BRIEF
The ISUZU GIGA 3 CBM pumper fire engine produced by CSCTRUCK Fire Rescue Truck is a compact and highly efficient firefighting vehicle designed for urban, industrial, residential, and municipal emergency response operations. Built on a dependable 4×2 left-hand-drive chassis, this fire engine combines maneuverability, durability, and professional firefighting performance, making it an excellent solution for cities, towns, factories, and fire brigades requiring a medium-capacity pumper truck.
With overall dimensions of 6,200 × 2,400 × 2,850 mm and a 3,300 mm wheelbase, the truck offers excellent road handling and easy access to narrow streets or crowded urban environments. Powered by a 3,856 ml diesel engine delivering 95 horsepower, it achieves a maximum speed of 100 km/h, ensuring rapid deployment during emergencies. The manual transmission system provides dependable driving control under varying road and terrain conditions.
The vehicle is equipped with a 3,000-liter water tank manufactured from high-quality carbon steel sheet with a thickness of 3–4 mm, ensuring structural strength and long service life. Internal tank fittings include an ingate, overflow valve, liquid level gauge, and manual sewage outlet for efficient maintenance and water management.

Its firefighting system features the proven CB10/20 fire pump, capable of delivering 20 L/s flow at 1.0 MPa pressure, with a fast priming time of only 30 seconds. The truck can be configured with either rear or mid-mounted pump placement for operational flexibility. Mounted on top is a PS20 fire monitor, delivering 20 L/s flow with a throwing range of 40 meters, full 360° horizontal rotation, and -30° to +80° elevation adjustment, enabling accurate fire suppression from multiple angles.
The power takeoff system uses a sandwich full-power PTO, controlled by a solenoid valve, with adjustable water cooling and splash lubrication for reliable long-term operation.
Additionally, the ISUZU GIGA 3 CBM pumper fire engine carries a full set of firefighting tools, including suction hoses, fire hoses, strainers, hydrant wrenches, extinguishers, axes, spades, buckets, and rescue accessories, making it a complete and ready-to-deploy firefighting unit.
FEATURES
- Compact Urban Response Design
Built on a reliable ISUZU GIGA 4×2 left-hand-drive chassis, this 3 CBM pumper fire engine features compact dimensions of 6,200 × 2,400 × 2,850 mm and a 3,300 mm wheelbase, allowing excellent maneuverability in narrow streets, residential districts, industrial plants, and congested city environments. - Efficient Diesel Powertrain
Equipped with a 3,856 ml diesel engine producing 95 horsepower, the vehicle reaches a maximum speed of 100 km/h for rapid emergency deployment. The manual transmission ensures dependable control and stable performance across varied road conditions. - Durable 3,000-Liter Water Tank
The fire engine carries a 3 CBM water tank constructed from 3–4 mm high-quality carbon steel for strength and longevity. The tank includes practical fittings such as an overflow valve, liquid level gauge, sewage outlet, and water inlet system for efficient operation and maintenance. - Professional Firefighting Pump and Monitor
Fitted with a CB10/20 fire pump, the truck delivers 20 L/s flow at 1.0 MPa pressure with a fast priming time of only 30 seconds. The top-mounted PS20 fire monitor offers 20 L/s discharge, a 40-meter water throwing range, 360° horizontal rotation, and wide elevation adjustment for precise firefighting coverage. - Complete Ready-to-Use Equipment Package
The ISUZU GIGA 3 CBM pumper fire engine comes fully equipped with essential firefighting and rescue tools, including suction hoses, delivery hoses, hydrant wrenches, extinguishers, strainers, axes, buckets, shovels, and other accessories, ensuring immediate readiness for emergency response tasks.
SPECIFICATION
| Items | Descriptions | Parameters |
| Fundamental Information
|
Drive Type | 4×2, LHD |
| Transmission | Manual | |
| Brand | CSCTRUCK Fire Rescue Truck | |
| Overall Dimensions (L×W×H) (mm) | 6,200×2,400×2,850 | |
| Water Tank Capacity (L) | 3,000 | |
| Wheel Base (mm) | 3,300 | |
| Gross Weight (kg) | 6,000 | |
| Curb Weight (kg) | 2,875 | |
| Tire
|
Tire Model | 6.50-16 10PR,
7.00-16 10PR |
| No. of Tires | 6 | |
| Engine
|
Engine Displacement (ml) and Emission Standard | 3,856(Euro 3) |
| Power (ps) | 95 | |
| Power Oil | Diesel oil | |
| Other Items | Maximum Speed (km/h) | 100 |
| No. of Passengers | 6-8 |
| Tank | Water Tank Capacity (m³) | 3 |
| Material | High-quality carbon steel sheet | |
| Thickness(mm) | 3~4 | |
| Inside Devices | Ingate, overflow valve, fluid level gauge,
Sewage outfall(Manual) |
|
| Fire Pump | Model | CB10/20 |
| Flow(L/s) | 20(standard pressure) | |
| Pressure(MPa) | 1.0(low pressure) | |
| Delivery time(s) | 30 | |
| Position | Postposition or middle position | |
| Fire Monitor | Model | PS20 |
| Pressure(MPa) | 0.8~1.0 | |
| Flow(L/s) | 20 | |
| Range(m) | 40 | |
| Working Angle(°) | 360(horizontal), -30~80(elevation) | |
| Operation Mode | Manual | |
| Power Takeoff | Type | Sandwich and full power |
| Operation Mode | Dominated by a solenoid valve | |
| Cooling Mode | Mandatory and adjustable water cooling | |
| Lubrication Mode | Splash oil lubricating |
Fire-fighting equipment:
|
Descriptions |
Specifications |
Quantities |
|
Water Absorption Tube |
Φ100mm×2m |
4 |
|
Water Strainer |
φ135mm |
1 |
|
Water Separator |
FFS80 |
1 |
|
Firehose |
φ80mm×20m |
3 |
|
Firehose |
φ65mm×20m |
3 |
|
Reducing Joint |
Φ80/ Φ65 |
1 |
|
Belt Bridge |
FH80 |
1 |
|
Water Collector |
FJ100 |
1 |
|
Infantees of Water Bag |
FP470 |
4 |
|
Hook of Water Bag |
FG600 |
4 |
|
Spanner of Fire Hydrant Underground |
FBA800 |
1 |
|
Spanner of Fire Hydrant Overground |
FB450 |
1 |
|
Spanner of Suction Pipe |
FS100 |
2 |
|
Dry-Chemical Fire Extinguisher* 2kg |
MFZ2 |
1 |
|
Squirt Gun |
|
1 |
|
Fire Bucket |
|
1 |
|
Fire Spade |
2# |
1 |
|
Door Breaker |
GT06 |
1 |
|
Small Fire Axe |
GF325 |
1 |
|
Fire Axe |
GFP890 |
1 |
