HOWO 6×6 12 CBM Airport Fire Vehicle

BRIEF



The HOWO 6×6 12 CBM airport fire vehicle, manufactured by CSCTRUCK Fire Rescue Truck, is a high-capacity aircraft rescue and firefighting vehicle engineered for rapid emergency intervention in airports, military airbases, petrochemical facilities, and large industrial fire protection zones. Combining the proven reliability of the HOWO all-wheel-drive chassis with advanced firefighting technology, this ARFF vehicle delivers outstanding mobility, powerful fire suppression capability, and exceptional operational stability under demanding rescue conditions.

With overall dimensions of 10,640 × 2,550 × 4,000 mm and a gross vehicle weight of 29,350 kg, the vehicle is designed to carry substantial firefighting resources while maintaining excellent maneuverability. Its 6×6 drivetrain, optimized approach and departure angles of 26° and 25°, and reinforced suspension system enable confident operation on runways, rough terrain, and off-road emergency environments. The 3-axle chassis supports axle loads of 8,750 kg at the front and 10,300 kg on each rear axle, ensuring balanced weight distribution and safe handling.

Power is supplied by Sinotruk’s MC13H series diesel engines, available in 2 configurations: the MC13H.57-61 delivering 422 kW, and the MC13H.60-61 producing an impressive 444 kW. Both 13.02-liter Euro VI engines provide strong acceleration and allow the vehicle to reach a maximum speed of 115 km/h, ensuring rapid response to critical incidents across large airport facilities.

The firefighting system features a total tank capacity of 11.750 m³, including a 10.100 m³ water tank and a 1.650 m³ foam tank. The specially designed concave tank structure improves vehicle stability while maximizing storage efficiency. Equipped with a high-performance fire pump and fire monitor, the vehicle delivers powerful water and foam projection for aircraft fire suppression, fuel spill containment, and rescue operations.

Additional features such as WABCO ABS, heavy-duty 20-inch tires, operational work lights, and configurable wheelbase options further enhance reliability, adaptability, and mission effectiveness, making the HOWO 6×6 12 CBM airport fire vehicle an ideal solution for modern airport firefighting operations.



FEATURES



1. High-Capacity Fire Suppression System

The HOWO 6×6 airport fire vehicle is equipped with a 12 CBM-class firefighting system, featuring a 10.100 m³ water tank and 1.650 m³ foam tank, providing a total firefighting agent capacity of 11.750 m³. Combined with a high-performance fire pump and monitor, it delivers powerful water and foam discharge for rapid suppression of aircraft fires, fuel spill incidents, and large-scale industrial emergencies.

2. Powerful Sinotruk Engine Performance

Powered by Sinotruk MC13H series Euro VI diesel engines, this ARFF vehicle offers 2 high-output configurations—422 kW or 444 kW. With a large 13.02-liter displacement, the engine delivers strong torque, rapid acceleration, and a maximum road speed of 115 km/h, ensuring fast deployment across expansive airport and industrial facilities.

3. Superior 6×6 All-Terrain Mobility

Built on a rugged HOWO 6×6 all-wheel-drive chassis, the vehicle provides exceptional traction and off-road capability. With a 26° approach angle, a 25° departure angle, reinforced suspension, and heavy-duty drivetrain components, it can confidently operate on runways, grass fields, gravel roads, and challenging rescue environments.

4. Heavy-Duty Structural Stability

With an overall size of 10,640 × 2,550 × 4,000 mm and a GVW of 29,350 kg, the vehicle is engineered for high-load operations. Its 3-axle weight distribution system and specially designed concave tank structure improve center-of-gravity control, enhance driving stability, and ensure safe handling during high-speed emergency response.

5. Advanced Safety and Operational Reliability

The vehicle is equipped with premium safety and operational features, including WABCO ABS braking system, heavy-duty 20-inch off-road tires, high-intensity work lights, and configurable wheelbase options. These features improve braking performance, nighttime visibility, operational flexibility, and overall mission reliability in demanding airport firefighting operations.



SPECIFICATION



Item	Specification
Overall Dimensions (L × W × H)	10,640 × 2,550 × 4,000 mm
Gross Vehicle Weight (GVW)	29,350 kg
Curb Weight	17,150 kg
Rated Payload	11,750 kg
Approach / Departure Angle	26° / 25°
Front / Rear Overhang	1,492 / 2,588 mm
Fuel Type	Diesel
Emission Standard	Euro VI
Axle Load	8,750 / 10,300 / 10,300 kg
Wheelbase Options	3,700 + 1,400 mm; 4,200 + 1,400 mm; 4,500 + 1,400 mm; 5,000 + 1,400 mm; 4,800 + 1,400 mm
Number of Axles	3
Maximum Speed	115 km/h
Number of Tires	6
Tire Specifications	395/85R20 20PR; 16.00R20 18PR
Leaf Spring Configuration	3/11, 3/16, 4/11, 4/16, 3/4, 4/4
Front Track	2,092 mm
Rear Track	2,092 / 2,092 mm

---

Engine Specifications

Item	Engine 1	Engine 2
Engine Model	MC13H.57-61	MC13H.60-61
Manufacturer	Sinotruk Co., Ltd.	Sinotruk Co., Ltd.
Displacement	13,020 ml (13.02 L)	13,020 ml (13.02 L)
Power Output	422 kW	444 kW

---

Tank Specifications

Item	Specification
Total Tank Volume	11.750 m³
Water Tank Capacity	10.100 m³
Water Tank Structure	“Concave” shaped tank
Front Left Water Tank Size (L × W × H)	1,230 × 780 × 1,480 mm
Front Right Water Tank Size (L × W × H)	1,230 × 780 × 1,480 mm
Rear Water Tank Size (L × W × H)	2,080 × 2,510 × 1,480 mm
Foam Tank Capacity	1.650 m³
Foam Tank Size (L × W × H)	1,230 × 950 × 1,480 mm

---

Additional Technical Information

Item	Specification
Front Extension	360 mm
ABS Manufacturer	WABCO Automotive Control Systems (China) Co., Ltd.
ABS Model	4460046300
Main Firefighting Equipment	Fire Pump, Fire Monitor
Work Lights	Side and rear work lights may only be used during operations, not while driving
Optional Equipment	Rear-view mirrors are selectable with the chassis.
