BRIEF
The ISUZU ELF 4-ton water tender fire truck, produced by CSCTRUCK Fire Rescue Truck, is a compact yet powerful solution designed for rapid firefighting operations in urban and rural environments. Built on the durable ISUZU ELF/QL1110ANKAY chassis, this tanker fire truck combines reliability, agility, and performance, making it ideal for emergency services that require a balance between maneuverability and firefighting capacity.
Equipped with a 4-ton water tank, the truck ensures a substantial water reserve for initial response and medium-scale fire suppression. Its 4×2 drive configuration offers excellent handling and stability on paved and moderately rough roads, while its compact size allows easy access to narrow streets and congested areas where larger fire engines may struggle. At the heart of the truck is the proven 4HK1-TCG61 diesel engine, delivering 139 kW of power, enabling the truck to reach speeds up to 100 km/h, ensuring swift arrival at emergency scenes.
The firefighting system is designed to meet demanding operational needs. It includes a Shanghai CB10/30 fire pump (with an optional upgrade to CB10/40), providing reliable and efficient water delivery for fire suppression tasks. Complementing the pump is the Weisite PS30W fire monitor, capable of projecting water or foam to distances of 50 meters or more, enabling firefighters to tackle fires from a safe and effective range.
Engineered for ease of use and long service life, the ISUZU ELF 4-ton water tender fire truck integrates modern safety and operational features to support firefighting crews in their daily missions. Its balance of capacity, performance, and compactness makes it a preferred choice for municipal fire departments, industrial sites, and other facilities requiring dependable fire protection in a lightweight and economical package.
FEATURES
- Efficient Water Capacity – Equipped with a 4-ton water tank, this fire truck is ideal for small- to medium-scale fire suppression and rapid response operations.
- Reliable Powertrain – Built on the ISUZU ELF/QL1110ANKAY chassis with a 4HK1-TCG61 diesel engine delivering 139 kW, ensuring strong performance and dependable operation even under demanding conditions.
- High-Speed Mobility – Capable of reaching a maximum driving speed of 100 km/h, allowing quick deployment to emergency sites.
- Advanced Fire Pump System – Fitted with a Shanghai CB10/30 fire pump (with an optional CB10/40 pump upgrade) that provides consistent water output for various firefighting tasks.
- Powerful Fire Monitor – Outfitted with a Weisite PS30W fire monitor capable of spraying water over a distance of ≥50 m, enabling effective firefighting from a safe distance.
SPECIFICATION
1. Chassis Parameters
| Item | Specification |
|---|---|
| Chassis Model | QL1110ANKAY |
| Chassis Manufacturer | Qingling Motors Co., Ltd. |
| Engine Model | 4HK1-TCG61 |
| Engine Manufacturer | Isuzu Engine Co., Ltd. |
| Engine Power | 139 kW (190 hp) |
| Engine Displacement | 5,193 ml |
| Max Speed | 100 km/h |
| Tire Model | 235/75R17.5 16PR |
| Number of Tires | 6 + 1 |
| Drive | 4×2 |
| Gearbox | 6-speed manual |
| Wheelbase | 3,815 mm |
| Tank Capacity | 4 tons of water |
2. Water Cannon System Parameters
| Item | Specification |
|---|---|
| Fire Pump Model | Shanghai CB10/30 (optional 40 pump) |
| Fire Monitor Model | Weisite PS30W |
| Fire Monitor Range | ≥50m |
| Power Take-off (PTO) | Full-power PTO with water cooling |
3. Whole Vehicle Parameters
| Component | Description |
|---|---|
| Cab | 4-door, flat-head, fully enclosed all-metal cab; original double-row cab; panoramic curved windshield; front bumper; front combination lamps; electric windows; front grille. |
| Tank | High-quality carbon steel (Q23**), welded structure, with longitudinal and transverse anti-surge plates; epoxy anti-corrosion treatment; optional 304 stainless steel or PP material. |
| Equipment Compartment | Fire pump located centrally or at rear; pump room has four water outlets (left/right sides); equipment boxes (left, right, rear) fitted with new pull-up high-strength aluminum alloy shutters. |
| Equipment Racks | Made from European-tech aluminum profiles, hidden joint design, full hex-screw connections; attractive and durable. |
| Electrical Configuration | 100W long light bar and siren on cab roof; 24V/60W scene lamp at rear; red/blue strobe lights on both sides; safety marker lights at lower sides; interior lighting in crew cab, equipment boxes, and pump room; rotary switches and pre-wired communication device interface. |
