTON/BJ1144VKPFD-02 chassis ensures structural strength and stability while maintaining maneuverability in both city streets and more challenging terrain. The truck’s 4×2 drive type combines efficient power transmission with ease of handling, ensuring quick deployment during critical emergencies.
Powering the vehicle is the WP4.1NQ190E61 engine, delivering 140kW of engine power, which allows the fire truck to achieve a maximum speed of 110 km/h. This performance ensures rapid response times, a key factor in effective fire suppression. The engine is engineered for durability and fuel efficiency, supporting prolonged operations without frequent refueling, a crucial aspect during extended firefighting missions.
Equipped with the Shanghai CB10/40 fire pump, the Foton 6-ton water fire truck can deliver a consistent and high-pressure water flow, enabling firefighters to tackle flames effectively. Complementing the pump is the Weisite PS30W fire monitor, which provides a powerful, adjustable water stream with a reach of 60 meters or more. This allows firefighters to target fires from a safe distance, enhancing both efficiency and safety during operations.
Overall, the Foton 6-ton water fire truck is a highly capable and versatile vehicle, combining strong engineering, reliable performance, and advanced firefighting equipment. Its design emphasizes speed, water capacity, and operational efficiency, making it an essential asset for fire departments seeking a dependable solution for a wide range of firefighting challenges.
FEATURES
- Large-Capacity Water Tank
- Equipped with a 6-ton water tank, enabling extended firefighting operations without frequent refilling.
- Reliable Chassis and Drive System
- Built on the FOTON/BJ1144VKPFD-02 chassis with a 4×2 drive type, providing stable performance and easy maneuverability on urban and rural roads.
- Powerful and Efficient Engine
- Fitted with a WP4.1NQ190E61 diesel engine delivering 140 kW of power, supporting a maximum speed of 110 km/h for rapid response to emergencies.
- High-Performance Fire Pump
- Uses a Shanghai CB10/40 fire pump, ensuring strong water delivery and dependable performance during firefighting tasks.
- Long-Range Fire Monitor
- Equipped with a Weisite PS30W fire monitor capable of projecting water or foam over distances of ≥60 m, improving safety and effectiveness when tackling fires from a distance.
SPECIFICATION
| Category | Parameter | Specification |
|---|---|---|
| Chassis Parameters | Chassis Model | BJ1144VKPFD-02 |
| Chassis Manufacturer | Beiqi Foton Motor Co., Ltd. | |
| Engine Model | WP4.1NQ190E61 | |
| Engine Manufacturer | Weichai Power Co., Ltd. | |
| Engine Power | 140kW (190hp) | |
| Engine Displacement | 4,088ml | |
| Maximum Speed | 110km/h | |
| Tire Model | 8.25R20 16PR | |
| Number of Tires | 6+1 | |
| Drive Type | 4×2 | |
| Transmission | Manual 6-speed | |
| Wheelbase | 4,300mm | |
| Tank Capacity | 6 tons of water | |
| Water Monitor System Parameters | Fire Pump Model | Shanghai CB10/40 |
| Water Monitor Model | Weisite PS30W | |
| Monitor Range | ≥60m | |
| Power Take-Off Model | Full-power PTO with water cooling | |
| Vehicle Body Parameters | Cabin | 4-door flat-nose all-metal enclosed cabin, factory double-row, panoramic curved windshield, front bumper, front combination lights, electric windows, lower front cover |
| Tank | High-quality carbon steel, welded structure, internal longitudinal and transverse baffles, epoxy anti-corrosion treatment. Optional 304 stainless steel or PP materials | |
| Equipment Compartments | Fire pump placed in center or rear; 4 outlets on both sides of pump room; equipment compartments on left/right rear sides with new high-strength aluminum alloy roll-up doors; equipment brackets made from European aluminum alloy profiles, concealed tower connection, internal hex connection, durable and aesthetic. | |
| Electrical Equipment | Front top of cabin: Long row 100W siren & lights; rear: 24V/60W fire scene light; sides: red-blue flashing lights and safety indicator lights; lighting inside cabin, equipment compartments, and pump room; rotary switches and reserved interfaces for communication equipment. |
