The ISUZU ELF double-cab 3.5-Ton foam fire truck is a versatile and highly efficient emergency response vehicle, meticulously engineered to meet modern firefighting demands. Built on the reliable ISUZU ELF double-cab chassis, this fire truck combines robust performance with practical functionality. At its core, it is powered by a 190 hp ISUZU engine paired with a 6-speed manual gearbox, ensuring smooth and responsive handling across diverse urban and rural terrains. The vehicle rides on durable 235/75R17.5 tires, providing stability, traction, and reliability during emergency operations. Standard equipment includes ABS for enhanced braking safety, power-assisted steering for easier maneuverability, air conditioning for crew comfort, electric windows, and central locking for convenience and security.
The mounted body of the tankerfire truck is constructed from a combination of high-quality steel and high-strength aluminum profiles, ensuring both structural integrity and reduced overall weight. Both the inner and outer panels are made from corrugated aluminum sheets, which offer superior resistance to deformation and corrosion while maintaining a lightweight design. The layout of the truck body is strategically divided to optimize operational efficiency: the front compartment serves as storage for essential firefighting equipment, the middle section houses the water and foam tanks, and the rear section contains the pump room, providing easy access for rapid deployment.
Component
Specification / Details
Water Tank
Capacity: 2,600 kg (2.6 m³) Dimensions: 1,830 × 1,330 × 1,120 mm
Class B Foam Tank
Capacity: 780 kg (0.765 m³) Foam density: 1.02 g/mL Dimensions: 535 × 1,330 × 1,120 mm
Total Tank Capacity
3.365 m³
Fire Pump
Type 30
Fire Monitor
Model: PS30W Range: >50 m
Side Protective Device
Material: Q235 steel, Integral structure for rigidity
Rear Lower Protective Device
Material: Q235 steel, Cross-section: 100 × 100 mm, Ground clearance: 490 mm, Bolted installation for chassis protection.
Designed with a double-cab layout, this fire truck can accommodate up to 6 personnel (3+3 seating configuration), allowing multiple firefighting and rescue team members to travel together to the emergency site. This arrangement significantly improves response efficiency and coordination during rescue operations, making it a reliable and practical solution for both municipal and industrial fire departments. Combining powerful performance, well-thought-out design, and essential firefighting equipment, the ISUZU ELF double-cab 3.5-Ton foam fire truck is a robust, safe, and highly functional vehicle for modern fire and rescue services.
