BRIEF
The ISUZU FVR 6-ton water tank fire truck, produced by CSCTRUCK Fire Rescue Truck, is a compact yet highly capable firefighting vehicle designed to meet the needs of urban, industrial, and rural emergency operations. Built on the sturdy ISUZU FVR/QL1180EQFRY chassis, this truck combines proven engineering with advanced firefighting equipment to deliver reliable performance in demanding environments.
Equipped with a 6-ton water tank, the truck ensures an ample water supply for first-response fire suppression, making it ideal for areas where external hydrant access may be limited. Its 4×2 drive type provides stable handling and maneuverability, supporting efficient navigation through narrow city streets or mixed-terrain routes. Powering the vehicle is the durable 6HK1-TCG61 engine, delivering 177 kW of engine power and enabling a maximum driving speed of 95 km/h, ensuring rapid deployment to emergency scenes.
The ISUZU FVR tanker fire truck is fitted with high-quality firefighting equipment for optimal performance. At its core is the Shanghai CB10/40 fire pump, known for dependable water output and consistent pressure during operations. Complementing the pump is the Weisite PS8/30 fire monitor, capable of delivering a powerful water jet with an impressive range of ≥60 meters. Together, these components enable efficient firefighting for both medium and large-scale incidents.
Engineered for versatility, the truck is suitable for a variety of applications, including urban fire suppression, industrial facility protection, and support for rural fire brigades. Its balanced design focuses on ease of operation, quick response times, and long-lasting durability. The ISUZU FVR 6-ton water tank fire truck offers an effective, cost-efficient solution for fire departments and rescue teams seeking a reliable vehicle that blends capacity, performance, and maneuverability for diverse firefighting challenges.
FEATURES
- Robust Chassis and Drive: Built on the ISUZU FVR/QL1180EQFRY chassis with a 4×2 drive type, providing stability and reliable on-road performance.
- Powerful Engine: Equipped with a 6HK1-TCG61 engine delivering 177 kW, ensuring strong power for rapid response.
- Ample Water Capacity: Features a 6-ton water tank, suitable for medium-scale firefighting operations.
- Efficient Firefighting Equipment: Includes the Shanghai CB10/40 fire pump and Weisite PS8/30 fire monitor, capable of projecting water over ≥60 meters.
- High Speed and Mobility: Maximum driving speed of 95 km/h, allowing quick deployment in urban and suburban areas.
SPECIFICATION
1. Chassis Parameters
| Item | Specification |
|---|---|
| Chassis Model | QL1180EQFRY |
| Chassis Manufacturer | Qingling Motors Co., Ltd. |
| Engine Model | 6HK1-TCG61 |
| Engine Power | 177 kW |
| Engine Displacement | 7,790 ml |
| Max Speed | 95 km/h |
| Tire Model | 295/80R22.5 16PR |
| Number of Tires | 6 + 1 |
| Drive Type | 4×2 |
| Gearbox | Manual, 8-speed (Fast 8-speed gearbox) |
| Wheelbase | 5,550 mm |
| Tank Capacity | 6 tons (water) |
2. Water Cannon System Parameters
| Item | Specification |
|---|---|
| Fire Pump Model | Shanghai CB10/40 |
| Fire Monitor Model | Weisite PS8/30 |
| Fire Monitor Range | ≥60m |
| Power Take-Off Model | Full-power PTO, water-cooled |
3. Vehicle Body Parameters
| Item | Description |
|---|---|
| Cab | 4-door, flat-front, fully enclosed all-metal cab; original double-row cab; panoramic curved windshield; front bumper; front combination lamps; electric windows; front grille panel. |
| Tank | Made of high-quality carbon steel (Q23**), welded structure with longitudinal and transverse anti-slosh baffles; epoxy anti-corrosion treatment; optional 304 stainless steel or PP material. |
| Equipment Compartment | Fire pump located in the middle or rear of the compartment; 4 water outlets on both sides of the pump room; equipment boxes on left, right, and rear fitted with new high-strength aluminum alloy roller shutters. |
| Equipment Brackets | Made of aluminum alloy profiles using European technology; hidden joint manufacturing; full inner hexagon connection structure; attractive and durable. |
| Electrical Configuration | 100W long warning light and siren mounted at the cab roof front; one 24V/60W scene light at the rear; red-blue strobe lights on both upper sides; safety lights installed below; lighting inside crew cabin, equipment compartments, and pump room; rotary switches and reserved communication equipment interface. |
