BRIEF
The MAN 4-ton chemical hazmat fire truck produced by CSCTRUCK Fire Rescue Truck is a highly specialized vehicle designed for rapid response to hazardous material incidents. Built on the robust MAN TGS 26.480 chassis, it features a 6×4 drive configuration that ensures excellent mobility and stability even in challenging terrains. Powered by a 353 kW engine operating at 1,900 rpm, the truck can reach a maximum speed of 90 km/h, providing both reliability and agility during emergency operations.
One of the key features of this hazmat fire truck is its 4,000 kg decontamination tank, which allows for efficient on-site chemical containment and cleanup. The vehicle is equipped with a 12 VA generator that delivers a rated power output at 50 Hz frequency, supporting both 220V and 380V voltages, ensuring sufficient electrical capacity for all on-board equipment. Its lighting system includes four 1,000W telescopic lights with Quartz halogen lamps, providing powerful illumination for nighttime operations or poorly lit environments, with a maximum reach of 7.6 meters from the ground. The working voltage for auxiliary equipment is 220V, supporting various tools and devices essential for hazmat response.
The MAN 4-ton chemical hazmat fire truck combines safety, efficiency, and advanced technology to handle chemical spills, hazardous material incidents, and decontamination operations. Its compact yet powerful design ensures rapid deployment, while the sturdy chassis and high-capacity tank enhance operational effectiveness. By integrating advanced lighting, generator systems, and reliable mechanical performance, this vehicle represents a comprehensive solution for fire departments and emergency response teams tasked with handling dangerous chemical environments. Its thoughtful design prioritizes both crew safety and operational efficiency, making it an indispensable asset for modern fire and hazmat rescue services.
This MAN hazmat truck exemplifies the combination of heavy-duty engineering, high-performance systems, and specialized firefighting capabilities tailored for chemical hazard management.
FEATURES
- High-capacity decontamination tank – Equipped with a 4,000 kg decontamination tank, allowing efficient chemical spill and hazardous material response.
- Powerful chassis and engine – Built on a MAN TGS 26.480 6×4 chassis with a 353 kW/1,900 rpm engine, ensuring strong performance and stability in emergencies.
- Advanced lighting system – Features 4×1,000 W telescopic lights with quartz halogen lamps, reaching a maximum height of 7.6 m for excellent night-time or low-visibility operations.
- Reliable on-board power supply – Includes a 12 VA generator supporting 50 Hz frequency and dual voltage output (220 V/380 V) for powering equipment and tools on-site.
- Rapid response capability – Maximum driving speed of 90 km/h, combined with robust 6×4 drive, ensures fast and safe access to hazardous incident sites.
SPECIFICATION
1. MAN 4ton Chemical Hazmat Fire Truck
| Parameter | Specification |
|---|---|
| Dimensions | 10,350×2,500×3,680 mm |
| Total mass of full load | 20,100 kg |
| Number of crew | 6 |
| Maximum speed | 90 km/h |
| Volume of decontamination tank | 4,000 kg |
2. Chassis
| Parameter | Specification |
|---|---|
| Manufacturer | Germany MAN Commercial Vehicle AG |
| Model | MAN TGS 26.480 |
| Drive form | 6×4 |
| Wheelbase | 4,500mm + 1,400mm |
| Seats | 2 + 4 |
| Engine power | 353kW/1,900 rpm |
| Rated torque | 2,300 N·m / 1,050–1,400 rpm |
| Gearbox | 16-speed manual |
| Power take-off | Full power take-off |
| Fuel tank capacity | 300 L |
3. Superstructure
| No. | Main Items | Technical Parameters |
| 3.1 | Cabin | |
| 3.1.1 | Structure | Single row cabin+crew cabin |
| 3.1.2 | Seats | 2+4, with a 3-point safety belt, the rear 4 seats with SCBA bracket for 6-9L air cylinders, with a storage box under the rear 4 seats |
| 3.2 | Standardized Sub-frame | |
| 3.2.1 | Material | High-strength rectangular tube made of special steel |
| 3.2.2 | Performance | Elastic connecting seats connect the liquid tank and the sub-frame |
| 3.3 | Compartment | |
| 3.3.1 | Material | High-strength aluminum alloy profiles (Never Rust) |
| 3.3.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear |
| 3.4 | Roller Shutter Door | |
| 3.4.1 | Material | Aluminum alloy profiles with anodized surface |
| 3.4.2 | Structure | With a rain-proof groove on the top, lever-type bar, lock handle, pull strap, two-point fixed seat, LED light, and sensors. |
| 3.5 | Foot Pedals | |
| 3.5.1 | Material | High-quality aluminum alloy |
| 3.5.2 | Structure | 50cm width, capable of bearing more than 300kg, featuring an anti-slip design with a double lock function. Mounted on both sides of the compartment. |
| 3.6 | Superstructure Electric Appliance | |
| 3.6.1 | Warning Light and Siren | Long-row warning light and siren are mounted above the cabin. The controller is installed in the driver’s cabin. |
| 3.6.2 | Strobe Light | Mounted on both sides of the compartment |
| 3.6.3 | External Lighting | LED lights are mounted on both sides of the compartment |
| 3.6.4 | Roof Lighting | LED lights are mounted on the inside of the roof |
| 3.6.5 | Side Indicator Light | The inline yellow warning light is mounted on the side of the compartment and pedals |
| 3.7 | Generator | |
| 3.7.1 | Brand | Optional |
| 3.7.2 | Model | Optional |
| 3.7.3 | Drive Type | Gasoline Generator |
| 3.7.4 | Rated Power | 12VA |
| 3.7.5 | Rated Frequency | 50Hz |
| 3.7.6 | Rated Voltage | 220V/380V |
| 3.7.7 | Location | In the storage compartment |
| 3.8 | Telescopic Light | |
| 3.8.1 | Brand | Optional |
| 3.8.2 | Model | Optional |
| 3.8.3 | Power | 4×1,000W |
| 3.8.4 | Lamp | Quartz halogen lamp |
| 3.8.5 | The Max. Height | 7.6m from the ground |
| 3.8.6 | Rotation Angle | Horizontal: 360°, Pitch 120° |
| 3.8.7 | Working Voltage | 220V |
| 3.8.8 | Installation Type | On the roof. |
